DESIGN GUIDE

PRO 48 SERIES

EFFECTIVE 1/4/2017

subzero-wolf.com.au

TABLE OF CONTENTS

3PRO 48 REFRIGERATION

8SUB-ZERO WARRANTIES

Features and specications are subject to change at any

time without notice.

Throughout this guide, dimensions may vary by ± 3 mm.

subzero-wolf.com.au

PRO 48 Refrigeration

Freshness nds unmistakable expression in the Sub-Zero

PRO 48. A 363 kg monument to food preservation—equal

parts sculpted metal design statement and culinary secret

weapon. Its vast interior, like its bold exterior, is crafted of

stainless steel. The PRO 48 is available with or without a

glass door and may be either built in or freestanding.

PRO 48 REFRIGERATION

ICB648PRO

ICB648PROG

PRO 48 MODELS

subzero-wolf.com.au

PRO 48 REFRIGERATION

2134

102 mm

HEIGHT DIMENSIONS ± 13 mm

657 mm

775

1070

767 mm

368 mm

606

781

533

60 mm

1219 mm

Overall Dimensions

PRO 48 MODELS

Models ICB648PRO, ICB648PROG.

INTERIOR CAPACITY R (L)* F (L)*

ICB648PRO 521 331

ICB648PROG 521 331

*Useable volume based on ISO 15502.

subzero-wolf.com.au

PRO 48 REFRIGERATION

OPENING

HEIGHT

FRONT VIEW

SIDE

VIEW

OPENING WIDTH

OPENING

DEPTH

TOP VIEW

Opening Dimensions

STANDARD | FLUSH INSTALLATION

For standard built-in installations, the face frame of the unit

will extend 51 mm beyond cabinetry. For ush installations,

the front of the face frame will be ush with surrounding

cabinetry.

OPENING DIMENSIONS WHD

Standard 1206 mm 2127 mm 620 mm

Flush 1219 mm 2137 mm 670 mm

subzero-wolf.com.au

PRO 48 REFRIGERATION

/%11-1+1*250%7-21

02()/6'%1&)86)(*5))67%1(-1+25-167%//)(%6%

67%1(%5(25A86,&8-/7-1%33/-'%7-212567%1(%5(&8-/7-1

-167%//%7-2167,)

%')

5%0)2

7,)81-7:-//);7)1(00

)<21('%&-1)75<1A86,&8-/7-1-167%//%7-2167,)*52172*

7,)*%')*5%0):-//&)A86,:-7,6855281(-1

'%&-1)75<





17)51%7-21%/02()/6

5207,)

%'725<()6-+1)(:-7,287%

75%16*250)55)

8-5)%#=)/)'75-'%/

6833/<*86)(%77,)'255)'75%7-1+*257,)81-7*5)48-5)(

<

2'%

251%7

21%

'2

(

)67

)32:)5'25

(

'%1

))%6

<

5)3

%')

(

86

7

)32:)5

)7

(



255202()/67,))/)'75-'%/6833/

6,28/(&))-7,)5

-17,)'%&-1)7%&29)7,)5)*5-

)5%725%"

00#!25-17,)'%&-1)7%/21

6-()





5))67%1(-1+7,)1/2'%7)7,)32:)532-17%63)57,)

(-%

5%0&)/2:6)3%5%7)'-5'8-76)59-'-1

21/<7,-6

%33/-%1')-65)48-5)(

5281(*%8/7'-5'8-7-17)55837)











-61275)'200)1()(%1(0%

'%86)-17)55837-21

23)5%7-21





2:)5

833/< #















=





-5'8-75)%.)5



%0

 )')

7%'/)



3521



5281(-1

7<3

)



02()/6'20):-7,%1%8720%7-'-')0%.)5%

35)6685)/-0-7-1

9%/9)%1(0)7)562*A);-&/)00

3-3):-7,@77-1

6-6-1'/8()(-17,)5)*5-

)5%725'%5721

211)'77,)35)6685)/-0-7-1

9%/9)'/26)727,):%7)57%3

!$!$ !!

IRECTION

Ensure water connection is

” BSP male

5)%()(287/)7





-P_7,)00:%7)5/-1)727,):%//%1(

22572)1685)-7-61?7648%6,)(:,)17,)5)

5-+)5%725-6

386,)(-1727,)'%9-7

2'%7)7,):%7)57%3)-7,)5-17,)

'%&-1)7%&29)%0-1-0802*00*5207,)A225



25-1

)'%

1)7%

)

!,):%7)5/-1)0867127-17)5

)5):-7,-167%//%7-212

7,)

-7-3&5%'.)76

















5)9)56)26026-66

67)0'%1&)

86)(

529-()(7,)5)-6'2167%17:%7)5

5)6685)2*&%5

72&%568

/-)(727,)81-7%7%//7-0)6

$-%#&" )-#* % &,+



 $%7)5 833/<-1)

00

%67

'



 $%7)55)6685)

>









 $%7)5-1)*25211)'7-21



FRONT VIEW

1918 mm

FROM

FLOOR

178

mm E

152

* +,&#&"$',#'&'!

('/ *+-(($0

*'$, *&,#. $',#'&

'!('/ */, *+-(($0

 ( &#&"'& + '! ++

2,200 mm

FROM

FLOOR

 *', *+-(($0 +#

!*#" ',#'&'!%%







pressure

limiting valve

6mm flexi hose

& tape to wall

 *', *+-(($0'.

!*#" ',#'&'!%%







pressure

limiting valve

6mm flexi hose

& tape to wall

Planning Information

subzero-wolf.com.au

PRO 48 REFRIGERATION

Standard Handles

Refer to the chart below for standard handle lengths for

PRO 48 models.

HANDLE LENGTH TUBULAR PRO

Door NA 703 mm

Refrigerator Drawer NA 506 mm

Freezer Drawer NA 294 mm

subzero-wolf.com.au

Sub-Zero International Limited Warranty

FOR RESIDENTIAL USE

FULL TWO YEAR WARRANTY*

For two years from the date of original installation, this Sub-Zero product warranty covers all parts and

labor to repair or replace, under normal residential use, any part of the product that proves to be defec-

tive in materials or workmanship. All service provided by Sub-Zero under the above warranty must be

performed by Sub-Zero factory certied service, unless otherwise specied by Sub-Zero, Inc. Service will

be provided during normal business hours.

FULL FIVE YEAR SEALED SYSTEM WARRANTY

For ve years from the date of original installation, this Sub-Zero product warranty covers all parts and

labor to repair or replace, under normal residential use, these parts that prove to be defective in materials

or workmanship: compressor, condenser, evaporator, drier and all connecting tubing. All service provided

by Sub-Zero under the above warranty must be performed by Sub-Zero factory certied service, unless

otherwise specied by Sub-Zero, Inc. Service will be provided during normal business hours.

For more information regarding your Sub-Zero product warranty, contact your authorized Sub-Zero dealer.

Warranties must comply to all country, state, city, local and or ordinance.

*Stainless steel (doors, panels, handles, product frames and interior surfaces) are covered by a limited

60-day parts and labor warranty for cosmetic defects.

*Replacement water lters and air purication cartridges are not covered by the product warranty.

Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &

Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design, are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.

All other trademarks are property of their respective owners in the United States and other countries.

SUBZERO-WOLF.COM.AU

Bank House, 11 – 19 Bank Place.

Melbourne Victoria Australia 3000

Telephone 03 9600 2218

enquiries@subzero.com
