SUB-ZERO DESIGN GUIDE

Contents

Built-In Refrigeration .......................... 3

PRO 48 Refrigeration ......................... 44

Integrated Refrigeration ...................... 50

Wine Storage ............................... 64

Undercounter Refrigeration .................... 84

Sub-Zero Warranties ......................... 92

IMPORTANT NOTE: Throughout this guide, dimensions may

vary by ± 1/8"(3).

Features and specifications are subject to change at any

time without notice. Visit subzero.com/specs for the most

up-to-date information.

Throughout this guide, dimensions in parentheses are millime-

ters unless otherwise specified.

MODEL BI-48S

Built-In Refrigeration 3

subzero.com/specs

Built-In Refrigeration. For the built-in line, Sub-Zero designers and engineers took a fresh look at everything, inside

and out. Exterior refinements include redesigned grilles and lower-profile hinges. Inside, new technology in food preserva-

tion makes the built-in line nothing short of revolutionary.

36"

(914)

36"

(914)

36"

(914)

84"

(2134)

BI-36R

36"

(914)

36"

(914)

84"

(2134)

30"

(762)

30"

(762)

48"

(1219)

48"

(1219)

42"

(1067)

42"

(1067)

84"

(2134)

36"

(914)

BI-36RG BI-36F BI-30UGBI-30U BI-36U BI-36UG

BI-36S BI-42S

BI-42SID

BI-42SD BI-48S

BI-48SID

BI-48SD

BUILT-IN MODELS

KEY FEATURES

•Four distinct design approaches: framed, overlay,

flush inset and stainless steel.

•Handle options coordinate with handles of Wolf

cooking products.

•Dual refrigeration; two compressors preserve food’s

goodness in two sealed compartments.

•Energy efficient; many models are ENERGY STAR®

qualified.

•NEW! Internal dispenser models provide ice and chilled

water inside the refrigerator.

•Advanced water filtration and air purification systems.

•Crisper and deli drawers form a lower-temperature

zone for produce and meats.

•Flip-up grille provides easy access for quick routine

maintenance.

•All models are Star-K certified.

Built-In Refrigeration 4

Built-In Design Options. A design classic is now even better. Four distinct design approaches provide limitless

flexibility for creating a beautiful kitchen. Lower-profile hinges enable the built-in units to blend more seamlessly with

surrounding cabinetry.

Framed. Custom cabinetry

panels slide into the door to

blend into the kitchen design.

Shown with full-length handle

and louvered grille option for

the traditional Sub-Zero look.

Overlay. Custom cabinet

overlay panels can be

combined with unique

hardware for design flexibility.

Shown with pro handle option

to complement Wolf ranges.

Built-In Refrigeration 5

subzero.com/specs

Flush Inset. This design

option allows for a flush door

and grille. Stainless steel panels

are available as sales acces-

sories. Shown with tubular

handle option to mirror Wolf

built-in ovens.

Stainless Steel. For a

professional look, this design

requires no customization. To

complement the look of Wolf

ranges, choose the pro handle

option shown here.

Built-In Refrigeration 6

36" (914)

84"

(2134)

24" (610)

4" (102)

733/4"

(1873)

237/8"

(606)

371/4"

(946)

17"

(432)

237/8"(606)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

MODELS BI-36R, BI-36RG AND BI-36F

Shipping weights and overall dimensions are based on

stainless steel models. For flush inset applications, add

1/2"(13) to door clearance dimensions.

All Refrigerator / All Freezer Models

OVERALL DIMENSIONS

Built-In Models

SPECIFICATIONS

Interior Capacity R cu ft (L) Fcuft(L)

ALL REFRIGERATOR / ALL FREEZER MODELS

BI-36R 23.4 (663)

BI-36RG 23.2 (657)

BI-36F 22.8 (646)

OVER-AND-UNDER MODELS

BI-30U 13.0 (368) 4.1 (116)

BI-30UG 13.0 (368) 4.1 (116)

BI-36U 16.2 (459) 5.3 (150)

BI-36UG 16.1 (456) 5.3 (150)

SIDE-BY-SIDE MODELS

BI-36S 12.2 (346) 8.0 (227)

BI-42S 16.1 (456) 8.0 (227)

BI-42SID 16.0 (453) 8.0 (227)

BI-42SD 16.0 (453) 8.1 (230)

BI-48S 18.8 (532) 9.5 (269)

BI-48SID 18.7 (530) 9.6 (267)

BI-48SD 18.7 (530) 9.7 (265)

Shipping Weight lbs (kg)

ALL REFRIGERATOR / ALL FREEZER MODELS

BI-36R 420 (191)

BI-36RG 430 (195)

BI-36F 406 (184)

OVER-AND-UNDER MODELS

BI-30U 462 (210)

BI-30UG 476 (216)

BI-36U 515 (234)

BI-36UG 529 (240)

SIDE-BY-SIDE MODELS

BI-36S 538 (244)

BI-42S 582 (264)

BI-42SID 608 (276)

BI-42SD 608 (276)

BI-48S 630 (286)

BI-48SID 656 (298)

BI-48SD 656 (298)

Built-In Refrigeration 7

subzero.com/specs

30" (762)

84"

(2134)

24" (610)

4" (102)

503/4"

(1289)

23"

(584)

237/8"

(606)

235/8"

(600) 311/4"

(796)

141/2"

(368)

237/8"(606)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

MODELS BI-30U AND BI-30UG

36" (914)

84"

(2134)

24" (610)

4" (102)

503/4"

(1289)

23"

(584)

237/8"

(606)

235/8"

(600) 371/4"

(946)

17"

(432)

237/8"(606)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

MODELS BI-36U AND BI-36UG

Over-and-Under Models

OVERALL DIMENSIONS

Built-In Refrigeration 8

Overall dimensions are based on stainless steel models.

For flush inset applications, add 1/2"(13) to door clearance

dimensions.

42" (1067)

84"

(2134)

24" (610)

4" (102 )

733/4"

(1873)

237/8"(606)

237/8"

(606)

261/4"

(668)

121/2"

(318)

83/4"

(222)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

MODELS BI-42S, BI-42SID AND BI-42SD

36" (914)

84"

(2134)

24" (610)

4" (102)

733/4"

(1873)

237/8"

(606)

221/4"

(565)

81/2"

(216)

101/4"

(260)

237/8"(606)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

MODEL BI-36S

Side-by-Side Models

OVERALL DIMENSIONS

Built-In Refrigeration 9

subzero.com/specs

48" (1219)

84"

(2134)

24" (610)

4" (102)

733/4"

(1873)

237/8"(606)

237/8"

(606)

30"

(762)

14"

(356)

93/4"

(248)

23/8"(60)

HEIGHT DIMENSIONS ± 1/2"(13)

Side-by-Side Models

OVERALL DIMENSIONS

MODELS BI-48S, BI-48SID AND BI-48SD

Built-In Refrigeration 10

Opening Width A

BI-36R, BI-36RG and BI-36F 351/2"(902)

BI-30U and BI-30UG 291/2"(746)

BI-36U and BI-36UG 351/2"(902)

BI-36S 351/2"(902)

BI-42S, BI-42SID and BI-42SD 411/2"(1054)

BI-48S, BI-48SID and BI-48SD 471/2"(1206)

24" (610)

OPENING

DEPTH

FRONT VIEWSIDE VIEW

TOP VIEW

OPENING WIDTH

24" (610)

OPENING DEPTH

833/4"

(2127)

OPENING

HEIGHT

Built-In Models

STANDARD INSTALLATION IMPORTANT NOTE: If an 83" (2108) grille height is specified,

the opening height must be decreased by 7/8"(22).Ifan88"

(2235) grille height is specified, the opening height increases

by 4" (102).

If two units are installed side by side, refer to pages 30–31 for

dual standard installations.
