CAM3260
Megapixel IR Bullet Outdoor
Network Camera
User Manual
Release 1.3
July, 2010
Surveon CAM3260
All Rights Reserved © Surveon Technology 2010
Copyright Statement
No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written consent of
Surveon Technology Inc.
Disclaimer
Surveon Technology makes no representations or warranties with respect to
the contents hereof and specifically disclaim any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, Surveon
Technology reserves the right to revise this publication and to make changes
from time to time in the content hereof without obligation to notify any
person of such revisions or changes. Product specifications are also subject to
change without notice.
Trademarks
Surveon and Surveon logo are trademarks of Surveon Technology Inc. All
other names, brands, products or services are trademarks or registered
trademarks of their respective owners
1
Surveon Network Camera User Manual
Surveon CAM3260
Table of Contents
Copyright Statement.......................................................................... 1
Table of Contents ............................................................................. 2
Chapter 1. Overview.......................................................................... 4
1.1. Network Camera Introduction ......................................................4
1.2. Network Camera Features...........................................................4
1.3. Network Camera Specifications ....................................................5
System Structure ..........................................................................7
1.4. Network Camera Hardware Installation ..........................................7
Chapter 2. Connecting to the Network Camera......................................... 8
2.1. Connecting with a Web Browser ...................................................9
Logging into the System for the First Time ......................................... 10
Installing Active X Components in Internet Explorer .............................. 11
Logging Out of the System............................................................. 12
Using the Help Interface ............................................................... 12
2.2. Connecting with an RTSP Player .................................................13
Connecting with a Mobile Device RTSP Player...................................... 13
Chapter 3. Web Interface...................................................................14
3.1. Interface Layout.....................................................................14
Control Descriptions .................................................................... 15
3.2. Settings................................................................................17
General.................................................................................... 17
Basic Settings ....................................................................... 17
User Account ........................................................................ 19
Date & Time......................................................................... 22
Network................................................................................... 23
Network Configuration............................................................. 24
Port Settings......................................................................... 25
UPnP.................................................................................. 26
Video & Audio Settings ................................................................. 27
www.surveon.com
2
Surveon CAM3260
Basic Settings ....................................................................... 27
Image Appearance.................................................................. 28
Video Streams....................................................................... 31
Audio Settings....................................................................... 33
PTZ......................................................................................... 34
Recording................................................................................. 35
Recording Basic Settings .......................................................... 35
Recorded File Management....................................................... 36
Event Notification....................................................................... 38
Event Server......................................................................... 38
Motion Detection ................................................................... 40
Tampering Detection .............................................................. 41
Tampering Detection .............................................................. 42
DI & DO............................................................................... 43
Event Settings....................................................................... 45
System..................................................................................... 51
MicroSD Card Management........................................................ 51
System Status ....................................................................... 52
System log ........................................................................... 53
Firmware Upgrade.................................................................. 54
Reset to Factory Default .......................................................... 55
Export/Import & Reboot .......................................................... 56
3
Surveon Network Camera User Manual
Surveon CAM3260
Chapter 1. Overview
1.1. Network Camera Introduction
CAM3260 is a professional IP network camera utilizing Internet Protocol (IP) to
transmit video streams and control signals over networks. Capable of operating
over both LANs and WANs, CAM3260 provides a complete budget-conscious remote
surveillance solution that is ultra clear and highly integrated. The CAM3260
combines a user-friendly interface and simplified installation with a powerful
feature set, including Motion Detection and Tampering Detection to provide users
an easy upgrade path to new digital surveillance system in a virtual environment.
These highlights make CAM3260 an ideal choice for environments that require
remote surveillance or video transmission.
1.2. Network Camera Features
Supports up to 10 simultaneous users
Built-in web server to allow real-time remote surveillance and control
using standard web browsers
Built-in microSD card slot for local backup
Supports dynamic IP, LAN, and the Internet (ADSL, Cable modem)
Supports most network protocols including: HTTP, TCP/IP, SMTP, DDNS,
DNS, DHCP, FTP, RTSP,CIFS, PPPoE
Supports 2-way audio
Automatically adapts image compression rate to available bandwidth
Provides Signal loss and motion-detection alerts (adjustable area and
sensitivity level)
Supports image recording and still image capture
www.surveon.com
4
Surveon CAM3260
1.3. Network Camera Specifications
CAM3260
Image sensor 1/3” 1.3 megapixel progressive scan CMOS
Lens 2.8-11 mm varifocal lens, F1.4
Viewing
Angle
Diagonal:122° ~ 35°
Horizontal:96° ~ 28°
Vertical: 72° ~ 21°
Day/Night Yes
IR LED Yes (30 m)
Min
illumination 0 lux (IR LEDs on)
Iris control N/A
Shutter time 1/5 ~ 1/15,000 s
Video
compression H.264 / MPEG-4 / MJPEG
Resolution Up to 1280x1024 (SXGA)
Video
control
Auto Gain Control, Auto White Balance, Auto
Electronic Shutter, Backlight Compensation,
Image Adjustment
Frame rate 15 fps at SXGA (1280 x 1024), 15 fps at HD720
(1280 x 720), 30 fps at VGA (640 x 480), 30 fps at
QVGA (320 x 240) , 30 fps at QQVGA (160 x 120)
Video
stream 2 simultaneous streams
at H.264, MPEG-4, and MJPEG
Bit rate 32K ~ 10Mbps, VBR, CBR
Intelligent
video Motion detection, tempering detection (blocked,
redirected, defocused, or spray-painted)
Built-in MIC N/A
Audio
compression 32KHz, ADPCM
Audio input 3.5mm phone jack
Audio output 3.5mm phone jack
Alarm in 2, Terminal block
Alarm out 1, Terminal block
AUX Power
Output 12VDC 400mA
Video buffer 2 second pre-alarm, 30 second post-alarm
5
Surveon Network Camera User Manual
Surveon CAM3260
Event action Send snapshot or video clip by FTP or email,
record to NAS, record to local storage, trigger DO
Supported
protocols
IPv4, ARP, TCP, UDP, ICMP, DHCP, NTP, DDNS,
SMTP, FTP, HTTP, CIFS, PPPoE, UPnP, RTP, RTSP,
RTCP, 3GPP
Ethernet 10/100 Base-T / RJ45
Local
storage microSD/SDHC card slot x 1 (Class 4/Class 6 only)
RS-485 1 (2 pins on terminal block)
SDK Surveon SDK 2.0
OS Microsoft Windows XP/Vista/7 (32 bit)
Browser Microsoft IE 6.0 or above
Software Surveon VMS 2.0
Temperature Operation: -20°C ~ 50°C (-4°F ~ 122°F)
Non-operation: -30°C ~ 70°C (-22°F ~ 158°F)
Humidity 20% ~ 95%, non-condensing
Power 12VDC
PoE (IEEE 802.3af) with Class 3
Power
consumption Max. 9.6 W (w/o Heater, no AUX Power)
Max. 25 W (w/ Heater, no AUX Power)
Dimension
(WxHxD) 105 x 218.8 x 191.41 mm (3.44" x 7.18" x 6.28")
Weight Net: 1,400g (3.09lb.)
Gross: 2,170g (4.8lb.)
Certification Safety: LVD
EMC: FCC, CE
IP66
www.surveon.com
6
Surveon CAM3260
System Structure
1.4. Network Camera Hardware Installation
Before the network camera is configured:
1. Install the camera in a suitable spot. The camera should have an
unobstructed view of the area to be surveyed.
2. Connect the camera to a power source. CAM3260 can accept power
from a power adapter or from Power over Ethernet enabled switches.
3. Connect the camera to a switch using an Ethernet cable. The Ethernet
port is located on the rear of the camera.
7
Surveon Network Camera User Manual
Surveon CAM3260
Chapter 2. Connecting to the
Network Camera
This section demonstrates how to connect to the network camera through two
methods:
•Web Browser – A simple web-based interface. Internet Explorer is the
recommended web browser for use with Surveon network cameras, and
our examples will be from this browser. Usage on other browsers will
be similar.
•RTSP Player – These include common streaming media players, such as
RealPlayer or Quicktime Player. These players can provide live view of
the camera using the Real-Time Streaming Protocol (RTSP).
