Superabrasive LAVINA Manuel utilisateur
-·
•••
□
I
e
Grinder is equipped with a Camlock fitting:
2.5" E250 on 25" machines
If working dry, connect a vacuum.
3" E300 on 30" machines
CONNECTING
A VACUUM
WATER
SYSTEM
TOOL
MOUNTING
1. Choose water source - tank or hose.
2. Adjust water flow.
Grinder is equipped with a two-way water tap.
1
2
Use the tool holder key /1 / to rotate the
key lock / 3 / in order to unlock and remove
back as shown, and rotate the key lock to
lock the security plate.
trapezoid slots, put the security plate
Place the QuickChange tools into the
security plate / 2/.
1
2
water tank
hose
3
11. Forward / Reverse
12. Run / Stop
3. Reset Alarms
6. USB Port
7. Hour Meter
1. Power Indicator
8. Power Plug
9. Emergency Stop Button
5. Tachometer (tool holder rpm)
4. Lights on/off
10. Potentiometer
2. Ready on/off
CONTROL
BOARD
STARTING
MACHINE
67
4
3
8
5
2
1
9
10
11
12
- the power indicator must glow in green. 1
Plug the machine into power supply 8
Turn the “Ready ON/OFF” switch to ON to power the control board. 2
Use the “Run / Stop” switch to run the machine. 12
STOPPING
MACHINE
Use the “Run / Stop” switch 12
or the Emergency Stop button to stop the machine. 9
In case of emergency, always press the Emergency Stop button.
8
9
12
2
1
12
