Chapter 1

Introduction

1-1 Overview

The A+ Server 2021TM-BTRF/BIBXRF is a high-end server comprised of two main

subsystems: the SC827 2U server chassis and the H8DMT-F/H8DMT-IBXF dual

processor serverboard. Please refer to our web site for information on operating

systems that have been certiﬁed for use with the system (www.supermicro.com).

In addition to the serverboard and chassis, various hardware components have

been included with the 2021TM-BTRF/BIBXRF, as listed below:

Eight passive CPU heatsinks (SNK-P0022+)•

Four 8-cm chassis fans (FAN-0111L4)•

Four air shrouds (MCP-310-82703-0B)•

Four riser cards (RSC-R1U-E16R-O-P)•

SATA Accessories•

One SATA backplane (BPN-SAS-827B)

Four 16-pin to 16-pin front control cable (CBL-0151L)

Four sets of SATA cables (CBL-0317L)

Four 4-pin fan cables (CBL-0320L)

Four 4-pin to 4-pin I2C cables (CBL-0323L)

Twelve 3.5" hot-swappable drive carriers (MCP-220-00024-0B)

One rackmount kit (MCP-290-00053-0N)•

One CD containing manual, drivers and utilities•

Chapter 1: Introduction

1-1

1-2

A+ SERVER 2021TM-BTRF/BIBXRF User's Manual

1-2 Serverboard Features

At the heart of the A+ Server 2021TM-BTRF/BIBXRF lies the H8DMT-F/H8DMT-

IBXF, a dual processor serverboard based on the nVidia MCP55 Pro Chipset and

designed to provide maximum performance. Up to four of these serverboards can

be mounted in the SC827 chassis. The 2021TM-BTRF server contains the H8DMT-F

serverboard, while the 2021TM-BIBXRF contains the H8DMT-IBXF serverboard.

The difference between the H8DMT-F and H8DMT-IBXF serverboards are the

availability of InﬁniBand components. Refer to the table below for details.

Serverboard Full IPMI Capability InﬁniBand

Components

H8DMT-F X

H8DMT-IBXF X X

The sections below cover the main features of the H8DMT-F/H8DMT-IBXF

serverboards (see Figure 1-1 for a block diagram of the chipset).

Processors

The H8DMT-F/H8DMT-IBXF supports single or dual AMD Opteron 2000 series

processors (Socket F type). Please refer to the serverboard description pages on our

web site for a complete listing of supported processors (www.supermicro.com).

Memory

The H8DMT-F/H8DMT-IBXF has eight 240-pin DIMM slots that can support up to

64 GB of DDR2-800/667/533 registered ECC SDRAM. The memory operates in an

interleaved conﬁguration and requires modules of the same size and speed to be

installed two at a time. See Chapter 5 for details.

Serial ATA

A Serial ATA controller is integrated into the nVidia MCP55 Pro Chipset to provide

a four-port 3 Gb/s SATA subsystem, which is RAID 0, 1, 5 and JBOD supported.

The SATA drives are hot-swappable units.

Note: The operating system you use must have RAID support to enable the hot-

swap capability and RAID function of the SATA drives.

PCI Expansion Slots

The H8DMT-F/H8DMT-IBXF has one PCI Express x16 expansion slot.

1-3

Chapter 1: Introduction

Onboard Controllers/Ports

One Fast UART 16550 compatible serial port and a Mellanox Connect-X MT25408

20Gb/s InﬁniBand controller are located on the serverboard. The color-coded

I/O ports include one COM port (an additional COM header is located on the

serverboard), a VGA (monitor) port, two USB 2.0 ports (additional 2+2 internal USB

headers are included on the serverboard) and two gigabit Ethernet ports.

Graphics Controller

The H8DMT-F/H8DMT-IBXF features an integrated Windbond WPCM450 BMC

graphics controller.

Other Features

Other onboard features that promote system health include onboard voltage

monitors, a chassis intrusion header, auto-switching voltage regulators, chassis and

CPU overheat sensors, virus protection and BIOS rescue.

1-3 Server Chassis Features

The following is a general outline of the main features of the SC827 server

chassis.

System Power

Each SC827 chassis model includes a high-efﬁciency 80 Plus Gold certiﬁed power

supply, rated at 1200 Watts plus one redundant backup power supply. In the unlikely

event your power supply fails, replacement is simple and can be accomplished

without tools.

SATA Subsystem

The SC827 supports up to twelve 3.5" hot-swap SATA drives in trays (3 for each

node). These drives are hot-swappable units and are connected to a backplane

that provides power and control.

Note: The operating system you use must have RAID support to enable the hot-

swap capability of the drives.

1-4

A+ SERVER 2021TM-BTRF/BIBXRF User's Manual

Front Control Panel

SC827 models include four front panels on the handles of the chassis which control

each of the systems. Each control panel on the A+ Server 2021TM-BTRF/BIBXRF

provides you with system monitoring and control for one server node. LEDs indicate

system power, HDD activity, network activity, system overheat and power supply

failure. A main power button and a system reset button are also included.

I/O Backplane

The SC827 is an ATX form factor chassis designed to be used in a 2U rackmount

conﬁguration. The SAS827B I/O backplane provides a low-proﬁle add-on card

slot, a COM port, a VGA port, two USB 2.0 ports and two gigabit Ethernet ports

per node.

For more information regarding the backplane, view the appendices found at the

end of this manual.

Cooling System

The SC827 chassis accepts four system fans powered from either backpane or the

serverboards. If not powered from the backpane, the SC827B model chassis powers

two fans from two motherboards, so that when one of the motherboard drawers is

removed, the second motherboard will continue running both fans.

Air Shrouds

The SC827 chassis includes four mylar air shrouds that direct the airﬂow where

cooling is needed on each serverboard. Always use the air shroud included with

your chassis on each serverboard.

Mounting Rails

The SC827 includes a set of quick-release rails, and can be placed in a rack for

secure storage and use. To setup your rack, follow the step-by-step instructions

included in this manual.

1-5

Chapter 1: Introduction

Figure 1-1. nVidia MCP55 Pro Chipset:

System Block Diagram

Note: This is a general block diagram. Please see Chapter 5 for details.

COM

AMD

Socket F AMD

Socket F

RDIMM

MCP55 PRO S

PCI-E Slot

PCI x16

IB MT25408

PCI x8

WPCM450

INTEL 82575

PCI x4

Gigabit LAN

Gigabit LAN RTL8201N

6x USB

USB

4x SATA

SATA

RMII

PCI LPC

DDR

W83793AG 4x Fan

W83627DHG

BIOS

COM

1-6

A+ SERVER 2021TM-BTRF/BIBXRF User's Manual

1-4 Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Asia-Paciﬁc

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3991

Web Site: www.supermicro.com.tw

Technical Support:

Email: [email protected]

Tel: 886-2-8228-1366, ext.132 or 139

1-7

Chapter 1: Introduction

1-5 2U Twin2: System Notes

As a 2U Twin2conﬁguration, the 2021TM-BTRF/BIBXRF is a unique server system.

With four system boards incorporated into a single chassis acting as four separate

nodes, there are several points you should keep in mind.

Nodes

Each of the four serverboards act as a separate node in the system.As independant

nodes, each may be powered off and on without affecting the others. In addition,

each node is a hot-swappable unit that may be removed from the rear of the chassis.

The nodes are connected to the server backplane by means of an adapter card.

Note: a guide pin is located between the upper and lower nodes on the inner chassis

wall. This guide pin also acts as a “stop” when a node is fully installed. If too much

force is used when inserting a node this pin may break off. Take care to slowly slide

a node in until you hear the “click” of the locking tab seating itself.

System Power

Asingle 1200W power supply is used to provide the power for all four serverboards.

Each serverboard however, can be shut down independently of the other with the

power button on its own control panel. As an option, you may add an additional

1200W power supply module for power redundancy.

SATA Backplane/Drives

As a system, the 2021TM-BTRF/BIBXRF supports the use of twelve SATA drives.

A single SATA backplane works to apply system-based control for power and fan

speed functions, yet at the same time logically connects a set of three SATA drives

to each serverboard. Consequently, RAID setup is limited to a three-drive scheme

(RAID cannot be spread across all twelve drives). See the Drive Bay Installation/

Removal section in Chapter 6 for the logical hard drive and node conﬁguration.

1-8

A+ SERVER 2021TM-BTRF/BIBXRF User's Manual

Notes

Chapter 2: Server Installation

2-1

Chapter 2

Server Installation

2-1 Overview

This chapter provides a quick setup checklist to get your A+ Server 2021TM-BTRF/

BIBXRF up and running. Following these steps in the order given should enable

you to have the system operational within a minimum amount of time. This quick

setup assumes that your system has come to you with the processors and memory

preinstalled. If your system is not already fully integrated with a serverboard,

processors, system memory etc., please turn to the chapter or section noted in

each step for details on installing speciﬁc components.

2-2 Unpacking the System

You should inspect the box the A+ Server 2021TM-BTRF/BIBXRF was shipped in

and note if it was damaged in any way. If the server itself shows damage you should

ﬁle a damage claim with the carrier who delivered it.

Decide on a suitable location for the rack unit that will hold the A+ Server 2021TM-

BTRF/BIBXRF. It should be situated in a clean, dust-free area that is well ventilated.

Avoid areas where heat, electrical noise and electromagnetic ﬁelds are generated.

You will also need it placed near a grounded power outlet. Read the Rack and

Server Precautions in the next section.

2-3 Preparing for Setup

The box the A+ Server 2021TM-BTRF/BIBXRF was shipped in should include two

sets of rail assemblies, two rail mounting brackets and the mounting screws you

will need to install the system into the rack. Follow the steps in the order given to

complete the installation process in a minimum amount of time. Please read this

section in its entirety before you begin the installation procedure outlined in the

sections that follow.

Choosing a Setup Location

Leave enough clearance in front of the rack to enable you to open the front door•

completely (~25 inches) and approximately 30 inches of clearance in the back

of the rack to allow for sufﬁcient airﬂow and ease in servicing.

2-2

A+ SERVER 2021TM-BTRF/BIBXRF User's Manual

This product is for installation only in a Restricted Access Location (dedicated•

equipment rooms, service closets and the like).

This product is not suitable for use with visual display work place devices•

acccording to §2 of the the German Ordinance for Work with Visual Display

Units.

Warnings and Precautions!

Rack Precautions

Ensure that the leveling jacks on the bottom of the rack are fully extended to•

the ﬂoor with the full weight of the rack resting on them.

In single rack installation, stabilizers should be attached to the rack. In multiple•

rack installations, the racks should be coupled together.

Always make sure the rack is stable before extending a component from the•

rack.

You should extend only one component at a time - extending two or more si-•

multaneously may cause the rack to become unstable.

Server Precautions

Review the electrical and general safety precautions in Chapter 4.•

Determine the placement of each component in the rack• before you install the

rails.

Install the heaviest server components on the bottom of the rack ﬁrst, and then•

work up.

Use a regulating uninterruptible power supply (UPS) to protect the server from•

power surges, voltage spikes and to keep your system operating in case of a

power failure.

Allow any hot plug drives and power supply modules to cool before touching•

them.

Always keep the rack's front door and all panels and components on the servers•

closed when not servicing to maintain proper cooling.

Ce manuel convient aux modèles suivants

Autres manuels Supermicro Serveur

Supermicro

Supermicro SuperStorage SSG-6029P-E1CR24H Manuel utilisateur

Supermicro

Supermicro SuperServer 120GQ-TNRT Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-511R-M Manuel utilisateur

Supermicro

Supermicro Supero SUPERSERVER 2027PR-DC1R Manuel utilisateur

Supermicro

Supermicro SuperServer SSG-640SP-DE2CR90 Manuel utilisateur

Supermicro

Supermicro SuperServer 1029U-TN12RV-NEBS Manuel utilisateur

Supermicro

Supermicro 7043P-8R Manuel utilisateur

Supermicro

Supermicro SuperStorage 6029P-E1CR16T Manuel utilisateur

Supermicro

Supermicro Supero A+ SERVER 1042G-TF Manuel utilisateur

Supermicro

Supermicro AS -1014S-WTRT Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-620H-TN12R Manuel utilisateur

Supermicro

Supermicro SuperServer 1029U-T Series Manuel utilisateur

Supermicro

Supermicro SuperServer 4027GR-TR Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-121H-TNR Manuel utilisateur

Supermicro

Supermicro X13SAE Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-111C-NR Manuel utilisateur

Supermicro

Supermicro SuperServer 1019S-MC0T Manuel utilisateur

Supermicro

Supermicro SUPERSERVER 1028UX-TR4 Manuel utilisateur

Supermicro

Supermicro SUPERSERVER 6015P-8(R) Manuel utilisateur

Supermicro

Supermicro SuperServer E300-8D Manuel utilisateur

Supermicro

Supermicro SuperServer SYS-2029U-E Series Manuel utilisateur

Supermicro

Supermicro SUPERSERVER 6028TP-HC0R Manuel utilisateur

Supermicro

Supermicro SuperServer 5019C-MHN2 Manuel utilisateur

Supermicro

Supermicro SUPERSERVER 2048U-RTR4 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
