Instruction and Operation Manual
Wireless
DP Transmitter Adapter
Dear Customer,
Thank you for choosing our product.
The operating instructions must be read in full and carefully observed
before you start up the device. The manufacturer cannot be held liable
for any damage which occurs as a result of non-observance or non-
compliance with this manual.
Should the device be tampered with in any manner other than a
procedure which is described and specified in the manual, the warranty
is void and the manufacturer is exempt from liability.
The device is designed exclusively for the described application.
S TO offers no guarantee for the suitability for any other purpose.
S TO is also not liable for consequential damage resulting from the
delivery, capability or use of this device.
2 Wireless DP Transmitter Adapter
Table of Contents
1 Safety instructions......................................................................4
2 Registered trademarks.................................................................5
3 RF Exposure Information and Statement........................................6
4 Application.................................................................................7
5 Features....................................................................................7
6 Technical Data ...........................................................................7
7 Contents of Package....................................................................8
8 Installation.................................................................................9
8.1 Add the DP Adapter to Existing System..................................10
8.2 Connect the DP Adapter to External Power Supply...................10
9 se the S4C-DP App..................................................................11
9.1 Download and Install...........................................................11
9.2 Get Service Partner Permission..............................................11
9.3 Enable the Configuration ....................................................12
10 S4C-DP App Instructions..........................................................14
10.1 Features...........................................................................14
10.2 Menus..............................................................................14
10.3 Online..............................................................................15
10.4 Settings............................................................................15
10.4.1 Dew Point Settings....................................................15
10.4.2 Sensor Display Channel.............................................16
10.4.3 Output Settings........................................................17
10.5 Calibration........................................................................17
10.5.1 Pressure Calibration..................................................17
10.5.2 One-point Calibration Dew Point..................................18
10.6 System.............................................................................18
10.6.1 Sensor Info..............................................................18
10.6.2 Language.................................................................19
10.6.3 App Version..............................................................19
11 Maintenance...........................................................................19
12 Disposal or Waste....................................................................19
Wireless DP Transmitter Adapter 3
1 Safety instructions
1 Safety instructions
Please check if this instruction manual accords ith the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which have to be
observed before and during installation, operation and
maintenance. Therefore this instruction manual has to be read carefully
by the technician as well as by the responsible user / qualified
personnel.
This instruction manual has to be available at the operation site of the
service kit at any time. In case of any obscurities or questions,
regarding this manual or the product, please contact the manufacturer.
WARNING!
Voltage used for supply!
Any contact ith energized parts of the product, may
lead to an electrical shock hich can lead to serious
injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance work.
•Any electrical work on the system is only allowed by authorized
qualified personal.
ATTENTION!
Permitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding the parameters can lead to
malfunctions and may lead to damage on the
instrument or the system.
•Do not exceed the permitted operating parameters.
•Make sure the product is operated in its permitted limitations.
•Do not exceed or undercut the permitted storage and operation
temperature and pressure.
4 Wireless DP Transmitter Adapter
1 Safety instructions
General safety instructions
•It is not allowed to use the product in explosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
Storage and transportation
•Make sure that the transportation temperature of the service kit
between -10°C ... +50°C.
•For transportation it is recommended to use the packaging that
comes with the device.
•Make sure that the storage temperature of the device is between
-10°C ... +50°C.
•Avoid direct V and solar radiation during storage.
•For the storage the humidity must be <90%, no condensation.
2 Registered trademarks
S TO®Registered trademark of S TO iTEC
MODB S®Registered trademark of the Modbus Organization,
Hopkinton, SA
Android™,
Google Play
Trademarks of Google LLC
Wireless DP Transmitter Adapter 5
3 RF Exposure Information and Statement
3 RF Exposure Information and Statement
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance of 20 cm between the radiator and
your body.
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help
•This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter.
6 Wireless DP Transmitter Adapter
4 Application
4 Application
The Wireless DP Transmitter Adapter provides a wireless interface
between the mobile phone App S4C-DP and the S TO Dew Point
Transmitters of the S211, S215, and S220. With this DP Adapter, you
can manage the Dew Point Transmitter settings through the free mobile
phone App S4C-DP, including:
•Read, configure, and verify operating parameters
•Monitor online measurement values
•Calibrate the Dew Point Transmitters
The Wireless DP Transmitter Adapter is referred to as DP Adapter for
short in the following description.
5 Features
•Connect mobile phone and Dew Point Transmitters with wireless
connection *
•M12 connector
•24 VDC power supply
•Extra low power consumption
* The DP Adapter contained the SRRC approved radio modular with
CMIIT ID: 2020DP2713.
6 Technical Data
Contains FCC ID: 2AC7Z-ESP32WROOM32E
Housing material Plastic casing
Connector M12, 5 pins
Weight 0.12 kg (without power supply)
Plug adapter power input 100...240 VAC / 0.7 A
Plug adapter power output 24 VDC/0.05 A
Power consumption of Wireless
DP Transmitter Adapter
1.2 W
Operating temperature -10℃ ... +50℃
Wireless DP Transmitter Adapter 7
7 Contents of Packa e
7 Contents of Package
Make sure that all components listed below are included in your
package.
Qty Description Ordering No.
1 Wireless DP Transmitter Adapter with M12
connection cable, and a 100...240 VAC/24 VDC
power supply (including 3 plug adapters of S,
E and K types) with 1.5 m cable
A699 3302
1 Instruction manual No P/N
8 Wireless DP Transmitter Adapter
8 Installation
8 Installation
The DP Adapter supports all models of the S211, S215, and S220, as
shown in the table below.
De Point
Transmitter Ordering No. Model
S211
S699 1211 2-wire analog + SDI
S699 2211 3-wire analog + SDI
S699 3211 3-wire analog + Modbus/RT
S699 4211 3-wire analog + Modbus/RT
with pressure sensor
S215
S699 1215 2-wire analog + SDI
S699 2215 3-wire analog + SDI
S699 3215 3-wire analog + Modbus/RT
S699 4215 3-wire analog + Modbus/RT
with pressure sensor
S220
S699 1220 2-wire analog + SDI
S699 2220 3-wire analog + SDI
S699 3220 3-wire analog + Modbus/RT
S699 4220 3-wire analog + Modbus/RT
with pressure sensor
The power consumption of the DP Adapter is low, which allows to
directly add it to the existing dew point transmitter connection system
with the existing power supply.
Besides, another solution is provided by using the supplied 100...240
VAC/24 VDC power supply adapter, which makes it more flexible on site.
Wireless DP Transmitter Adapter 9
8 Installation
8.1 Add the DP Adapter to Existing System
1. Connect the dew point transmitter with the M12 connector on the
DP Adapter.
2. Connect the DP Adapter to your existing power supply by the M12
cable.
8.2 Connect the DP Adapter to External Po er Supply
1. Connect the Dew Point Transmitter with the M12 connector on the
DP Adapter.
2. Connect the DP Adapter with the M12 connector on the power
supply adapter.
3. Plug the power supply adapter into an electricity supply.
