The use of shop equipment is subject to certain hazards that cannot be prevented by mechanical means,
but only by exercise of intelligence, care, and common sense. It is therefore essential to have personnel
involved in the use and operation of equipment who are careful, competent, trained, and qualified in the
safe operation of this equipment and its proper use. Examples of hazards are dropping, tipping, or slipping
of parts/components caused primarily by improperly securing loads, overloading, off-centered loads, use
on other than hard level surfaces, and using equipment for a purpose for which it was not designed.
The owner and / or operator shall study and understand the product and safety instructions before operat-
ing this equipment. Safety information shall be emphasized and understood. If the operator is not fluent in
English, the product and safety instructions shall be read to and discussed with the operator in the oper-
ator’s native language by the purchaser / owner or his designee, making sure that the operator compre-
hends their contents. A copy of these instructions / warnings shall be retained for future reference.
• ItistheresponsibilityoftheownerofthiskittoensureitisbeingusedinaccordancewithallOSHA,
provincial, and local safety regulations. Always wear protective eye wear when working with this
piece of equipment.
• Do Notusebeyondratedcapacity.IMPORTANT:Theratedcapacityofthisrepairkitisaffectedand
can be reduced depending on the attachments used. Wedge rams are rated at 1/2 ton capacity. When
using extension tubes, each tube used reduces the capacity by 50%. For example if one extension tube
isusedthecapacityis50%.WhenusingtheRamToeandPlungerToecapacityisreducedto50%of
ramcapacity.MaximumRubberHeadcapacityis0.5Tonforthe0302024Tonunitand1.0Tonforthe
030207 - 10 Ton unit. (see chart below) Use only adapters / extensions provided with the unit.
• Alwayspositiontheshortestextensiontubefarthestawayfromtheraminamultipletubesetup.
• Do Not use this equipment as a vehicle lifting device or as a vehicle support
• Do Not subject the hose to extreme cold, heat sharp surfaces, abrasion, or impact.
• Ensurethehoseisfreeofobstructions,andisinastraightlineorarc,donotoperatethepumpwiththe
hose bent sharply.
• Do not operate the pump when the ram reaches full extension, operating the pump with the ram
at full extension could cause damage to the ram and/or personal injury.
• Never operate the pump with release valve closed and hose disconnected from ram, this will pressurize
the hose and connections, possibly causing a burst condition and damage to the pump, hose and / or
personal injury.
• Checkthehoseandconnectionsoftenforleaksordamage.Preventthehosefrombeingpinched,cut
or having heavy objects fall onto the hose. If a leak occurs, the ram will retract, if the hose is cut, the
setup will immediately lose pressure.
• Noalterationsormodificationsshallbemadetothisproduct.
• Do Not carry the pump / ram assembly by the hose.
• STOP and Checktoensurethesetupisstablepriortostartinganywork,aswellasCHECKOFTEN
thatthesetupremainsstableduringanyworkbeingperformed.Operatethepumpslowly,whileatthe
same time watching the ram and points of contact to ensure the operation is safe and secure.
• Failuretoheedthesewarningsmayresultinpersonalinjury,propertydamageorboth.
!WARNING!
