LaboForce-100
Instruction Manual
Original Instructions
Doc. no.: 16367025-03_B_en
Date of release: 2022.10.13
Copyright
The contents of this manual are the property of Struers ApS. Reproduction of any part of this manual without
the written permission of Struers ApS is not allowed.
All rights reserved. © Struers ApS 2022.10.24.
2 LaboForce-100
Table of Contents
1 About this manual 5
2 Safety 5
2.1 Intended use 5
2.2 LaboForce-100safety precautions 5
2.2.1 Read carefully before use 5
2.3 Safety messages 6
2.4 Safety messages in this manual 7
3 Getting started 8
3.1 Device description 8
3.2 LaboForce-100 8
4 Transport and storage 9
4.1 Long-term storage or shipping 9
5 Installation 9
5.1 Unpacking 9
5.2 Checking the packing list 9
5.3 Installation - LaboForce-100 10
5.4 Electrical connection to the machine 10
5.5 Compressed-air connections 11
5.6 The specimen mover 11
5.6.1 Inserting a specimen holder 11
5.6.2 Inserting a specimen mover plate 12
5.6.3 Adjusting the height of the specimen mover plate 12
5.6.4Adjusting the horizontal position of the specimen holder or specimen
mover plate 14
5.6.5 Completing the adjustment 15
5.7 The flexible specimen holder 15
5.7.1 Inserting a flexible specimen holder 17
5.7.2 Adjusting the height of the flexible specimen holder 17
5.7.3 Adjusting the horizontal position of the flexible specimen holder 19
5.8 LaboDoser-100 with LaboForce-100 19
5.9 LaboDoser-10 with LaboForce-100 19
5.10 Noise and vibration levels 19
6 Operating the device 20
6.1 Control panel functions 20
LaboForce-100 3
7 Maintenance and service 21
7.1 General cleaning 21
7.2 Daily 22
7.3 Weekly 22
7.3.1 LaboForce-100 - the specimen mover head 22
7.4 Monthly 23
7.4.1 LaboForce-100 - Emptying the water/oil filter 23
7.5 Spare parts 23
7.6 Service and repair 23
7.6.1 Service check - LaboForce-100 24
7.7 Disposal 24
8 Troubleshooting 25
8.1 LaboForce-100 25
8.1.1 Messages and errors - LaboForce-100 25
9 Technical data 28
9.1 Technical data - LaboForce-100 28
9.2 Diagrams - LaboForce-100 29
9.3 Legal and regulatory information 32
10 Manufacturer 32
Declaration of Incorporation of Partly Completed Machinery 33
4 LaboForce-100
1 About this manual
Instruction Manuals
Struers equipment must only be used in connection with and as described in the Instruction
Manual supplied with the equipment.
Note
Read the instruction manual carefully before use.
Note
If you wish to view specific information in detail, see the online version of this
manual.
2 Safety
2.1 Intended use
The device is for professional semi-automatic materialographic preparation (grinding or polishing)
of materials for further materialographic inspection.
LaboForce-100 is intended to be used in combination with:
• LaboPol-30
• LaboPol-60
• LaboDoser-100
Do not use the device for
the following
Other equipment than stated in the section "Intended use".
Model LaboForce-100
2.2 LaboForce-100safety precautions
2.2.1 Read carefully before use
Ignoring this information and mishandling of the equipment can lead to severe bodily injuries and
material damage.
1 About this manual
LaboForce-100 5
Specific safety precautions - residual risks
1. To prevent specimens from detaching from the specimen holder, make sure that the specimen
or specimens are clamped securely in the specimen holder.
2. Protective footwear is recommended when you handle heavy specimen holders.
General safety precautions
1. The machine must be installed in compliance with local safety regulations. All functions on the
machine and any connected equipment must be in working order.
2. This device must be mounted securely on the machine.
3. The operator must read the safety precautions and Instruction Manual, as well as relevant
sections of the manuals for any connected equipment and accessories.
4. If you observe malfunctions or hear unusual noises, switch off the machine and call technical
service.
5. Consumables: only use consumables specifically developed for use with this type of
materialographic machine.Alcohol-based consumables: follow the current safety rules for
handling, mixing, filling, emptying and disposing of alcohol-based liquids.
6. In case of fire, alert bystanders and the fire brigade.Disconnect the electrical power supply.Use
a powder fire extinguisher.Do not use water.
7. This machine must be operated and maintained only by skilled/trained personnel.
8. Always switch off the electrical power supply and remove the plug or power cable before
dismantling the machine or installing additional components.
9. The machine must be disconnected from the electrical power supply prior to any service. Wait 5
minutes until residual potential on the capacitors is discharged.
10. Struers equipment must only be used in connection with and as described in the Instruction
Manual supplied with the equipment.
11. The equipment is designed to be used only with Struers consumables specifically designed for
this purpose and this type of machine.
12. If the equipment is subjected to misuse, incorrect installation, alteration, neglect, accident or
incorrect repair, Struers will accept no responsibility for damage to the user or the equipment.
13. Dismantling of any part of the equipment, during service or repair, should always be performed
by a qualified technician (electromechanical, electronic, mechanical, pneumatic, etc.).
2.3 Safety messages
Struers uses the following signs to indicate potential hazards.
ELECTRICAL HAZARD
This sign indicates an electrical hazard which, if not avoided, will result in death or
serious injury.
6 LaboForce-100
2 Safety
DANGER
This sign indicates a hazard with a high level of risk which, if not avoided, will
result in death or serious injury.
WARNING
This sign indicates a hazard with a medium level of risk which, if not avoided,
could result in death or serious injury.
CAUTION
This sign indicates a hazard with a low level of risk which, if not avoided, could
result in minor or moderate injury.
CRUSHING HAZARD
This sign indicates a crushing hazard which, if not avoided, could result in minor,
moderate or serious injury.
HEAT HAZARD
This sign indicates a heat hazard which, if not avoided, can result in minor,
moderate or serious injury.
General messages
Note
This sign indicates that there is a risk of damage to property, or a need to proceed
with special care.
Hint
This sign indicates that additional information and hints are available.
2.4 Safety messages in this manual
WARNING
Struers equipment must only be used in connection with and as described in the
Instruction Manual supplied with the equipment.
CRUSHING HAZARD
Wear safety shoes when handling heavy machinery.
2 Safety
LaboForce-100 7
3 Getting started
3.1 Device description
LaboForce-100 is a control panel/specimen mover unit which can be mounted on the following
machines for semi-automatic materialographic preparation (grinding/polishing): LaboPol-30 and
LaboPol-60.
On the control panel screen the operator sets up the process parameters required, the
grinding/polishing surface and the cooling fluid/abrasive suspension to be applied.
Cooling water is applied automatically when the operator opens the water tap.The operator applies
other fluids manually, or automatically if LaboDoser-100 is installed.
A holding device for the preparation of specimens must be used with the specimen mover. The
holding device holds a maximum of 6 specimens.
The operator decides which holding device should be used:
• A specimen holder, which is a fixture that secures the specimens.
• A specimen mover plate, where pressurized feet from the mover head keep the specimens in
place.
The operator starts the machine by pressing the Start button on the control panel.
The machine stops automatically.
The operator cleans the specimens before the next preparation step or inspection.
The machine must always be used with the splash guard in place.
If the emergency stop is activated, the power to all moving parts is cut.
3.2 LaboForce-100
Front view
AControl panel
BTurn/push knob knob
CLED lights (not shown)
DSpecimen mover head
EControl panel column
8 LaboForce-100
3 Getting started
4 Transport and storage
If, at any time after the installation, you have to move the unit or place it in storage, there is a
number of guidelines we recommend that you follow.
• Package the unit securely before transportation.
Insufficient packaging could cause damage to the unit and will void the warranty. Contact
Struers Service.
• Struers recommends that all original packaging and fittings are kept for future use.
4.1 Long-term storage or shipping
For instructions on how to prepare the unit for long-term storage or shipping, see the specific
machine manual.
Pay specific attention to the following:
• Disconnect the unit from the electrical power supply.
• Remove the control panel or specimen mover.
• Place the machine and accessories in their original packaging.
5 Installation
5.1 Unpacking
Note
Struers recommends that all original packaging and fittings are kept for future use.
1. Cut the packing tape on the top of the box.
2. Remove the loose parts.
3. Remove the unit from the box.
5.2 Checking the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
Pcs. Description
1 LaboForce-100
1 Connection piece. Diameter: 6 to 1/8"
4 Transport and storage
LaboForce-100 9
Pcs. Description
1 Allen key with cross handle, 4x150
1 Spacing disc
1 Instruction Manual set
5.3 Installation - LaboForce-100
Note
This device must be mounted securely on the machine.
Note
Do not use the Turn/push knob knob to move LaboForce-100.
Procedure
1. Install the specimen mover in the support hole of the
machine.
2. Use the Allen key to tighten the two fastening screws. Do
not tighten the screws completely.
ASupport hole
BFastening screws
5.4 Electrical connection to the machine
Hint
The communication cable in the support hole is not used for LaboForce-100.
The cable attached to LaboForce-100 provides a 24 V power supply and a data bus, which enables
the machine and LaboForce-100 to communicate.
1. Switch off the machine.
2. Connect the cable to the LaboForce-100 connector on the back of the machine.
10 LaboForce-100
5 Installation
