Supero SUPERSERVER 6015W-Ni Manuel utilisateur

SUPERSERVER 6015W-Ni

SUPER

USER’S MANUAL

1.0

Manual Revision 1.0

Release Date: March 11, 2008

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

SUPER MICRO COMPUTER reserves the right to make changes to the product described in this

manual at any time and without notice. This product, including software, if any, and documenta-

tion may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any

medium or machine without prior written consent.

IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE

OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO SHALL NOT HAVE

LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE

PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING

OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the SuperServer 6015W-Ni. In-

stallation and maintenance should be performed by experienced technicians only.

Manual Organization

Chapter 1: Introduction

The ﬁrst chapter provides a checklist of the main components included with the

server system and describes the main features of the SUPER X7DWU serverboard

and the SC812L-520U chassis, which make up the SuperServer 6015W-Ni.

Chapter 2: Server Installation

This chapter describes the steps necessary to install the SuperServer 6015W-Ni

into a rack and check out the server conﬁguration prior to powering up the system.

If your server was ordered without processor and memory components, this chapter

will refer you to the appropriate sections of the manual for their installation.

Chapter 3: System Interface

Refer here for details on the system interface, which includes the functions and

information provided by the control panel on the chassis as well as other LEDs

located throughout the system.

Chapter 4: System Safety

You should thoroughly familiarize yourself with this chapter for a general overview

of safety precautions that should be followed when installing and servicing the

SuperServer 6015W-Ni.

iii

Preface

SUPERSERVER 6015W-Ni Manual

Chapter 5: Advanced Serverboard Setup

Chapter 5 provides detailed information on the X7DWU serverboard, including the

locations and functions of connectors, headers and jumpers. Refer to this chapter

when adding or removing processors or main memory and when reconﬁguring the

serverboard.

Chapter 6: Advanced Chassis Setup

Refer to Chapter 6 for detailed information on the 1U SC812L-520U rackmount

server chassis. You should follow the procedures given in this chapter when install-

ing, removing or reconﬁguring peripheral drives and when replacing the system

power supply unit and cooling fans.

Chapter 7: BIOS

The BIOS chapter includes an introduction to BIOS and provides detailed informa-

tion on running the CMOS Setup Utility.

Appendix A: BIOS POST Messages

Appendix B: BIOS POST Codes

Appendix C: System Speciﬁcations

Preface

Notes

SUPERSERVER 6015W-Ni Manual

Table of Contents

Chapter 1 Introduction

1-1 Overview ......................................................................................................... 1-1

1-2 Serverboard Features ..................................................................................... 1-2

Processors ...................................................................................................... 1-2

Memory ........................................................................................................... 1-2

UIO ................................................................................................................. 1-2

Serial ATA........................................................................................................ 1-2

Onboard Controllers/Ports .............................................................................. 1-2

1-3 Server Chassis Features ................................................................................ 1-4

System Power ................................................................................................. 1-4

Control Panel .................................................................................................. 1-4

I/O Backplane.................................................................................................. 1-4

Cooling System ............................................................................................... 1-4

1-4 Contacting Supermicro.................................................................................... 1-5

Chapter 2 Server Installation

2-1 Overview ......................................................................................................... 2-1

2-2 Unpacking the System .................................................................................... 2-1

2-3 Preparing for Setup......................................................................................... 2-1

Choosing a Setup Location............................................................................. 2-1

Rack Precautions ............................................................................................ 2-2

Server Precautions.......................................................................................... 2-2

Rack Mounting Considerations ....................................................................... 2-3

Ambient Operating Temperature ................................................................ 2-3

Reduced Airﬂow ......................................................................................... 2-3

Mechanical Loading ................................................................................... 2-3

Circuit Overloading..................................................................................... 2-3

Reliable Ground ......................................................................................... 2-3

2-4 Installing the System into a Rack ................................................................... 2-4

Identifying the Sections of the Rack Rails...................................................... 2-4

Installing the Chassis Rails............................................................................. 2-5

Installing the Rack Rails ................................................................................. 2-5

Installing the Server into the Rack.................................................................. 2-6

Installing the Server into a Telco Rack ........................................................... 2-7

2-5 Checking the Serverboard Setup.................................................................... 2-8

2-6 Checking the Drive Bay Setup........................................................................ 2-9

vii

Table of Contents

Chapter 3 System Interface

3-1 Overview ......................................................................................................... 3-1

3-2 Control Panel Buttons ..................................................................................... 3-1

Reset............................................................................................................... 3-1

Power .............................................................................................................. 3-1

UID .................................................................................................................. 3-1

3-3 Control Panel LEDs ........................................................................................ 3-2

Universal Information LED .............................................................................. 3-2

NIC2 ................................................................................................................ 3-3

NIC1 ................................................................................................................ 3-3

HDD................................................................................................................. 3-3

Power .............................................................................................................. 3-3

Chapter 4 System Safety

4-1 Electrical Safety Precautions .......................................................................... 4-1

4-2 General Safety Precautions ............................................................................ 4-2

4-3 ESD Precautions............................................................................................. 4-3

4-4 Operating Precautions .................................................................................... 4-4

Chapter 5 Advanced Serverboard Setup

5-1 Handling the Serverboard ............................................................................... 5-1

Precautions ..................................................................................................... 5-1

Unpacking ....................................................................................................... 5-1

5-2 Processor and Heatsink Installation ............................................................... 5-2

5-3 Connecting Cables.......................................................................................... 5-5

Connecting Data Cables ................................................................................. 5-5

Connecting Power Cables .............................................................................. 5-5

Connecting the Control Panel......................................................................... 5-5

5-4 I/O Ports .......................................................................................................... 5-6

5-5 Installing Memory ............................................................................................ 5-7

5-6 PCI Expansion Cards...................................................................................... 5-9

5-7 Serverboard Details ...................................................................................... 5-10

X7DWU Quick Reference ..............................................................................5-11

5-8 Connector Deﬁnitions.................................................................................... 5-12

5-9 Jumper Settings ............................................................................................ 5-19

5-10 Onboard Indicators........................................................................................ 5-21

5-11 Floppy, IDE and SATA Drive Connections .................................................... 5-22

5-12 Installing Software......................................................................................... 5-24

Supero Doctor III........................................................................................... 5-25

SUPERSERVER 6015W-Ni Manual

viii

Chapter 6 Advanced Chassis Setup

6-1 Static-Sensitive Devices.................................................................................. 6-1

Precautions ..................................................................................................... 6-1

6-2 Control Panel .................................................................................................. 6-2

6-3 System Fans ................................................................................................... 6-2

System Fan Failure......................................................................................... 6-3

6-4 Drive Bay Installation/Removal ....................................................................... 6-4

Accessing the Drive Bays ............................................................................... 6-4

6-5 Power Supply .................................................................................................. 6-6

Power Supply Failure...................................................................................... 6-6

Chapter 7 BIOS

7-1 Introduction...................................................................................................... 7-1

7-2 Running Setup ................................................................................................ 7-2

7-3 Main BIOS Setup ............................................................................................ 7-2

7-4 Advanced Setup.............................................................................................. 7-7

7-5 Security ......................................................................................................... 7-23

7-6 TPM State ..................................................................................................... 7-24

7-7 Boot............................................................................................................... 7-25

7-8 Exit ................................................................................................................ 7-26

Appendix A BIOS POST Messages

Appendix B BIOS POST Codes

Appendix C System Speciﬁcations

Chapter 1

Introduction

1-1 Overview

Supermicro's SuperServer 6015W-Ni is an economic, dual processor 1U rackmount

server. The SuperServer 6015W-Ni is comprised of two main subsystems: the

SC812L-520U 1U rackmount chassis and the X7DWU dual processor serverboard.

Please refer to our web site for information on operating systems that have been

certiﬁed for use with the SuperServer 6015W-Ni. (www.supermicro.com)

In addition to the mainboard and chassis, various hardware components may have

been included with your SuperServer 6015W-Ni, as listed below:

 Two (2) CPU heatsinks (SNK-P0017)

 Two (2) 10-cm blower fans (FAN-0059L4)

 One (1) air shroud (MCP-310-00008-01)

 Two (2) riser cards (RSC-R1UU-2E8 and RSC-R1UU-E8R+)

 SATA Accessories:

One (1) 48-cm SATA cable (CBL-0206L)

One (1) 59-cm SATA cable (CBL-0207L)

One (1) 70-cm SATA cable (CBL-0208L)

 Rackmount hardware with screws (CSE-PT34)

Two (2) rack rail assemblies

Six (6) brackets for mounting the rack rails to a rack/telco rack

 One (1) CD-ROM containing drivers and utilities:

 SuperServer 6015W-Ni User's Manual

Chapter 1: Introduction

1-1

SUPERSERVER 6015W-Ni Manual

1-2

1-2 Serverboard Features

At the heart of the SuperServer 6015W-Ni lies the X7DWU, a dual processor

serverboard based on Intel's 5400 chipset. Below are the main features of the

X7DWU (see Figure 1-1 for a block diagram of the chipset).

Processors

The X7DWU supports single or dual 771-pin Intel Xeon 5400/5300LV/5200/5100LV

series processors at a FSB speed of 1600/1333/1066 MHz. Please refer to the

serverboard description pages on our web site for a complete listing of supported

processors.

Memory

The X7DWU has eight 240-pin DIMM sockets that can support up to 64 GB of

ECC FBD (Fully Buffered DIMM) DDR2-800 (fully supported with 1600 MHz CPUs

only), DDR2-667 or DDR2-533 SDRAM. The memory is an interleaved conﬁgura-

tion, which requires modules of the same size and speed to be installed in pairs.

Please refer to Chapter 5 for memory speed jumper settings.

UIO

The X7DWU is a specially-designed serverboard that features Supermicro's UIO

(Universal I/O) technology. UIO serverboards have a PCI-Express x8 connector that

can support any one of several types of UIO card types to add SAS ports, additional

LAN ports, etc. to the serverboard. This allows the user to tailor the serverboard

to their own needs.

Serial ATA

An on-chip (ESB2) SATA controller is integrated into the X7DWU to provide a six-

port, 3 Gb/sec Serial ATA subsystem, which is RAID 0, 1 and 10 supported (RAID 5

also supported with Windows OS). The SATA drives are hot-swappable units. Note:

The operating system you use must have RAID support to enable the hot-swap

capability and RAID function of the Serial ATA drives.

Onboard Controllers/Ports

One ﬂoppy drive controller and one onboard ATA/100 controller are provided to

support up to two IDE hard drives or ATAPI devices. The color-coded I/O ports

include one COM port, a VGA (monitor) port, two USB 2.0 ports, PS/2 mouse and

keyboard ports and two gigabit Ethernet ports.
