SunStar SWF Manuel utilisateur

SWF EMBROIDERY MACHINE

How to Replace the Presser Foot Driving Cam

Set the presser foot 4mm T-wrench

Picture 1

Picture 2

1.Remove the Top Shaft Cover

1) Change the color to the last needle bar to secure

2) Remove the top shaft cover.

the sufficient space for the following steps.

and then use 3mm T-wrench to remove the head from the arm.

1)Remove the head face plate (U) with +driver

3Remove the arm protection

2Remove the head

Remove the top shaft cover

+driver, -driver Corner Driver

+driver, 3mm T-wrench

plate and side cover

2.Remove Head

driving cam

presser foot driving

cam setup JIG pin

[G] ARM

A. Content

DM-M-22

Order Tools Required

B. Order

C. Details

JIG /

Instruments

No.

CD CODE No:

Top Shaft Cover

─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE

1)Use a (-) driver to remove the arm protection

plate.

2)Use a (+) driver to remove the arm side cover B.

Refer to Picture 3

Picture 3

1)On the menu of OP Box, select "TOOL"

→ "PF UP/DOWN" in order to down the presser foot.

2) Set the angle plate to 150 degrees.

Refer to Picture 4

Picture 4 3) Insert the presser foot cam JIG pin in order of

the presser foot cam collar, the presser foot

driving cam base and the take-up driving cam base.

Refer to Picture 5

Picture 4

4) Adhere the presser foot driving cam to the side

of take-up driving cam. And then use a 4mm

T-wrench to assemble it

Refer to Picture 5, 6

Picture 5

3. Remove the Arm Protection Plate & the Side Cover

4. Set the Presser Foot Driving Cam

presser foot

cam

JIG pin

Caution

) At this time, check that the cutting

part of presser foot driving cam collar matches

with the cutting part of presser foot driving

cam.

─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─

SWF EMBROIDERY MACHINE

5) Set the angle plate to 100 degrees. And then turn

the presser foot driving pin pulley to check that

presser foot reciprocator set smoothly moves up

and down.

Picture 6 6)On the menu of OP Box, select "TOOL"

→ "PF UP/DOWN" in order to up the presser foot.

& the Side Cover

1) Assemble them in reverse of disassembly.

5. Assemble the Arm Protection Plate

6.Assemble the Head

7.Assemble the Top Shaft Cover

Caution

) If the setting of the presser foot

driving cam is bad, the balance of machine is

broken and then the shaking may extremely occur.

So, the correct setting is needed.

─ Ver.2009 1st ────────────────────── SunStar Co., Ltd ─
