Suntek HC-910Pro Manuel utilisateur
Model:HC-900Plus
APP&Cloud Service
30MP 2
H.265
Model:HC-900Plus
APP&Cloud Service
30MP 2
H.265
Model:HC-910Pro
Live video & APP
Videorecording
SPECIFICATIONS
Photo recording
Photo resolution
File format
Time lapse mode
Multi-shot mode
Stamp
Capture mode
30 /24 / 20 / 16 / 12 / 8 / 5 / 3 MP
.JPG
5 / 30min , 1 / 2 / 3 / 6 / 12 / 24hour
Up to 9 photos per detection
Date, time, temperature (℃/℉)and
moon phase
Camera /Video /Camera&Video /
Time-lapse
Videoresolution
File format
Video length
Capturemode
4K / 2K / 1080P / 720P / VGA
.MP4 / H.265
5s /10s / 30s / 60s / 90s
Colorful mode at daytime,
black and white mode at night
Memory storage
Support Internalmemory:none
External memory: Micro SD card
(up to 256GB, Not included)
- 01 -
Cellular/Wireless Transmission
Instantly record in the Cloud and APP
Video
Live Video
APP control to check video or record
Instantly record in the Cloud and APP
Power source
Dimensions
Waterproof level
Viewing
Built-in screen TFT 2.0”
Alkaline Battery
External Power Jack
1.5V AA Battery*8
DC 12V/1A(3.5x1.3mm)
Detection system
Motion Sensor
Detection Angle
Detection Range
Trigger Speed
Delay between each detection
1x PIR
90°
Adjustable from 1 to 98 Ft
0.2second
1/10 seconds, 1/3/5/10/15/30 minutes
Night time illumination system
Infrat LEDs
Flash Range
Exposure
＜98 Ft
Auto / 100 / 200 / 400
Optical field of view
120°
155mm x 84mm x 65mm
Recommendations
Operating temperature (-4℉to + 158℉) (-20℃to + 70℃)
IP 66
- 02 -
No-glow lR led
THE BASICS
- 03 -
Antenna
Photosensitive
Lens
LED Indicator
INSTALLATION
- 04 -
Step 1
Open the battery cover and
insert 8 batteries (AA)
following to the positive and
the negative battery sign
01
02
Close the battery cover to
resist water and dust.
03
- 05 -
Step 3
Insert the sim card into the card slot after sim card is inserted
turn on and check the letf side of the screen.
Step 2
Insert Micro SD(Not included) memory card
to Trail Camera.
- 06 -
App (iOS) App (Android)
or
Step 5
Scan the QR codes below search for“SUNTEKCAM” on the Apple app store
or search for “SUNTEKCAM” on the Google Play to download the app.
②
Tips：slide the mode switch form TEST to ON.
The camera will start working after 10 seconds countdown,
the red indicator light blinks meanwhile.
Step 4
①Slide the mode switch
Check the signal grid color.
Green means receiving signal, White means signal reception failed.
Need to check if the sim card whether locked or effective.
- 07 -
- 08 -
- 09 -
OPERATING BUTTON
MENU Menu Button -- Menu Setting
SHUTTER Shutter Button -- Start/End Video Recording or Photo Taking
Video Button -- Video Recording Mode
Camera Button -- Photo Mode
Replay Button -- Replay Mode
OK Button
EXTERNAL POWER SUPPLY
Use 12V DC Power source (Not included)
Tips：In replay viewing page, slide the " " and " " for browsing.
Press the " SHUTTER " button, to quit the replay view page.
