SumoSecurity IP-WF-42M Manuel utilisateur
NVR Connection Setup
LAN 1 LAN 2 LAN 3
Monitor / Television
Router
HDMI
Cat5e / 6
Connect a HDMI cable from the NVR to a monitor / television. Connect a Cat5e / 6 cable from
the NVR to the LAN port of a router. Plug in the included USB mouse to the NVR. Plug in the
power adapter to a power outlet. Note: A 2TB surveillance hard drive is preinstalled in the
NVR. USB and SD card ports are also provided for backing up onto external media
Power Adapter
Sumo
Powerful Defense
Security
WAN 12V
Antenna
Antenna
SD Card
Storage VGA HDMI
Install the camera inside or outside. The camera has an ingress rating of IP66 and can be
installed outside in the elements. Plug in the power adapter to an available power source.
The NVR will automatically detect the wireless camera. No pairing is necessary. In case the
IP camera is not detected, the NVR user interface has an option to pair cameras.
Camera Setup
5
Sumo
Powerful Defense
Security
DC
Mobile Setup
Download the free RXCamView
app on your smartphone or tablet
1Launch the app and add the
NVR by clicking on Device
2
Click on the +icon and select
Manual for adding the NVR
3Fill in all the relevant elds. For the
Device ID, scan the QR code
located on the NVR
4
Sumo
Powerful Defense
Security
Mobile Setup
Turn on push notications by
clicking Alarm
5Click the gear icon
6
Toggle to green to enable
push notications
7
Sumo
Powerful Defense
Security
