A Division of Snow Joe®, LLC Model 24V-SS11-CT Form No. SJ-24V-SS11-CT-880E-MR2

OPERATOR’S MANUAL

RCORDLESS SNOW SHOVEL – TOOL ONLY

24V MAX* | 11-INCH

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Read all instructions before using this cordless snow shovel.

Basic safety precautions should always be followed to reduce

the risk of re, electric shock and personal injury.

General Safety WARNINGS!

You and any other operator of this snow shovel must read,

understand and follow these instructions in their entirety, and

should reread them at the start of each snow season. Failure

to follow these instructions may result in ELECTRIC SHOCK,

FIRE and/or serious PERSONAL INJURY.

Notice the personal safety alert symbol mused in this

manual to draw your attention to a WARNING given along

with the particular operating instruction. This means that

the operation requires special ATTENTION, CAUTION and

AWARENESS.

1. Keep work area clean and well lit – Cluttered, dark areas

invite accidents.

2. Use the right product – Do not use this machine for any

job except that for which it is intended.

3. Replacement parts – When servicing this unit, use only

identical replacement parts. Replace or repair damaged

cord immediately on the charger.

Do not use on gravel surfaces unless the snow shovel

is adjusted for such surfaces in accordance with the

operator’s manual.

4. Keep children, bystanders and pets away –

All spectators, including pets, should be kept a safe

distance away from the work area.

5. Dress properly – Do not wear loose articles of clothing or

jewelry. They can become caught in moving parts.

Wear rubber boots.

6. Avoid accidental starting – Make sure the safety

switch and the trigger switch are in the o position

before inserting the battery in the unit. Do not carry the

cordless snow shovel with the safety switch and the

trigger switch engaged.

7. Moving parts – Keep hands and feet away from moving

parts. Keep guards in place and in proper working order.

8. mCAUTION! Exercise caution to avoid slipping or falling.

Wear protective footwear that will protect your feet and

improve your footing on slippery surfaces.

9. Use safety glasses – Also use safety footwear,

snug-tting clothing, protective gloves, hearing and head

protection.

10. Stay alert – Watch what you are doing. Use common

sense. Do not operate the cordless snow shovel when you

are tired or under the inuence of alcohol or drugs.

11. Do not force the tool – It will perform better with less

likelihood of personal or mechanical injury if it is used at

the rate for which it was designed.

12. Do not overreach – Keep proper footing and balance at

all times.

13. If the cordless snow shovel strikes a foreign object,

follow these steps:

• Stop the cordless snow shovel. Remove the battery.

• Inspect for damage.

• Repair any damage before restarting and operating

the snow shovel.

14. Disconnect the tool – Turn o the power switch and

remove the battery when it is not in use, before servicing

it, when changing accessories and when performing any

other maintenance task.

15. Store idle tool indoors – When not in use, the cordless

snow shovel should be stored indoors in a dry,

locked place out of the reach of children.

16. Maintain the cordless snow shovel with care –

Follow the applicable maintenance instructions for

replacing parts and changing accessories. Lubrication is

not required.

mThis is the safety alert symbol. It is used to alert

you to potential personal injury hazards. Obey all

safety messages that follow this symbol to avoid

possible injury or death.

Improperly using or maintaining this cordless snow

shovel could result in injury or death. To reduce

this potential, comply with the following safety

instructions.

This cordless snow shovel can amputate hands and

feet if used incorrectly. It can also pick up foreign

objects, which can become dangerous projectiles

when thrown into the air. Failure to observe the

following safety instructions could result in serious

personal injury.

Training

• Read, understand and follow all instructions on the machine

and in the manual before operating this unit. Thoroughly

familiarize yourself with the controls and the proper use of

the equipment. Know how to stop the unit and disengage

the controls quickly.

• Children should never be allowed access to the equipment.

Adults should never operate the equipment without

carefully reading and understanding these instructions.

• Keep the area of operation clear of all persons, particularly

small children and pets.

• Exercise caution to avoid slipping or falling.

Preparation

• Thoroughly inspect the area where the equipment is to be

used and remove all doormats, sleds, boards, wires and

other foreign objects.

• Do not operate the equipment without wearing adequate

winter garments. Avoid loose tting articles of clothing that

can become caught in moving parts. Wear footwear that will

improve footing on slippery surfaces.

• Do not attempt to clear snow from a gravel or crushed

rock surface. This product is intended for use only on

paved surfaces.

• Never attempt to make any adjustments while the motor

is running (except when specically recommended by the

manufacturer).

• Always wear safety glasses or eye shields during operation

or while performing an adjustment or repair to protect your

eyes from foreign objects that may be thrown from the

machine.

Operation

• Do not put hands or feet near or under rotating parts.

Keep clear of the discharge opening at all times.

• Exercise extreme caution when operating on or crossing

gravel drives, walks or roads. Stay alert for hidden hazards

or trac.

• After striking a foreign object, stop the motor. Thoroughly

inspect the cordless snow shovel for any damage, and

repair the damage before restarting and operating the

cordless snow shovel.

• If the unit should start to vibrate abnormally, stop the motor

and check the unit immediately to ascertain the cause.

Vibration is generally a sign of trouble.

• Stop the motor and remove the battery whenever you leave

the operating position, when transporting the unit, before

unclogging the rotor blade housing and when making any

repairs, adjustments or inspections to the unit.

• When cleaning, repairing or inspecting the cordless snow

shovel, make sure that all moving parts have come to a

complete stop before beginning work.

• Exercise extreme caution when operating on slopes.

• Never operate the cordless snow shovel without proper

guards and other safety devices in place and in proper

working order.

• Never direct the discharge toward people or areas where

property damage can occur. Keep children, pets and other

bystanders away from the work area.

• Do not overload the machine capacity by attempting to

clear snow at too fast a rate.

• Look behind and use care when backing up with the

cordless snow shovel.

• Never operate the cordless snow shovel without good

visibility or light. Always be sure of your footing, and keep

a rm hold on the handles. Walk, never run, with the unit.

Clearing a Clogged Rotor Housing

Hand contact with the rotating rotor blades inside the rotor

housing is the most common cause of injury associated

with cordless snow shovels. Never use your hands to clear a

clogged rotor housing.

To clear the rotor housing:

• Shut the motor o and remove the battery.

• Wait 10 seconds to be sure the rotor blades have come to a

complete stop.

• Always use a clean-out tool, not your hands, to free the

rotating blades.

Maintenance and Storage

• Check all fasteners at frequent intervals for proper tightness

to ensure that the equipment is in safe working condition.

• Always refer to the operator's manual for important details,

such as how to properly store your cordless snow shovel

for an extended period of time.

• Maintain or replace safety and instruction labels as needed.

• Run the machine a few minutes after throwing snow to

prevent the rotor blades from freezing.

Battery + Charger

Safety Instructions

NOTE: This unit is a tool only. The battery and the charger are

not included. They must be purchased separately.

Model 24V-SS11-CT is compatible with the iON+ 24V System

batteries and chargers. See page 14 for more information.

We pay a great deal of attention to the design of every battery

pack to ensure that we supply you with batteries that are safe,

durable and have a high energy density. The battery cells have

a wide range of safety devices. Each individual cell is initially

formatted and its electrical characteristic curves are recorded.

This data is then used exclusively to be able to assemble the

best possible battery packs.

Despite all the safety precautions, caution must always be

exercised when handling batteries. The following points must

be obeyed at all times to ensure safe use. Safe use can only

be guaranteed if undamaged cells are used. Incorrect handling

of the battery pack can cause cell damage.

IMPORTANT! Analyses conrm that incorrect use and poor

care of high-performance batteries are the main factors

responsible for personal and/or product damage.

mWARNING! Use only approved replacement batteries;

other batteries may damage the cordless snow shovel and

cause it to malfunction, which can lead to serious personal

injury.

mWARNING! Do not use a battery pack or appliance that

is damaged or modied. Damaged or modied batteries may

exhibit unpredictable behavior resulting in re, explosion or risk

of injury.

Do not modify or attempt to repair the appliance or the battery

pack except as indicated in the instructions for use and care.

Have your battery pack serviced by a qualied repair person

using only identical replacement parts. This will ensure that the

safety of the battery pack is maintained.

mCAUTION! To reduce the risk of injury, charge the

iON+ 24V lithium-ion battery pack only in its designated

iON+ 24V lithium-ion lithium-ion charger. Other types of

chargers present risk of re, personal injury and damage.

Do not wire a battery pack to a power supply plug or car

cigarette lighter. Such misuse will permanently disable or

damage the battery pack.

• Avoid dangerous environments – Do not charge the

battery pack in rain, snow or in damp or wet locations.

Do not use the battery pack or charger in the presence of

explosive atmospheres (gaseous fumes, dust or ammable

materials) because sparks may be generated when inserting

or removing the battery pack, which could lead to a re.

• Charge in a well-ventilated area – Do not block the

charger vents. Keep them clear to allow for proper

ventilation. Do not allow smoking or open ames near a

charging battery pack. Vented gases may explode.

NOTE: The safe temperature range for the battery is

41°F – 105ºF (5°C – 40.5°C). Do not charge the battery

outside in freezing weather; charge it at room temperature.

• Maintain charger cord – When unplugging the charger,

pull the plug, not the cord, from the receptacle to reduce

the risk of damage to the electrical plug and cord.

Never carry the charger by its cord or yank it by the cord

to disconnect it from the receptacle. Keep the cord away

from heat, oil and sharp edges. Make sure the cord will not

be stepped on, tripped over or subjected to damage or

stress when the charger is in use. Do not use the charger

with a damaged cord or plug. Replace a damaged charger

immediately.

• Do not use an extension cord unless it is absolutely

necessary – Using the wrong, damaged or improperly

wired extension cord poses a risk of re and electric shock.

If an extension cord must be used, plug the charger into a

properly wired 16 gauge or larger extension cord with the

female plug matching the male plug on the charger. Make

sure that the extension cord is in good electrical condition.

•Check the rated input for the charger before using –

The charger must be plugged into an appropriate

receptacle.

• Use only recommended attachments – Use of an

attachment not recommended or sold by the battery

charger or battery pack manufacturer may result in risk of

re, electric shock or personal injury.

• Unplug charger when not in use – Make sure to remove

battery packs from unplugged chargers.

mWARNING! To reduce the risk of electric shock,

always unplug the charger before performing any cleaning

or maintenance. Do not allow water to ow into the charger.

Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock

hazards.

• Do not burn or incinerate battery packs – Battery packs

may explode, causing personal injury or damage.

Toxic fumes and materials are created when battery packs

are burned.

• Do not crush, drop or damage battery packs – Do not

use the battery pack or charger if they have sustained a

sharp blow, been dropped, run over or have been damaged

in any way (i.e. pierced with a nail, hit with a hammer,

stepped on, etc.).

• Do not disassemble – Incorrect reassembly may pose

a serious risk of electric shock, re or exposure to toxic

battery chemicals. If the battery or charger are damaged,

contact an authorized Snow Joe®+ Sun Joe®dealer or

call the Snow Joe®+ Sun Joe®customer service center at

1-866-SNOWJOE (1-866-766-9563) for assistance.

• Battery chemicals cause serious burns – Never let a

damaged battery pack contact the skin, eyes or mouth. If a

damaged battery pack leaks battery chemicals, use rubber

or neoprene gloves to safely dispose of it. If skin is exposed

to battery uids, wash the aected area with soap and

water and rinse with vinegar. If eyes are exposed to battery

chemicals, immediately ush with water for

20 minutes and seek medical attention. Remove and

dispose of contaminated clothing.

• Do not short circuit – A battery pack will short circuit if

a metal object makes a connection between the positive

and negative contacts on the battery pack. Do not place a

battery pack near anything that may cause a short circuit,

such as paper clips, coins, keys, screws, nails and other

metallic objects. A short-circuited battery pack poses a risk

of re and severe personal injury.

• Store your battery pack and charger in a cool,

dry place – Do not store the battery pack or charger where

temperatures may exceed 105ºF (40.5ºC), such as in direct

sunlight or inside a vehicle or metal building during the

summer.

Information about the battery

1. For optimum battery performance, avoid low discharge

cycles by charging the battery pack frequently.

2. Store the battery pack in a cool place, ideally at

77°F (25°C) and charged fully.

3. Lithium-ion batteries are subject to a natural aging

process. The battery pack must be replaced at the latest

when its capacity falls to just 80% of its capacity when

new. Weakened cells in an aged battery pack are no

longer capable of meeting the high power requirements

needed for the proper operation of your snow shovel,

and therefore pose a safety risk.

4. Do not throw battery packs into an open re as this poses

a risk of explosion.

5. Do not ignite the battery pack or expose it to re.

6. Do not exhaustively discharge batteries. Exhaustive

discharge will damage the battery cells. The most

common cause of exhaustive discharge is lengthy storage

or non-use of partially discharged batteries. Stop working

as soon as the performance of the battery falls noticeably

or the electronic protection system triggers. Place the

battery pack in storage only after it has been fully charged.

7. Protect batteries and the tool from overloads. Overloads

will quickly result in overheating and cell damage inside

the battery housing even if this overheating is not

apparent externally.

8. Avoid damage and shocks. Immediately replace batteries

that have been dropped from a height of more than one

meter or those that have been exposed to violent shocks,

even if the housing of the battery pack appears to be

undamaged. The battery cells inside the battery may have

suered serious damage. In such instances, please read

the waste disposal information for proper battery disposal.

9. If the battery pack suers overloading and overheating,

the integrated protective cuto will switch o the

equipment for safety reasons.

IMPORTANT! Do not press the ON/OFF switch any more

if the protective cut-o has been activated. This may

damage the battery pack.

10. Use only original battery packs. The use of other batteries

poses a re risk and may result in injuries or an explosion.

Information about the charger and the

charging process

1. Please check the data marked on the rating plate of the

battery charger. Be sure to connect the battery charger

to a power supply with the voltage marked on the rating

plate. Never connect it to a dierent mains voltage.

2. Protect the battery charger and its cord from damage.

Keep the charger and its cord away from heat, oil and

sharp edges. Have damaged cords repaired without delay

by a qualied technician at an authorized Snow Joe®+

Sun Joe®dealer or call the Snow Joe®+ Sun Joe®

customer service center at 1-866-SNOWJOE

(1-866-766-9563).

3. Electrical plugs must match the outlet. Never modify

the plug in any way. Do not use any adapter plugs with

grounded appliances. Unmodied plugs and matching

outlets will reduce the risk of electric shock.

4. Keep the battery charger, battery pack(s) and the cordless

tool out of the reach of children.

5. Do not use the supplied battery charger to charge other

cordless tools.

6. During periods of heavy use, the battery pack will become

warm. Allow the battery pack to cool to room temperature

before inserting it into the charger to recharge.

7. Do not overcharge batteries. Do not exceed the maximum

charging times. These charging times only apply to

discharged batteries. Frequent insertion of a charged or

partially charged battery pack will result in overcharging

and cell damage. Do not leave batteries in the charger for

days on end.

8. Never use or charge batteries if you suspect that it has

been more than 12 months since the last time they were

charged. There is a high probability that the battery pack

has already suered dangerous damage (exhaustive

discharge).

9. Charging batteries at a temperature below 41°F (5°C) will

cause chemical damage to the cells and may cause a re.

10. Do not use batteries that have been exposed to heat

during the charging process, as the battery cells may have

suered dangerous damage.

11. Do not use batteries that have suered curvature or

deformation during the charging process or those that

exhibit other atypical symptoms (gassing, hissing,

cracking, etc.).

12. Never fully discharge the battery pack (maximum

recommended depth of discharge is 80%). A complete

discharge of the battery pack will lead to premature aging

of the battery cells.

Protectionfromenvironmentalinuences

1. Wear suitable work clothes. Wear safety goggles.

2. Protect your cordless tool and the battery charger from

moisture and rain. Moisture and rain can cause dangerous

cell damage.

3. Do not use the cordless tool or the battery charger near

vapors and ammable liquids.

4. Use the battery charger and cordless tools only in dry

conditions and at an ambient temperature of 41ºF – 105°F

(5°C – 40.5°C).

5. Do not keep the battery charger in places where the

temperature is liable to reach over 105°F (40.5°C).

In particular, do not leave the battery charger in a car that

is parked in the sunshine.

6. Protect batteries from overheating. Overloads,

overcharging and exposure to direct sunlight will result

in overheating and cell damage. Never charge or work

with batteries that have been overheated – replace them

immediately, if possible.

7. Store the charger and your cordless tool only in dry

locations with an ambient temperature of 41ºF – 105°F

(5°C – 40.5°C). Store your lithium-ion battery pack in a

cool, dry place at a temperature of 77°F (25°C). Protect

the battery pack, charger and cordless tool from humidity

and direct sunlight. Only place fully charged batteries in

storage.

8. Prevent the lithium-ion battery pack from freezing.

Battery packs that were stored below 32°F (0°C) for more

than 60 minutes must be discarded.

9. When handling batteries, be wary of electrostatic charge.

Electrostatic discharges can damage the electronic

protection system and the battery cells. Avoid electrostatic

charging and never touch the battery poles.

Safety Symbols

The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all

instructions on the machine before attempting to assemble and operate.

The rotating part will continuously

run for several seconds after you

turn o the machine.

READ THE OPERATOR'S

MANUAL(S) – Read, understand

and follow all instructions in the

user manual(s) before attempting

to assemble and operate.

SAFETY ALERT – Indicates a

precaution, a warning or a danger.

Wear hearing protection.

Wear eye protection.

Wear breathing protection.

Keep bystanders and children a

safe distance (at least 11 yd/10 m)

away from the work area.

WARNING! Do not expose the

unit to rain or wet conditions.

Keep dry.

CAUTION! Beware of stones and

other foreign objects that could

be thrown from the appliance.

DANGER! Cutting/dismemberment

hazard - Keep hands away from the

rotating auger. Do not use hands to

unclog rotor housing. Stop motor

before removing debris.

DANGER! Cutting/dismemberment

hazard - Keep feet away from the

rotating auger.

Symbols SymbolsDescriptions Descriptions

Indoor use only. Only use

battery charger indoors.

Do not use hands to unclog chute.

Keep hands, feet and clothing

away from the rotating auger to

avoid injury.

Wear safety gloves during use to

protect hands.

Wear safety footwear at all times to

provide protection against objects

that may accidentally fall on feet.

Know Your Cordless Snow Shovel

Read the owner’s manual and safety rules carefully before operating your cordless snow shovel. Compare the illustration

below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this

manual for future reference.

1. Upper handle

2. ON/OFF trigger switch

3. Battery compartment

4. Joint-xing knob and bolt (2)

5. Handle knob

6. Middle pole

7. Lower pole

8. Motor housing

9. Scraper blade

10. Shovel blade

11. Auxiliary handle

12. Upper pole

13. Safety switch

THE OTHER SIDE

SOLD

SEPARATELY

Battery + Charger

options available at

snowjoe.com

24VBAT

24VBAT-LTE 24VBAT-LT

24VBAT-XR

24VCHRG-QC

24VCHRG-DPC

Technical Data

Motor......................................................................400 W brush

Battery Voltage Max*................................................... 24V D.C.

Battery Capacity .................................. See page 14 for battery

options and specications

Battery Runtime Max ........................... See page 14 for battery

options and specications

No Load Speed .......................................................... 2500 rpm

Rotor ....................................................... 2-blade paddle auger

Clearing Width ......................................................11 in. (28 cm)

Depth of Snow Cut ............................................. 7 in. (17.8 cm)

Throw Distance Max .................................................. 20 ft (6 m)

Plowing Capacity Max .............................................. 74 lbs/min

(33 kg/min)

Net Weight .............................................................9 lbs (4.1 kg)

*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage

under typical load is 21.6 volts.

Unpacking

Carton Contents

• Cordless snow shovel upper pole assembly

• Cordless snow shovel lower pole assembly

• Middle pole with auxiliary handle

• Joint-xing knob and bolt (2 sets)

• Manuals with registration card

NOTE: In order to operate this cordless snow shovel you will

need iON+ 24V System batteries and chargers. See page 14 for

battery options and specications, or visit snowjoe.com.

1. Carefully remove the cordless snow shovel and check to

see that all of the above items are supplied.

2. Inspect the product carefully to make sure no breakage or

damage occurred during shipping. If you nd damaged or

missing parts, DO NOT return the unit to the store. Please

call the Snow Joe®+ Sun Joe®customer service center at

1-866-SNOWJOE (1-866-766-9563).

NOTE: Do not discard the shipping carton and packaging

material until you are ready to use your new cordless snow

shovel. The packaging is made of recyclable materials.

Properly dispose of these materials in accordance with

local regulations.

IMPORTANT! The equipment and packaging material are

not toys. Do not let children play with plastic bags, foils

or small parts. These items can be swallowed and pose a

suocation risk!

Battery Pack Operation

The equipment is powered by a lithium-ion battery. The battery

pack is completely sealed and maintenance free.

Battery Charge Level Indicator

The battery pack is equipped with a push button for checking

the charge level. Simply press the push button to read o the

battery charge level from the LEDs of the battery indicator:

• All 3 level monitoring LEDs are lit: Battery charge level

is high.

• 2 level monitoring LEDs are lit: Battery charge level is

decreasing. Stop work as soon as possible.

• 1 level monitoring LED is lit: Battery is at. Stop work

IMMEDIATELY and charge the battery. Otherwise the

battery’s service life will be greatly shortened.

NOTE: If the charge level button does not appear to be

working, insert the battery into the charger and charge as

needed.

NOTE: Immediately after using the battery pack, the charge

level button may display a lower charge than it will if checked

a few minutes later. The battery cells “recover” some of their

charge after resting.

In order to operate this cordless snow shovel you will need

a iON+ 24V System battery and charger. See page 14 for

battery and charger options and specications, or for more

information visit snowjoe.com.

TOOL ONLY

BATTERY + CHARGER SOLD SEPARATELY

Charge level button

The battery is at 30% capacity

and requires charging

The battery is at 60% capacity

and requires charging soon

The battery is at full capacity

Light IndicatorsLights

Charger Operation

mWARNING! Charge only iON+ 24V lithium-ion battery

packs with its compatible iON+ 24V lithium-ion charger. Other

types of batteries may cause personal injury and damage.

To reduce the risk of electric shock, do not allow water to ow

into the charger's AC/DC plug.

When to Charge the iON+ 24V

Lithium-Ion Battery

NOTE: The iON+ 24V lithium-ion battery packs do not develop

a "memory" when charged after only a partial discharge.

Therefore, it is not necessary to run down the battery pack

before placing it into the charger.

• Use the battery charge indicator lights to determine when to

charge your iON+ 24V lithium-ion battery pack.

• You can "top-o" your battery pack's charge before starting

a big job or after a long day of use.

Charging the Battery

1. Press the push lock buttons on the battery to pull the

battery pack out of the equipment (Fig. 1).

2. Depending on your Snow Joe®+ Sun Joe®charger

model, how to recharge your lithium-ion battery will vary.

You may either insert your 24-volt battery into the

24VCHRG-QC Quick Charger (sold separately) or the

24VCHRG-DPC Dual Port Charger (sold separately)

(Figs. 2 – 3).

3. The battery indicator LEDs will illuminate one by one

during the charging process. Unplug the charger

immediately when the 3 LEDs are all illuminated.

4. The 24VCHRG-QC Quick Charger (sold separately) and

the 24VCHRG-DPC Dual Port Charger (sold separately)

are also equipped with additional charging indicating

lights which will indicate the charging status (Figs. 2 – 3).

mCAUTION! FIRE HAZARD. When disconnecting the

charger from the battery, be sure to unplug the charger from

the outlet rst, then disconnect the charger from the battery.

mWARNING! The chargers do not automatically turn

owhenthebatteryisfullycharged.Please take care not

toleavethebatterypluggedintothecharger.Switchoor

unplug the charger at the mains when charging is complete.

In order to operate this cordless snow shovel you will need

a iON+ 24V System battery and charger. See page 14 for

battery and charger options and specications, or for more

information visit snowjoe.com.

TOOL ONLY

BATTERY + CHARGER SOLD SEPARATELY

Fig. 1

Push lock button

Fig. 2 Battery pack

24VCHRG-QC

quick charger

(Sold separately)

red

Charging

green

Fully

Charged

Fig. 3 Battery pack

24VCHRG-DPC

dual port charger

(Sold separately)

red

Charging

green

Fully

Charged

5. Timely recharging of the battery will help prolong the

battery's life. You must recharge the battery pack when

you notice a drop in the equipment's power.

IMPORTANT! Never allow the battery pack to become fully

discharged as this will cause irreversible damage to the

battery.

6. When charging is complete, remove the battery from the

charger by pulling the push lock button and sliding the

battery backward to unlock it from the charger.

Assembly

Connecting the Poles

1. Slide the middle pole into the lower pole assembly.

Align the screw holes (Fig. 4).

2. Insert the bolt through the square hole in the pole and

secure the other end with the joint-xing knob (Fig. 5).

Twist until tight.

NOTE: You may have to carefully move the wiring inside

the tube to one side if it blocks the path of the bolt.

3. Slide the upper pole assembly onto the middle pole.

Align the screw holes (Fig. 6).

4. Insert the bolt through the square hole in the pole and

secure the other end with the joint-xing knob (Fig. 7).

Twist until tight.

Operation

mWARNING! Keep the area to be cleared free of stones,

toys or other foreign objects that the rotor blades might pick

up and throw. Such items could be covered by snow and are

easy to overlook, so be sure to conduct a thorough inspection

of the area before beginning work.

Fig. 4

Middle pole

Lower pole

assembly

Fig. 5

Joint-xing

knob Bolt

Fig. 6

Upper pole

assembly

Middle pole

Fig. 7

Joint-xing

knob Bolt

Square hole

In order to operate this cordless snow shovel you will need

a iON+ 24V System battery and charger. See page 14 for

battery and charger options and specications, or for more

information visit snowjoe.com.

TOOL ONLY

BATTERY + CHARGER SOLD SEPARATELY

Table des matières

Langues :

Autres manuels sunjoe Souffleuse à neige

sunjoe

sunjoe SNOWJOE 324E Manuel utilisateur

Manuels Souffleuse à neige populaires d'autres marques

Murray

Murray 624504X4A Manuel utilisateur

Blizzard

Blizzard POWER PLOW 8100PP Manuel utilisateur

Craftsman

Craftsman 486.24837 Manuel utilisateur

Yard-Man

Yard-Man E2B5 Manuel utilisateur

ST ST 526 A Manuel utilisateur

MTD

MTD 3AA Manuel utilisateur

Toro

Toro Power TRX 1428 OHXE Manuel utilisateur

Ryobi

Ryobi RYAC800 Manuel utilisateur

Poulan Pro

Poulan Pro 416829 Manuel utilisateur

Poulan Pro

Poulan Pro 437986 Manuel utilisateur

MTD

MTD 319-180-00 Manuel utilisateur

Brute

Brute 1695565 Manuel utilisateur

Egholm

Egholm City Ranger 2250 Manuel utilisateur

Poulan Pro

Poulan Pro 420915 Manuel utilisateur

GreenWorks

GreenWorks SNF402 Manuel utilisateur

LOFTNESS

LOFTNESS 601D1 Manuel utilisateur

LOFTNESS

LOFTNESS 1082I Manuel utilisateur

LOFTNESS

LOFTNESS 481EL Manuel utilisateur

sunjoe SNOWJOE 24V-SS11-CT Manuel utilisateur

Manuels Souffleuse à neige populaires d'autres marques
