PRO Series Refrigeration

Use and Care Guide

CLEANING, MAINTENANCE,

AND MORE

2 | Sub-Zero Customer Care 800.222.7820

Contents

3PRO Series Refrigeration

4Safety Precautions

6PRO Series Features

7Interactive Controls

8Storage

11 Operation

14 Care Recommendations

15 Water Filtration System Data

16 Troubleshooting

19 Sub-Zero Warranty

PRO Series Refrigeration

subzero.com | 3

Customer Care

The model and serial number are printed on the enclosed

product registration card. Both numbers are also listed on

the product rating plate. Refer to page 4 for rating plate

location. For warranty purposes, you will also need the

date of installation and name of your authorized Sub-Zero

dealer. Record this information below for future reference.

SERVICE INFORMATION

Model Number

Serial Number

Date of Installation

Certiﬁed Service Name

Certiﬁed Service Number

Authorized Dealer

Dealer Number

If your product ever needs attention, be sure to use a

Sub-Zero Factory Certiﬁed Service provider recommended

by our Customer Care Center, or select one from our list

of providers available at subzero.com/locator. All Factory

Certiﬁed Service providers are carefully selected and thor-

oughly trained by us.

PRO Series Refrigeration

Important Note

To ensure this product is installed and operated as safely

and eciently as possible, take note of the following types

of highlighted information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION indicates a situation where minor injury or prod-

uct damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

IMPORTANT NOTE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise speciﬁed.

4 | Sub-Zero Customer Care 800.222.7820

Safety Precautions

IMPORTANT INSTRUCTIONS

WARNING

Do not store explosive substances such as

aerosol cans with a ﬂammable propellant in

this appliance.

WARNING

Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of

obstruction.

WARNING

Do not use mechanical devices or other

means to accelerate the defrosting pro-

cess, other than those recommended by the

manufacturer.

WARNING

Do not expose this appliance to rain.

WARNING

This appliance is only intended for residential

use.

WARNING

• This appliance contains ﬂammable refrig-

erant and must be handled, installed, ser-

viced, and decommissioned by authorized

personnel. Once decommissioned, consult

local authorities for disposal instructions.

• To minimize the risk of ignition due to

improper installation, replacement parts,

or service procedures, only refrigeration

technicians with ﬂammable refrigerant

training who are aware of the dangers of

dealing with high voltage electricity and

refrigerant under pressure are allowed to

work on this equipment.

• Do not damage the refrigeration circuit

when installing, maintaining, or servicing

the unit.

• This symbol indicates risk of ﬁre/

ﬂammable materials.

CAUTION

Incorporated ice makers must be installed by

the manufacturer or its service agent.

WARNING

Do not use electrical appliances inside the

food storage compartments of the appliance,

unless they are of the type recommended by

the manufacturer.

subzero.com | 5

Safety Precautions

IMPORTANT INSTRUCTIONS

WARNING

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or instruc-

tion concerning use of the appliance by a

person responsible for their safety. Children

should be supervised to ensure they do not

play with the appliance.

WARNING

DANGER: Risk of child entrapment. Before you

throw away your old refrigerator or freezer:

• Take o the doors.

• Leave the shelves and drawer dividers in

place so that children may not easily climb

inside.

WARNING

PROPOSITION 65 FOR CALIFORNIA RESIDENTS

Cancer and Reproductive Harm—

www.P65Warnings.ca.gov

6 | Sub-Zero Customer Care 800.222.7820

PRO Series Features

FEATURES

1Product Rating Plate (inside drawer)

2Freezer External Touch Display

3Refrigerator External Touch Display

4Air Puriﬁcation System

5Glass Shelves

6Slide-Out Bins

7Pull-Out Shelf

8Side Rail Supports

9Refrigerator Crisper Drawer

10 Removable Crisper Lid

11 Refrigerator Storage Drawer

12 Freezer Storage Drawer

13 Automatic Ice Maker

14 Ice Container

15 Water Filtration System (behind grille)

16 Condenser (behind grille)

PRO Series Features

PRO3650 (solid door model)

PRO4850G (glass door model)

subzero.com | 7

Interactive Controls

Interactive Touch Controls

For initial start-up, touch and hold POWER on either

external touch display, located on the grille.

Temperature can be adjusted in one-degree increments.

The left and right external displays control dierent tem-

perature zones in the unit, but can both access the settings

menu.

EXTERNAL TOUCH DISPLAY

To unlock the display, touch and hold for three seconds.

The display will lock automatically after 30 seconds of

inactivity. Refer to the illustrations below.

To adjust the temperature, touch the temperature dis-

played next to the corresponding zone icon.

To turn the ice maker on or o or to active max ice, touch

the ice cube(s) icon.

Freezer display

(36" model shown)

3838

Refrigerator display

SETTINGS

To access the Settings menu, touch on either external

touch display.

SETTINGS

Activate or deactivate power to the unit

Enable or disable automatic display lock

Activate, deactivate, or refresh puriﬁer life reminder

Enable or disable door/drawer alarm and duration

Enable or disable connect

Enable, disable reminder, or refresh ﬁlter life reminder

Enable or disable Sabbath mode

Adjust soft on lighting and accent lighting (if applicable)

Adjust temperature units

Adjust alarm volume and tone

Select language

View troubleshooting and service information

8 | Sub-Zero Customer Care 800.222.7820

Refrigerator Storage

GLASS SHELVES

To remove or adjust a glass shelf, tilt up, then lift up and

out. To reposition, insert the shelf in the tracks along the

back wall, then lower the front until it locks into position.

Refer to the illustration below.

IMPORTANT NOTE: Use care when handling glass shelves

to prevent breakage or scratching of the interior.

CAUTION

Warm glass shelves to room temperature before

immersing in warm water.

SLIDE-OUT BINS

Integrated rails mounted below the glass shelves allow

slide-out bins to be positioned in a variety of locations. To

remove or adjust a slide-out bin, pull the handle of the bin

forward until it stops, and lift up and out of the rails. Refer

to the illustration below.

Keeping Food At Its Best

DUAL REFRIGERATION®

This Sub-Zero features a unique Dual Refrigeration®

system to keep food fresher longer. Three separate

controls allow the refrigerator, refrigerator drawer(s), and

freezer to be set at dierent temperatures.

With the Sub-Zero Dual Refrigeration®system, individual

refrigerator and freezer systems have been designed to

maintain accurate, consistent temperatures and proper

humidity levels for longer food life expectancy. Dual

Refrigeration®eliminates transfer of fresh food odors to

frozen food and ice and does not freeze the moisture out

of the air in the fresh food section.

For handy tips and information on how to maximize food

freshness, refer to the freshness cards stored in the refrig-

erator.

Storage

Glass shelf removal

Slide-out bin removal

subzero.com | 9

Freezer Storage

STAINLESS STEEL SHELVES (48" MODELS)

To remove or adjust a shelf, tilt up, then lift up and out. To

install, insert the shelf in the tracks along the back wall,

then lower the front until it locks into position.

ICE CONTAINER

To remove the ice container, pull the drawer out to full-

extension, then lift the container up and out.

Refrigerator Storage

PULL-OUT SHELF

The bottom shelf pulls out for easy access to condiments

and other items commonly stored on door shelves. Adjust-

able rails keep items snugly in place. To adjust, pull the rail

up and rotate. Refer to the illustration below.

CRISPER LID

To remove the crisper lid assembly, pull the upper refrig-

erator drawer all the way out, raise the front edge of the

crisper lid up, and pull out from the back. Refer to the

illustration below.

DRAWER DIVIDERS

Long dividers run the full depth of the drawer, with shorter

dividers that connect to the long dividers to compartmen-

talize the drawer.

To remove the short dividers, lift up and out. The long

dividers cannot be removed.

Pull-out shelf

Crisper lid (48" model shown)

Storage

10 | Sub-Zero Customer Care 800.222.7820

Storage Drawers

Refrigerator and freezer storage drawers are removable for

cleaning. An automatic stop is built in to prevent the draw-

ers from coming all the way out unintentionally.

To remove, pull the drawer out to full-extension. Apply

forward pressure to the front of the drawer slide, and pull

up and back on the drawer handle. Refer to the illustration

below.

Storage

DRAWER

SLIDE

Storage drawer removal
