Table of Contents
i Dear Customer,.................................2
1. General view .....................................4
2. Included in delivery........................6
3. Explanation of the safety
symbols used....................................7
4. Safety instructions ..........................8
4.1 Intended use...................... 10
4.2 Improper use ..................... 11
5. Functional description ............... 12
5.1 Description of the safety
functions ............................. 12
6. Safety instructions for the
installation ...................................... 14
6.1 You will require the
following tools .................. 14
7. Flush mounting............................. 15
8. Surface mounting ........................ 24
9. Check the rotational direction. 32
10. Setting the end points................ 33
11. Manual operation......................... 35
12. Automatic mode; conguring the
opening and closing times ....... 36
13. Automatic mode;
Auto / Manual switchover......... 38
14. Automatic solar function........... 39
14.1 Switch the automatic solar
function on/o.................. 40
14.2 Automatic solar function;
set limit ................................ 41
15. Erase settings................................. 42
16. Removing the ush-mounted
belt winder (e.g. in the event
of a move) ....................................... 43
17. Flush-mounted belt winder,
remove the belt in the event of
unit failure....................................... 44
18. Removing the surface-mounted
belt winder (e.g. in the event
of a move) ....................................... 45
19. Surface-mounted belt winder,
remove the belt in the event of
unit failure....................................... 46
20. What to do if... ?............................. 47
21. Information about maintenance
and care of your equipment..... 49
22. Technical Specications............. 50
22.1 Dimensions ush-mounted
device................................... 51
22.2 Dimensions surface-
mounted device ............... 52
23. CE Mark and EC Declaration of
Conformity...................................... 53
24. Warranty conditions.................... 54
