CA7DUAL

Tablet PC

Android 4.2

User Manual

Tablet of Contents

Specifications..………………………………………………………………….1

What’s inside the box…...………………………………………………………1

Tablet Parts...……………………………………………………………………2

Getting started...………………………………………………………………...3

How to use TF card ..……………………………………………………………8

How to connect with computer…...……………………………………………9

Connection to Internet...………………………………………………………..9

Camera…………………………………………………………………………10

Trouble Shooting....…………………………………………………………….11

Warranty conditions…………………………………...………………….……13

Specifications

Display: 7 inch 800X480 Capacitive multi-touch screen

CPU: A20 Dual-Core 1.0GHZ

RAM: 1GB DDR III

GPU Mali-400

Internal Storage: 8GB

Expansion Memory: Micro SD card up to 32GB (not supplied)

Built-In Wireless: 802.11b/g/n

TV Port: mini HDMI 1.4

front camera 0,3 Mpixels

AC Adapter: DC 5V-2A

Operating System: Android 4.2.2 “Jelly Bean”

Battery: 3000 mAh

Made in China

What’s Inside The box

Tablet – 1pc

Power Adapter -1pc

USB Cable-1pc

OTG Cable-1pc

Instruction manual - 1pc

Warranty card 1pc

Tablet Part

1- Power button

2- Earphone jack

3- Micro USB port

4- Return button

5- Mini HDMI port

6- Micro TF CARD

slot

Name function

Power Keep pressed to turn on/off the tablet;

shortly press to activate standby

USB OTG Port PC connection/peripheral connection

through OTG cable (for example keyboard,

USB device)/battery charge through the

supplied adaptor

Earphone jack Connect earphone to this standard 3.5mm

jack

Exit/return Exit from the current function/return to the

TV HD output Mini HDMI TV output to connect an external

screen.

Micro SD input Insert a micro SD card (up to 32GB)

Getting Started

Battery Charging

The tablet has a built-in rechargeable Li-polymer battery.

1. To charge connect the AC power adapter to the micro USB jack on the

right side of the tablet.

2. The battery icon shows the battery status and charging status

3. The tablet can be used even if the battery is being charged.

the above icons indicate the different level of power left in the battery

4. Do not replace the battery without authorization.

5. Recharge the unit for at least half hour if it has been idle for a long time

and fails to turn on.

6. Fully charge the battery at least once monthly

Disposal

The battery might contain the polluting material, please give it to the official

recycling-station before disposing the tablet pc, and don’t litter.

Power ON/OFF

ON:

Press the button for 5 seconds until the tablet turns “ON”.

OFF:

1.Press the button for 2 seconds and the option to power appears.

2.Select OK to power off the tablet

Screen Lock

This feature locks the screen, at the same time turns OFF the screen’s

backlight after a few seconds.

Screen locks when:

1. System is idle.

2. Manually activated by pressing the Power button once.

Screen unlock :

Home screen

The Home screen will look similar to the picture below. It is actually five

screens, each of which can have a different layout of icons. To switch between

screens, simply slide your finger left or right across the display.

The status bar and navigation buttons are always visible, no matter which

Home screen you can currently viewing.

The Desktop contains shortcuts to your most-used applications and widgets

Touch the screen icon to quickly search the World Wide Web using Google.

The icon will launch the Application menu.

The status bar displays system information, such as current time, wireless

connectivity and battery.

Touch to Expand the status bar for more detailed information.

The button moves back one step to the previous menu/page.

The buttons returns immediately to the Android desktop.

The button displays a menu of recently opened applications.

The screen capture .

The volume decrease.

The volume increase.

Settings Menu

The settings menu allows you to adjust the devices system configuration.

To change settings:

1. Touch the "Settings" menu icon on the Application menu.The

Settings menu will open.

2. Guide your finger up or down the left side of the screen to scroll through

the list of available categories.

3. Touch a category title to view further options on the right side of the

screen.

Wi-Fi - Connect to /disconnect from wireless networks, view connection status

Data usage - Enable / disable mobile data, view current usage, set mobile data limit (note:

this function is available only on devices supplied with 3G card)

Touch and pull down the top right corner screen to enter the faster setting option

Sound - Change volume, touch sound, screen lock sounds etc

Display - Change brightness, wallpaper, sleep settings, font size etc

Storage - Manage NAND and Micro SD card, view available capacity etc

Battery - See battery status and powered-on time

Apps - Manage applications, running services etc

Accounts - Manage accounts etc

Location services - Change approximate location detection, improve search results

Security - Change screen lock type, encryption, password, credential storage etc

Language & input Select language, add to the dictionary, edit on-screen keyboard settings,

vocal search, etc

Backup & reset - Backup & restore data, perform factory reset, etc

Date & time - Set date, time zone, time, clock format etc

Accessibility - Set up large text, auto-rotate screen, speak password etc

Developer options - Advanced functions for Android developers

About tablet - Information about your Android device

How to Use TF card

1. Insert the TF card into the TF card slot. Gently push TF card into slot until it

clicks into place.

2. A prompt will be seen on the screen saying “ Preparing SD card “

Removing TF card

1. Close all applications and documents which have been opened from the TF

card.

3. Select “Setting” and find “ Storage” then click “Unmount SD card”.

4. A prompt will be seen on the screen saying “ SD card safe to remove”

5. Gently press the TF card to remove and pull out the TF card.

Note: Insert the TF card in correct position, otherwise it will damage the card

and the slot.

Software Keyboard

The tablet has a software keyboard which automatically shows up when

you tap the place on screen where a text or a number are to be entered.

Touch Screen

The touch screen responds to finger touch.

Note: don’t place any object on the touch screen for it may damage or crush

the screen.

Single Click: single click one icon to choose the icon or option you want.

Long Press: press and hold one icon to make appear a menu related to the

executed function (if available).

Drag: drag on the screen and you can move between magic cube sides or

drag the application icons into the shortcut bar.
