SunSynk SUNSYNK MAX Manuel utilisateur

SUNSYNK MAX

Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.

171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong.

Tel: +852 2884 4318 Fax: +8522884 4816

www.sunsynk.com / [email protected]

USER MANUAL

v.7 (12/09/22)

MAX | User Manual2

Table of Contents

1. SAFETY 5

1.1. General Safety 5

1.2. Symbols 5

1.3. Safety Instructions 6

1.4. Disposal Remarks 6

2. PRODUCT INTRODUCTION 7

2.1. Product Size 9

2.2. Basic System Architecture 10

3. TECHNICAL SPECIFICATIONS 11

4. INSTALLATION 13

4.1. Parts List 13

4.2. Selecting the Mounting Area 14

4.3. System Diagram 15

4.4. Mounting the Inverter 15

4.5. Function Port Denition 17

4.6. Battery Connection 18

4.6.1. Recommended DC Battery Protection 19

4.7. Connecting a Lithium Battery 20

4.8. Battery Temperature Sensor Connection 20

4.9. Connecting the AC 22

4.9.1. Recommended AC Surge Protector 23

4.10. Installing the CT Coil 24

4.11. Earth Connection (MANDATORY) 25

4.12. Meter Connection 26

4.12.1. System Connection for the CHNT Meter 26

4.13. Wiring System for Inverter 27

4.14. PV Connection 28

4.14.1. PV Module Selection 28

4.14.2. PV Module Wiring 28

4.15. PV Protection 29

4.16. Single-Phase Parallel Connection Diagram 30

4.17. Single-Phase Parallel with Diesel Generator Connection Diagram 31

4.18. Diesel Generator Connection Diagram 32

MAX | User Manual3

5. OPERATION 33

5.1. Display 33

5.2. Switching ON/OFF 33

5.3. Home Page 34

5.4. Status Page 34

5.5. System Flow Page 35

5.6. Setup Page 36

5.7. Set Time (Clock) 37

5.8. Set Company Name / Beeper / Auto dim 37

5.9. Factory Reset and Lock Code 38

5.10. Battery Setup Page 39

5.11. Generator & Battery Page 40

5.12. Battery Discharge Page 42

5.13. Setting Up a Lithium Battery 44

5.14. Program Charge & Discharge Times 49

5.15. Grid Supply Page 51

5.16. Connecting the DRM’s 52

5.17. Advanced Settings for Paralleling Inverters 53

5.18. Solar Power Generated 56

5.19. Grid Power 56

5.20. Advanced Settings for Wind Turbines 57

5.21. Advanced Settings for Auxiliary Load 58

5.22. Advanced Settings for Peak Shaving 59

5.23. Fault Codes 60

6. OPERATING MODES 63

6.1. Mode I: Basic 63

6.2. Mode II: With Generator 63

6.3. Mode III: With Smart Load 64

6.4. Mode IV: AC Couple 64

7. COMMISSIONING 66

7.1. Start-Up / Shutdown Procedure 66

7.2. Information for Commissioning the Inverter 67

7.3. GDFI Fault 68

8. MAINTENANCE 68

MAX | User Manual4

APPENDIX A 68

APPENDIX B 69

APPENDIX C 69

APPENDIX D 69

APPENDIX E 70

MAX | User Manual5

1. SAFETY

This device should only be used in accordance with the instructions within this manual and in

compliance with local, regional, and national laws and regulations. Only allow this device to be installed,

operated, maintained, and repaired by other person(s) who have read and understood this manual.

Ensure the manual is included with this device should it be passed to a third party.

DO NOT allow minors, untrained personnel, or person(s) suering from a physical or mental impairment

that would aect their ability to follow this manual, install, maintain or repair this device.

Any untrained personnel who might get near this device while it is in operation MUST be informed that it

is dangerous and instructed carefully on how to avoid injury.

1.1. General Safety

1.2. Symbols

WARNING This symbol indicates information that if ignored, could result in personal

injury or even death due to incorrect handling.

CAUTION This symbol indicates information that if ignored, could result in personal

injury or physical damage due to incorrect handling.

PLEASE NOTE Indicates information that is considered important, but not hazard-related.

MAX | User Manual6

1.3. Safety Instructions

Be sure to read this manual thoroughly before installation.

Do not attempt to install the inverter by yourself. Installation work must be carried out in compliance

with national wiring standards and by suitably qualied personnel only. Do not turn on the power until all

installation work is complete.

Do not disassemble the inverter. If you need repair or maintenance, contact a professional service cen-

tre.

Always use an individual power supply line protected by a circuit breaker and operating on all wires with

a distance between contacts of at least 3mm for this unit.

The unit must be correctly grounded, and the supply line must be equipped with a suitable breaker and

RCD to protect people.

Disconnect all wires/cables before performing any maintenance or cleaning to reduce the risk of electri-

cal shock.

The unit is not explosion-proof, so it should not be installed in an explosive atmosphere.

Never touch electrical components immediately after the power supply has been turned o since the

system can still have residual energy, so an electric shock may occur. Therefore, after turning o the

power, always wait 5 minutes before touching electrical components.

This unit contains no user-serviceable parts. Always consult an authorised contractor for repairs.

1.4. Disposal Remarks

DO NOT dispose this product with domestic waste!

Electrical devices should be disposed of in accordance with regional directives on electronic and/ or elec-

tronic-waste disposal. In case of further questions, please consult your supplier. In some cases, the supplier

can take care of proper disposal.

WARNING

HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION.

The Sunsynk Max can only be installed by a qualied licensed electrical contractor. This is not a DIY

product.

MAX | User Manual7

2. PRODUCT INTRODUCTION

The Sunsynk MAX is the most powerful low-voltage inverter in the world, achieving a maxium output power

of 16kW and battery charge current of 300A. This power management tool allows the user to hit those ‘par-

ity’ targets by managing power-ow from multiple sources such as solar, mains power (grid) and generators,

and then eectively storing and releasing power as and when utilities require.

INTERACTIVE

Supporting Wi-Fi or GSM monitoring

Visual power ow screen

Parallel / multi invert function grid-tied and o-grid

COMPATIBLE

Compatible with main electrical grid voltages or power generators

Self-consumption and feed-in to the grid

Auto restart while AC is recovering

Auto earth bond feature (Via a relay)

CONFIGURABLE

Fully programmable controller

Programmable supply priority for battery or grid

Programmable multiple operation modes: on-grid/o-grid & UPS

Congurable battery charging - current/voltage based on the application

Congurable AC / solar / generator charger priority by LCD setting

SECURE

Overload/over-temperature/short-circuit protection

Smart battery charger design for optimized battery protection

Limiting function installed to prevent excess power overow to grid

ACDC AlarmNormal

Colorful touch LCD, IP65 protection degree

DC couple and AC couple to retrot existing solar system

Max. 16 inverters in parallel; Support multiple batteries parallel

Max. charging/discharging current of 300A

16kW super hybrid inverter

Support storing energy from diesel generator

275

MAX | User Manual8

1. Inverter Indicators 6. Modbus(RS-485) Port 11. PV input with two MPPT

2. LCD Display 7. Parallel port 12. Generator input

3. Function Buttons 8. Battery input connectors 13. Load

4. DC Switch 9. Functon Port 14. Grid

5. Power on/o button 10. Battery(CANBus) Port 15. WiFi Interface

MAX | User Manual9

2.1. Product Size

MAX | User Manual10

2.2. Basic System Architecture

The following illustraton shows basic applicaton of this inverter.

It also includes following devices to have a Complete running system.

Generator or Utlity

PV modules

Consult with your system integrator for other possible system architectures depending on your require-

ments.

This inverter can power all kinds of appliances in home or once environment, including motor type applianc-

es such as refrigerator and air conditioner.
