INTRODUCTION

The MLR2-E is a Multi-Line, Multi-Format Digital Receiver for

commercial fire and burglary. The basic unit consists of up

to 30 individual line cards (DRL2E) connected to a CPM2.

The MLR2-E can decode a variety of popular and widely

used communication formats. Refer to Appendix A, DRL2E

Communication Formats for a list of the available communication

protocols.

The MLR2-E’s real-time clock and calendar stamps all

information received with the time and date, and all information

may be printed and/or forwarded to a computer. To ensure

security, adjustment of the clock, calendar and other

programming is password-protected.

CPM2

The CPM2 Central Processing Module oversees operation

of the line cards. Along with its built-in keypad and LCD

message screen, the CPM2 features one parallel printer,

and two COM Ports.

DRL2E

Each DRL2E Module can monitor two telephone lines. The

Line Card module is equipped with a 256-event nonvolatile

memory buffer to record events and corresponding telephone

numbers. Caller Source capability is built-in and telephone

numbers can be printed out, sent to automation and stored

in memory. Events and information stored in memory can be

printed at any time. Each line card also features flash EPROM

uploads through the Debug port for software upgrades or

options programming.

SUPERVISION

The standby battery voltage and connections are supervised.

The Line Cards are also continuously supervised to ensure

uninterrupted communication with the CPM2. Any trouble

conditions are reported on the LCD screens and sent to the

printer and the computer.

The DRL2E Line Card Module also verifies communications with

the CPM2. In the event of a malfunction, the operator will be

advised with a visual indication and the Line Cards will continue

to function. Each line card will continue to receive information.

The printer is supervised for loss of power, off-line, paper out

and other trouble conditions. The communication link to the

computer through the RS-232 port is monitored by the

supervisory “heartbeat” test transmissions.

COMPATIBILITY

Central station automation software packages such as:

• M.A.S. • DICE • SIMSII • S.I.S. • GENESIS • MICROKEY

support the MLR2-E Sur-Gard interface. Compatibility with the

automation software in a system used at a central station is

intended to be handled under a separate UL 1981 software

and/or site certification evaluation.

CPM2 OUTPUTS/INPUTS

The CPM2 features three switched-negative outputs. One output

labeled “OPTION” has a corresponding LED on the CPM2

front panel; the factory default programming slowly flashes

the OPTION LED when the “OPTION” output is activated.

Switched negative outputs are also provided for the

Acknowledge and Trouble LEDs.

SYSTEM OVERVIEW

• Patented Caller Identification (Call Display) capability

• Patent Pending DNIS Identification

• Battery backed up RAM on each DRL2E line card

module for programming and event buffers.

• Fast communication between line cards and CPM2

• Flash Upload for software upgrades

• Up to 64 different options set (profiles per line)

• Patent Pending Virtual configurations

• 3/1, 4/2 formats with or without parity, 4/1 without parity

at 10, 14, 20, or 40 Baud

• 4/1, 4/2, 4/3, and 4/3 with checksum DTMF formats

• Optional* Formats: 3-2, 4/1,4/2 extended

• Contact ID (DTMF) format

• Super Fast or High Speed DTMF format, with or without

parity

• DTMF 4/1 Express format optional*

• DTMF 4/2 Express format

• FBI Super Fast format with or without parity

• RADIONICS Modem II, Modem IIE, Modem IIIa2and

BFSK formats

• SIA format: 110 and 300 Baud, tone and data

acknowledgment

• SK FSK1, FSK2

• Any handshake frequencies by increment of 100 Hz

from 300 Hz to 3400 HZ, Dual Tone, SIA FSK, Modem

IIx, Double Dual Tone and ITI selected by configuration

commands.

• Up to 8 different handshakes per profile with individual

duration control.

• Large, easy to read 2-line, 16-characters-per-line, Liquid

Crystal Display screen

• All modules function individually to help ensure

uninterrupted operation during hardware or software

upgrades

• Inputs on CPM2 for UPS supervisory

• 30 lines maximum per receiver

• 256-event memory buffer on each individual line cards

• Real-time clock

• CPM2 features 16-bit microcontroller

• 1 parallel printer port and 2 serial RS-232 ports

• Programmable serial port configurations

• Programmable System Functions: Computer and printer

• Fast transmission of multiple alarms to the computer

and printer to ensure operator’s quick response

• Continuous verification of the computer-receiver links

with the “heartbeat” function

• Switched-negative outputs on CPM2 (special

applications)

• AC-lost detection and standby battery supervision

• Low battery detection and automatic low battery disconnect

to prevent deep-discharge damage to battery

• Operator Acknowledge option

• Telephone Line Supervision and reporting

*All formats noted as optional are selected using configuration

commands.

firealarmresources.com

VIRTUAL RECEIVER ARCHITECTURE

The most novel feature of the DRL2E is the ability to use the

telephone company information delivered as DNIS (Dialed

Number Information Service) or Caller ID. This allows the

Sur-Gard Format Expert System to handle on the fly each

received call. With this feature, dedicated line pool hardware

is eliminated. Instead, the DNIS or Caller ID information allows

dynamic options that set up virtual line pools to identify security

formats and extend account numbers.

Standard DNIS is supported up to 10 digits. Each dialed

number should be assigned to a virtual receiver. Multiple

Caller ID numbers can be assigned to a single virtual receiver.

Each dialed number would formerly have been a line pool on

conventional line cards.

NUMBER OF LINE CARDS SUPPORTED

The system will support a maximum of 15 line cards concurrently

connected.

APPROVALS

Industry Approvals

The MLR2-E is listed for meeting the following approvals:

•UL 864 Control Units for Fire-Protective Signaling

Systems

•UL 1610 Central Station Burglar Alarm Units

This equipment should be installed in accordance with the

requirements of NFPA72, NFPA70 and UL827.

UL MANUAL MODE

For UL manual mode, each event will activate the internal

buzzer to be acknowledged manually. Each event will also

be sent automatically to the connected printer.

For Central Station applications, the signaling performance of

each DACT (Digital Alarm Communication Transmitter) shall

be manually tracked. Failure to receive a signal from a DACT

over a 24 hour period shall be handled as a trouble signal.

UL REQUIREMENTS

Installation - The product is intended to be installed in

accordance with its installation instructions and the

requirements of the local authority having jurisdiction (AHJ).

For Grade AA and A Central Station Service:

•The polling between the premise radio and the central

station shall be such that a failure of the radio link shall

be annunciated within 200 seconds at the central station.

Programming 006: Option 2 must be on and Option 3 must

be off.

•The radio shall be mounted in an attack-resistant enclosure.

•Simultaneous alarm signals shall be sent over the DACT

line and radio.

•Failure of the premise radio shall be reported over the

DACT line and annunciated at the central station within

200 seconds.

•Failure of the DACT line shall be reported over the radio

and annunciated at the central station within 200 seconds.

•Opening and closing signals must be transmitted over the

radio or the DACT line.

For Grade B central station service and grade A police

station connect with high line security:

•The radio shall be mounted in an attack resistant enclosure.

•The system shall send a check-in signal to the central

station every 24 hours.

•A listed compatible burglar alarm sounding device shall

be used in conjunction with the system.

•Opening and closing signals are not required for Police

station connect service.

For grade C central station service:

•The radio shall be mounted in an attack-resistant enclosure.

•The system shall send a check-in signal to the central

station every 24 hours.

For commercial Fire Installations:

•The one-way radio shall be a secondary communication

line to the DACT.

•Each communication line will supervise the other.

•The DACT shall send a check-in signal to the central

station every 24 hours.

•The Bell +, Bell - terminals on the control panel shall not

power other devices.

firealarmresources.com

MLR2-E BACKPLANE CONNECTION DIAGRAM

CONNECTIONS FOR DML2E LINE CARD EXPANSION

MV3 MV2

P4 P2

R13

R11

R12

P4 P2

R13

R11

R12

P4 P2

R13

R11

R12

MODULE

MV3 MV2

P4 P2

R13

R11

R12

Battery

12V Rechargeable

lead-acid

35Ah

Transformer

16 V

, 175 VA

firealarmresources.com

MLR2-E UPS CONNECTION DIAGRAM

MV3 MV2

P4 P2

R13

R11

R12

Battery

12V Rechargeable

lead-acid

35Ah

Transformer

16 VAC, 175 VA

110 VAC/16 VAC, 60 Hz, 175VA

TRANSFORMER

firealarmresources.com

QUICK START

Receiver Setup and Operation Without

Programming

UNPACKING

Carefully unpack the receiver and inspect for shipping damage.

If there is any apparent damage, notify the carrier immediately.

BENCH TESTING

It is suggested that the receiver be tested before actual

installation; becoming familiar with the connections and setup

of the unit on the workbench will make final installation more

straightforward.

The following items are required:

•16VAC, 175VA Transformer

•2 telephone lines

•One or more dialers or digital dialer control panels

Dialers and control panels using an optocoupler phone line

interface will require a connection method providing a DC

current for direct connection testing.

POWER UP

When power is applied, the receiver will beep and will indicate

any trouble conditions on the LCD message screen. If the

Line Cards do not have telephone lines connected, the DRL2E

modules will beep and their “Line Fault”LEDs will FLASH.

Press the flashing [ACK] button to silence the buzzer. If there

is no computer or printer connected, a trouble message will

be displayed on the CPM2 LCD and the “ACK”light will

FLASH. Press the [ACK] button to silence the CPM2 buzzer.

OPERATION WITH DEFAULT PROGRAMMING

Without any changes to the factory default programming, the

receiver operates as follows:

•Answers incoming calls on the first ring

•Sends SIA FSK as the first handshake

•Sends 1400 Hz as the second handshake

•Sends double dual tone as the third handshake

•Sends 2300 HZ tone as the fourth handshake

•Sends Modem II tone as the fifth handshake

•Sends ITI, Modem IIE, Modem IIIa2 tone as sixth

handshake

•The following formats can be manually selected:

3/2, 4/1 express, 4/2 extended, 4/2 checksum and 3/1

checksum.

Signals can be displayed on the debug output as they are

received. The signals are then sent to the parallel printer

and computer connected to serial port COM1. The default

event codes described in the “DRL2E Library Decoding

and Event Codes Table”will be used with the Sur-Gard

Automation Communication Protocol to send signals to the

computer, if connected.

If a computer is not connected, press the [ACK] button on

the CPM2 module to silence the buzzer.

DEBUG OUPUT

The debug output is another means of accessing the line

card’s programmed options and diagnostics features. A null

modem cable is required to connect by serial communication.

DEBUG CABLE CONNECTIVITY

Connect the female DB-9 connector to the serial port of a

computer.

DEBUG SOFTWARE SETUP

Using WIN9x, point and click on the “START”button. Access

“Programs”-> “Accessories”-> “HyperTerminal.”Once in

the HyperTerminal window, point and click on “Hypertrm.exe”

icon.

A connection description window should appear. A prompt

should appear on the “Name”category. Type a name. Point

and click on “OK."

A phone number window should appear. Choose the “direct

to”COM port required for connection and point and click

on “OK”.

COM Port properties windows should appear. The configuration

should be :

•Bits per second: 19200

•Data bits: 8

•Parity: None

•Stop bits: 1

•Flow control: None

Point and click on the “OK”button after setting the configuration.

The HyperTerminal window should appear. Press any button.

The debug menu will be displayed.

BUTTON COMMANDS

CCold boot

DThis button will initiate the download of a file to the line

card.

OThis button will enable the user to dump the current

programmed options of the line card or set an option to

a particular value.

VTo view software version information

DOWNLOADING STEPS

Press the “D”button to initiate downloading of the binary file.

The Hyper Terminal will display:

Ready to download.

CCCC

Point and click at “Transfer”on the Hyper Terminal menu and

access the “Send File”category (you also have right-click

access with the mouse). The “Send File”window should appear.

Change the protocol to “X-modem”and place the correct

path and file name of the binary file to be uploaded. Point

and click on the “Send”button and the downloading status

window should appear.

The line card will restart automatically after a successful upload.

firealarmresources.com

INSTALLATION

MOUNTING THE RECEIVER

Install the MLR2-E in a closed 19"/48cm rack or cabinet with

a locking rear access door. Cover all unused spaces with

blank metal plates. The LCD screens on the receiver are

designed to be viewed below eye level. If the unit must be

mounted where the screens are above eye level, angle the

unit downwards to improve visibility. The following items can

be supplied for a complete installation:

Stand-up Unit (61.25"/1.55cm tall up to 30 telephone lines)

Part # MLR2-CL

•Rack

•Door with lock and ventilation

•Blank plates 21"/53cm (2)

•Blank plate 5.25"/13.3cm (3)

•Screws

•Washers

•Clipnuts

•FROST 16V/175VA transformer

•AC Utility Box

•AC Cable Clamps (2)

•8'/2.4m Battery Cables

•3-Gauge conductor AC Cable

NOTE: If 30 telephone lines are not used, cover each un-

used location with a blank plate.

Desk-mount Unit (28"/71cm tall up to 14 telephone lines)

Part # MLR2-CM

•Rack

•Louvered door back plate

•Blank Plate 1.75"]

•Back Plate 7"/17.8cm

•Blank Plates 5.25 (4)

•Screws

•Washers

•Clipnuts

•FROST 16V/175VA

•AC Utility Box

•AC Cable Clamp for 3/8"/1cm cable

•8'/2.4m Battery Cable

•18 gauge 3-conductor AC Cable

NOTE: If 18 telephone lines are not used, cover each unused

location with a blank plate

PRINTER CONNECTIONS

Connect the parallel printer to the MLR2-E printer output port

using a standard parallel printer cable.

For UL Listed applications, the following UL listed printers

can be used with the MLR2-E:

•Sur-Gard CPV-1150

•Sur-Gard CPV DMP-206

•DMP SCS-PTR

IMPORTANT: Do not use a printer cable that has only 1

common ground wire.

COMPUTER CONNECTIONS

Connect the computer to the MLR2-E RS-232 port using a serial

cable to COM1.

IMPORTANT: Do not use a null modem cable.

Receiver RS-232 Computer RS-232 Computer RS-232

25 pin connector 25 pin connector 9pin connector

223

332

775

TELEPHONE LINE CONNECTIONS

With 6-pin modular cables, connect each line module jack

(line 1 or 2) to its corresponding telephone line.

GROUNDING

For maximum resistance to static and electrical noise, the

19"/48cm rack frame should be connected to earth ground

through the AC utility box.

POWER SUPPLY

Ensure that all electrical connections are made correctly. After

verifying all connections, connect the RED and BLACK leads to

a 12VDC sealed rechargeable battery. Be sure to observe polarity

when connecting the battery. When the battery is connected,

test the system under battery power only. CAUTION: Connecting

a positive (+) terminal to a negative (-) terminal may cause a

fire and possibly serious personal harm.

For 4-hour standby a 12-volt 35 Ah rechargeable battery should

be used in conjunction with an engine-driven power generator.

BATTERY CHARGING CURRENT

The maximum battery charging current is factory set at 1A.

DB-25 to DB-25 DB-25 to DB-9

firealarmresources.com

DRL2E DIGITAL RECEIVER

LINE CARD

The DRL2E acts as an interface between the digital alarm

transmitter and the CPM2. Different communication formats

can be used to transmit the information.

The main functions of the line cards are to continuously monitor

the telephone line, receive calls from digital dialers or control

panels, and to report alarms to the CPM2. In addition, if a

Line Card is unable to communicate with the CPM2, then

each Line Card is capable of functioning independently. Each

Line Card can record 256 different alarm messages and 255

Caller-ID telephone numbers.

GENERAL INFORMATION

The receiver is capable of processing signals from digital

communicators in a variety of formats. The type of signal

(alarm, trouble, restore, cancel and so on) can be printed.

DRL2E FEATURES

•Operator selection of communication formats and

handshake priority

•64 profiles per line card, up to 30 line pools.

•Flash Download for software upgrades.

•Records up to 256 messages.

•Records up to 256 Caller ID phone numbers. This

feature helps to locate and identify the source of the

device in communication and assists in troubleshooting.

•Multiple alarms are forwarded to the computer and

printer through the CPM2 with minimum delay

•The DRL2E monitors the telephone line connection,

and line faults will result in reports to the computer

and the printer

•DRL2E automatically goes into standalone mode in case

of CPM2 failure

•“Watchdog”timer continually monitors receiver operation

•“Cold boot”option allows receiver’s configuration to be

reset to factory default programming

•DSP processing to reduce data receiving errors, and to

help for weak and noisy signals

•Gain boost available to amplify weak signals

•Serial link for troubleshooting and easy software

upgrade

INSTALLATION

Check the configuration information listed in the Quick Reference

Guide to make any required changes for your particular

application.

DRL2E CONTROLS

Each DRL2E Module features 2 line cards. The LEDs and

push buttons on the left side and the upper LCD are for Line

Card 1. The LEDs and push buttons on the right side and the

lower LCD are for Line Card 2.

Momentarily depressing and releasing a button will register

as a single input or keystroke. Pressing and holding a button

for approximately 1 second will register as a repeating input

or keystroke. For example, to quickly scroll through a list of

items, you press and hold the appropriate button, rather than

pressing the button repeatedly.

LCD (Liquid Crystal Display)

Displays incoming data, programming and other information.

The display is backlit for visibility in low light environments.

AUDIO

The “Audio”light comes ON when the receiver is in Audio

Mode. When ON, “listen-in”or “2-Way Audio”is in use. The

“Audio”light will automatically turn OFF at the end of the

timed period or when the [CANCEL] button is pressed.

LINE FAULT

The “Line Fault”light will come ON if the telephone line is

disconnected. The “Line Fault”light will turn OFF automatically

when the telephone line is restored.

MESSAGE ERROR

The “Message Error”light will come ON when faulty data is

received (for example, if the round pair does not match, or if the

checksum is incorrect). Press the [ACK] button to acknowledge

the error; the “Message Error”light will be shut OFF.

[ACK/FUNCTION] BUTTON

Press this button to acknowledge an alarm in emergency

manual mode. In the normal mode, press this button to access

the Line Card Menu.

ALARM

The “Alarm”light is located inside the [ACK/FUNCTION] button.

The “Alarm”light will flash if an alarm is received. The “Alarm”

light will be shut OFF when the alarm is successfully

communicated to the CPM2, or when the operator acknowledges

the alarm by pressing the [ACK/FUNCTION] button.

CANCEL SELECT

While on-line, press this button to drop the line. In normal

mode, press this button to select the current item.

WATCHDOG

The "Watchdog" light will FLASH once every 4 seconds to

incicate that Line Card operation is being monitored.

firealarmresources.com

DRL2E Operating Mode

DRL2E STANDBY MODE

With the Line Card installed, apply power to the unit. This

message will be displayed briefly on the top LCD:

INITIALIZING

CONTRAST LOADING

Next, the following message will be displayed on each line

card in turn, starting with line card 1:

PRESS ACK+SELECT

TO COLDBOOT

The cold booting procedure is covered in detail below.

The LCDs will then display:

INITIALIZING

CONTRAST LOADING

During this time, the line cards will load default options and

code, and perform a low-level diagnostic to determine the

status of the system.

Once the line cards are ready, they will display a message

similar to the following:

DRL2E-Line #D

<<-Line Fault->>

After these startup messages, the line card monitors the

telephone line and the CPM2.

LINE FAULT

The DRL2E verifies the telephone line voltage every 10 seconds.

The “Line Fault”light will come ON after two successive line

verifications indicate irregular telephone line voltage. This

message will be displayed:

DRL2E-Line #D

<<-Line Fault->>

If the Line Check option is enabled, the following information

will be transmitted to the printer and computer:

Printer: L01- 0000-PHONE-LINE-TROUBLETIME:DATE

(printer option set to 03)

Computer: 0RRL[#0000 | NLTRRLL]

NOTE: The first RRL is subject to the line card length

option.The second RRL is the receiver and line card number,

both in HEX.

If the Line Check option is disabled, the DRL2E will not send

the report to the printer or computer. Refer to “DRL2E

Programmable Features”for information on enabling the Line

Check option.

When the line condition returns to normal, the “Line Fault”

LED will be shut OFF.

If the Line Check option is enabled and the telephone line

returns to normal, the following information will be transmitted

to the printer and computer:

Printer: L01- 0000-PHONE-LINE-RESTORALTIME:DATE

Computer: 0RRL[#0000 | NLRRRLL]

NOTE: The first RRL is subject to the line card length

option. The second RRLL is the receiver and line

card number, both in HEX.

CPM2 ERROR; DISPLAY ALARM MESSAGES

If the DRL2E cannot detect CPM2 polling and there are no

alarm events in the event buffer, this message will be displayed:

DRL2E Line #D

<<-CPM ERROR->>

If alarm messages cannot be sent to the CPM2 because of

the error, the DRL2E will display the oldest message which

has not been manually acknowledged. The “Alarm”light will

FLASH and the sounder will beep if the “Mute Buzzer”Option

is programmed as [00], [02] or [03].

When a CPM2 Error is present, each alarm must be manually

acknowledged. Press the [ACK/FUNCTION] button to acknowledge

the alarm and silence the Line Card sounder. If several alarms

have been received but cannot be sent to the CPM2, they will

have to be individually acknowledged; when all alarms are

acknowledged, the Line Card sounder will be silenced.

Up to 128 alarm messages for the printer and computer will be

retained in the CPM2 event buffer. When the event buffer is full,

the oldest messages will be deleted as new events are recorded.

When the CPM2 Error condition is corrected, the alarm

messages in the event buffer will be transmitted to the CPM2.

KEEP LAST ALARM MESSAGE

The DRL2E may be programmed to leave the last alarm

message on the display screen until a new message is received.

A typical alarm message is shown below:

0000 PHONE LINE

TROUBLE 28

“0000”is the “internal”account code.

“28”is the event’s location in the event buffer.

STANDBY MODE

When the Line Card is operating normally, this message will

be displayed:

DRL2E Line #D

Unit in Standby

LINE CARD MENU MODE

When the unit is not on line, pressing the [ACK/FUNCTION]

button will display the first Function Menu:

PRINTER BUFFER

ACK:menu SEL:sel

Press the [ACK] button to scroll through the menu items. Press

the [SELECT] button to select the function displayed on the

LCD screen. When a function is selected, press [ACK] and

[SELECT] together to exit from the Menu Mode. The DRL2E

will automatically exit from the Menu Mode if no keys are pressed

for 30 seconds.

firealarmresources.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sur-Gard Récepteur

Sur-Gard

Sur-Gard SG-System III Manuel utilisateur

Sur-Gard

Sur-Gard MLR2E Manuel utilisateur

Sur-Gard

Sur-Gard MLR2000 Manuel utilisateur

Sur-Gard

Sur-Gard SG-MLR2000 Manuel utilisateur

Sur-Gard

Sur-Gard System Five Manuel utilisateur

Sur-Gard

Sur-Gard System I Manuel utilisateur

Sur-Gard

Sur-Gard System III Manuel utilisateur

Sur-Gard

Sur-Gard SG Security Communications MLR2-DG Manuel utilisateur

Sur-Gard

Sur-Gard SG-System IV Manuel utilisateur

Sur-Gard

Sur-Gard SG System II Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
