Sunricher SR-2812BS Manuel utilisateur

Wall mounted RGB/W DMX512 controller

Parameter

Touch sensitive

Glass interface(White & Black)

Feature

SR-2812B

Control 1 zone,save up to 4 color

Part No. Operation Voltage DIMENSIONS

ø/h (mm)

OUTPUT

SR-2812B 12-24VDC 86x86x29.1

DMX512 Signal

Product Size

29.1

86.0

Installation

12-24VDC

Power Supply

Button introduction

Wiring diagram

D- GN D

Power Supply

12-24VDC

Vin D +

Power Supply

12-36VDC

110V-230VAC

SR-2812B

GND

110V-230VAC

D1 D1 D 2 D2

SR-2102B

DMX512 Decode r

GND

whi te

D1 D1 D 2 D2

SR-2102B

DMX512 Decode r

GND

whi te

D1 D1 D 2 D2

SR-2102B

DMX512 Decode r

GND

whi te

Color Wheel:

Touch to choose color

Brightness Color Running Button:

Short touch to start or Pause color

running mode;

Long touch to adjust speed (10 built-in

color running mode)

Switch: Short to

switch on/off

touch

Save Color:

Long Touch S1/S2/S3/S4 to save

your favorite colors

Short touch to choose the color R.G.B.W

Long touch to dim brightness of R.G.B.W

ISO 900 1：2000

Safety & Warnings

Warranty Agreement

1) The product shall be installed and serviced by a qualified person.

2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof

enclosure.

3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.

4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the

product.

5) Never connect any cables while power is on and always assure correct connections to avoid short circuits

before switching on.

7) For update information please consult your supplier.

Please ensure that the cable is secured tightly in the connector

1) We provide lifelong technical assistance with this product:

5-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The

warranty is for free repair or replacement and covers manufacturing faults only.

For faults beyond the 3-year warranty we reserve the right to charge for time and parts.

2) Limited Warrenty

Any defects caused by wrong operation.

Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and

replacement of chips.

Any damages due to transportation, vibration etc. after purchase.

Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.

Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near

harmful chemicals.

Product has been updated

3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.

Operation

How to save color or mode

buttons can save the color from mode or save color when you touch color wheel or touch

buttons.

Press button ,mode runs, see favorite mode---> press or or or button over 3 seconds until

connected light flashes. Then it saved successful ly.

Touch color wheel or touch color temperature button or touch any buttons----> see favorite color--->

press button over 3 seconds until connected light flashes. Then it saved successfully

How to recall color or mode?

Touch S1/S2/S3/S4 directly. .
