SUNGZU SKA500 Manuel utilisateur
SKA500 OPERATION GUIDE
Perfect Life from Endless Power!
Shenzhen Sungzu Technology Co.,Ltd
Manufacturer: Shenzhen Sungzu Technology Co.,Ltd
Add: 3/F, Block 1, Jiuhua Tech Park, Xingwei RD, Bao'an District,
Shenzhen City, Guangdong Province, P.R.C
Website: www.sungzu.com
Email: tony-chen@sungzu.com
Warning: Please read and understand the contents of this manual
carefully before using this product, and operate and use it in strict
accordance with the instructions, to avoid damage to the product or
external devices and equipment caused by improper use, and may
cause personal injury in severe cases.
Product No.
Catalog
Catalog
Product Introduction
Product Parameters
Operation Instruction
Beep Prompt
Trouble Shooting
Accessories List
Cautions
Product Liability Exemption
Warranty Card
1
2
3
4
8
8
9
10
10
11
1
1
1.Product Introduction
2
SKA500 is new generation multi-purpose power station backup battery pack.
This item is built-in long cycle times lithium-ion power battery and adopted high
strength aluminium alloys body. Its safety and reliability have been approved by
our R&D team long time testing. SKA500 achieved approval CE, RoHS, FCC
certificates and our factory passed through ISO9001. It brings user’s safety and
comfortable experience with its unique features.
SKA500 has two ways to get power. It can be recharged both by solar panel and
home electricity with provided ac adapter. SKA500 has multiple outputs. It
supports any output electric devices with its dual AC output 110V or 220V which
load power no more than 500W.
SKA500 can be used for any electric devices charging such as medical equipment,
emergency relief, outdoor activities, UAV drone battery, self-drive travelling,
family backup power, lighting, military etc.
1. AC output port×2
3. AC power switch
2. DC ON/OFF button
5. Charge input port
6. DC19V output
7. USB 5V output x3
4. DC12V output x4 8. USB 5V QC output
11. Cooling fan
10. Working fuse x2
9. Spare fuse x2
2
1
23
4
5
6
78
9
10
11
2.Product Parameters
3
1.Input voltage/current:
AC adapter input:
Solar panel input:
Fully charging time:
2. DC output：
2.1 USB output voltage/current:
2.2 DC output voltage/current:
3.AC output：
3.1 AC output：
3.2 Output voltage/current：
4.Capacity：
5.Size：
6.N.W：
7.Battery cycle times:
8.Working temperature:
9.Working humidity:
10.Multiple protections:
19Vdc/10A(Max)
22Vdc-30Vdc 10A(Max)
5.5 ~7 hours(charging by provided AC adapter)
5Vdc 3.0A (MAX)
5V ：5Vdc/2.0A,9Vdc/2.0A,12Vdc/1.5A
12Vdc/8.0A(Max) 19Vdc/3.5A(Max)
500W
220Vac/2.28A/50Hz 110Vac/4.64A/60Hz
14.8V/39Ah (3.7V/156000mAh)
381mm×243mm×128mm
7.5KG
≧800 times (capacity≧80%)
-10℃～65℃
≦95%
short circuit protection, over-charge protection,
over-heat protection, over-discharge protection,
over-voltage protection
3
1.1 When you are firstly using the unit, please insert provided four fuses to place.
Two fuses are for working. The other two fuses are backup ones for future use.
And then recharge the unit, it would be activated from sleeping mode.When
you insert the fuse,it might cause sparks due to the current into the circuit
board from fuse, but it won't hurt human body or destroy the products.
3.Operation Instruction
4
1.1Product activation steps：
1
（1）Open the fuse soft
socket cover.
（2）Insert the fuse.
The left slots are spare fuses
slots, the right slots are for
working fuses. Please make
sure all the working fuse
slots are fully plugged in,
or it will not work.
2Make sure the fuses
are fully inserted.
(3)Recharge the unit to activate it.
（Use the product’s standard
adapter to charge the product
for 10 to 30 seconds）
4
5
2. Check the capacity
Click DC button to check the capacity as belows.
Capacity1%~25% Capacity26%~50% Capacity51%~75% Capacity76%~100%
19V DC port output:
19V is working
12V DC port output:
12V is working
5V USB port output:
5V is working
5V QC port output:
5V or 9V or 12V is working
Blue indicator light on
Green light (× 4) light on
3. Turn on the unit
Long press DC button for 3 seconds,blue LED indicators and four green indicators
would turn on as below.
4. Direct current output
4.1 After turn on the unit, connect the electric devices to the DC or USB port for
charging. LED indiator would show as below.
5
6
5.1 Turn on AC output：Turn on AC Switch to “-”as below photo, red LED
indicator would turn on. Now it is ready to charge any electric devices
which load power below 500W.
The red indicator light on
4.2 DC output guidelines
5.2 AC output guidelines
TV
5.AC output
Supply power to mobile phone
Supply power to IPAD
Supply power to car equipment
Supply power to the 12V LED light
Supply power to the laptop
supply power to the refrigerator
supply power to the TV
supply power to laundry machinery
6
7
5.4 If without connecting AC output for 30 minutes, unit would sound “beep”
around 30 seconds to remind user to turn off the AC switch to avoid any
unexpected consumption. (SKA500 might sound “beep” when charge any
electric devices power very low or current very small. Don’t worry. It is
normal. It won’t effect the usage.)
5.3 Warning:
(1) Do not place your finger or hand-held conductor inside the “AC outlet” to
avoid electric shock.
(2) Before AC power equipment is connected, please confirm whether the
equipment voltage & power is consistent with the output voltage & power of
the power station.
(3) Do not connect AC output of SKA500 with its own DC input, or the unit SKA500
would be damaged.
7.Charging while discharging
This unit supports charging while discharging. When the input power is less
than the output power, the battery power will gradually reduce to the low power
state. At this time, the beep alarm of the product reminds the user to turn off the
output. If the output is not shut down in time, the product will automatically cut
off the output, and continue to sound beep alarm until the product power
reaches more than 30% stop beep and automatically open the output.
8. Cooling system:
Intelligent temperature control system is built in this product. When the internal
temperature of the unit is higher than 45℃, the cooling fan opens automatically
and closes automatically when the internal temperature of the unit falls below 45℃.
14.8V/39Ah
（3.7V/156000mAh）
SKA500
2915mAh
35X+
11560mAh
8X+
68W
6X+
28W
18H+
60W
10H+
75W
5.5X+
80w
7H+
50w
16H+
7
6.Equipment approximate charging time
