Surefire A2-HA-xx Manuel utilisateur

Model A2-HA-xx

A2 AviatorDigital Plus™ Flashlight

Digitally-Controlled Dual Light

Source Flashlight

Operator’s Manual

Revision A 6-1-2003

A2 AVIATOR

Introduction

The A2 Aviator®is fitted with three LEDs (Light

Emitting Diodes) surrounding an incandescent

main lamp. Powered by two 3-volt lithium

batteries, the Aviator features digital current

regulation circuitry and a two-stage switch. The

current regulation circuitry matches the lamp’s

current requirements to the batteries’ output to

achieve a more consistent (even) level of light

output for the useable life of the batteries. The two-

stage switch gives the user a choice of either a low-

output LED or a high-output incandescent beam

from a single switch. The Aviator is available in

four LED colors: White (WH), Blue (BL), Green

(GN), and Red (RD).

Light Activation

Depress the tailcap pushbutton switch for

momentary activation. Depressing switch halfway

activates the low-output LEDs. Depress

pushbutton completely to activate high-output

incandescent lamp: the light will stay on as long as

the pushbutton is depressed. Note: If light fails to

function, the tailcap may be in the lock-out

position. Rotate the tailcap clockwise until the light

can be momentarily activated.

For constant light rotate the tailcap clockwise until

the LEDs activate, continue rotating to activate

high-output beam. Note: The Aviator is a high-

output lighting device and should not be left on

unattended. External surface temperature will rise

during prolonged operation; this is a normal

operating phenomenon.

OPERATION

Lock-out Tailcap (U.S. Patent Number 6,222,138)

The lock-out position disables the tailcap

pushbutton switch and is suggested to avoid

accidental light activation during storage. From the

momentary-on position, rotate the tailcap

approximately one and one half turns counter-

clockwise to lock the light in the OFF position.

Battery Replacement

Unscrew the tailcap and insert new batteries with

positive ends toward LED assembly. Replace

tailcap and rotate clockwise to the momentary-on

position. Depress tailcap pushbutton switch to test.

WARNING: Lithium batteries can explode or

cause burns if disassembled, shorted, recharged or

exposed to fire or high temperatures. Do not mix

with used batteries or other battery types, or put in

backwards.

Maintenance

Twice yearly (or more frequently depending on

usage) clean and lubricate threads with a clean

cloth and apply thin coat of silicon-based lubricant

to rubber O-rings. Note: DO NOT use petroleum-

based lubricant on SureFire O-rings. After

prolonged exposure to moisture, the bezel, lamp,

and batteries should be removed, inspected, and

dried if necessary.

Caution

Make sure the Lamp is off before storage to

prevent damage caused from overheating the

Lamp or nearby objects.

This unit has approval

SUREFIRE®

LED ASSEMBLY

SCREW (3)

FLASHLIGHT BODY

SF123A

BATTERY

LOCK-OUT TAILCAP

A2 AVIATOR LED

SureFire A2 Aviator

Tested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

Output & Runtime

Accurately specifying light output (lumens) and

runtime is more complicated for LED flashlights

than it is for tungsten lamp flashlights.

What can be said, in simple terms at this time, is

that the light output of the A2 exceeds the 60

lumen output of comparable SureFire tungsten

lamp flashlights (6P, C2, E2e, etc.), and runtime is

longer than the one hour specified for these

tungsten lamp flashlights.

A2 AVIATOR LED

Warranty Claims

For repair or replacement contact Customer

Service at 800-828-8809 (toll free) or 714-

545-9444 and obtain a Return Merchandise

Authorization number (RMA#). Then

package the unit carefully and return (no

COD’s please) to:

SureFire

Repairs Department, RMA#___

17680 Newhope Street, Suite B

Fountain Valley, CA 92708-6122

SureFire will pay any reasonable shipping

costs to return the unit to you.

Warranty

SureFire®warrants its products to be free

from defects in materials and workmanship.

SureFire will repair or replace, at its option

without charge, any product or part found to

be defective under normal use and service.

Such repair or replacement shall be the

purchaser’s sole and exclusive remedy under

this warranty. This warranty does not

include normal maintenance and services

and does not apply to any products or parts

that have been subjected to modification,

misuse, negligence, accident, improper

maintenance or repair by anyone other than

SureFire.

Warranty Limitation

There is no other express warranty.

SureFire®hereby disclaims any and all

implied warranties, including but not limited

to fitness for a particular purpose. SureFire

shall not be liable for incidental,

consequential, or special damages arising

out of, or in connection with, product use or

performance.

UM_A2

71-01-604

18300 Mt. Baldy Circle, Fountain Valley, CA 92708-6122

www.surefire.com 800-828-8809
