Model No. SAE-P48

4 post Parking Lift

Single Point Manual Release

Lifting Capacity 8,000 lbs

Installation & Operation &

Maintenance Instructions

Important Note

1. This equipment can not be installed, operated or repaired without reading instructions.

2. Electricity must be hooked up by certified electrician.

3. Do not use this equipment beyond its rated capacity.

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions



TABLE OF CONTENTS

Packing, transport and storage .......................................................................................................................................5
1 Packing..............................................................................................................................................................................5
2 Transport...........................................................................................................................................................................5
3 Storage..............................................................................................................................................................................5
Description of the machine...............................................................................................................................................6
Technical specifications....................................................................................................................................................7
Safety......................................................................................................................................................................................9
1 General warnings.............................................................................................................................................................9
2 Risks for people...............................................................................................................................................................9
3 Personnel crushing risks................................................................................................................................................9
4 Risk of the vehicle falling from lift..................................................................................................................................9
5 Slipping risks..................................................................................................................................................................10
6 Electrocution risks .........................................................................................................................................................10
7 Risks resulting from improper lighting........................................................................................................................10
8 Risks of breaking component during operation.........................................................................................................10
9 Risks for unauthorized uses.........................................................................................................................................10
10 Risks during vehicle lifting and working...................................................................................................................10
Installation...........................................................................................................................................................................11
1 Tool required...................................................................................................................................................................11
2 Checking for room suitability........................................................................................................................................12
3 Lighting.......................................................................................................................................................................12
4 Installation surface.........................................................................................................................................................12
5 Site layout..................................................................................................................................................................12
6 Connect the platforms and beams..............................................................................................................................13
7 Mount on the top post plate and fix safety ratchets..................................................................................................14
8 Mount on lifting platforms.............................................................................................................................................14
9 Fix transfer bar...............................................................................................................................................................16
10 Routing steel cable......................................................................................................................................................17
11 Installation of power unit.............................................................................................................................................17
12 Connection of hydraulic hoses..................................................................................................................................18
13 Lock system assembly................................................................................................................................................18
14 Make electrical hookup to power unit.......................................................................................................................19
15 Oil filling and bleeding.................................................................................................................................................20
16 Final installation...........................................................................................................................................................20
16.1 Runway leveling adjustment...........................................................................................................................20
16.2 Locking position adjustment..........................................................................................................................21
16.3 Accessory installation......................................................................................................................................21
16.4 Caster kit installation........................................................................................................................................21
17 Anchoring columns......................................................................................................................................................21
18 Check before start-up.................................................................................................................................................22
18.1 General checks...................................................................................................................................................22
18.2 Steel cable for proper installation.................................................................................................................22
18.3 Safety lock for proper installation.................................................................................................................22
18.4 Hydraulic system for proper operation........................................................................................................22
19 Check with load ...........................................................................................................................................................22
Operation and use.............................................................................................................................................................23
1 Controls of lift .................................................................................................................................................................23
1.1 Lifting......................................................................................................................................................................23
1.2 Standing .................................................................................................................................................................24
1.3 Lowering.................................................................................................................................................................24
2 Moving with caster kit ..............................................................................................................................................24
Maintenance........................................................................................................................................................................25
1 Ordinary maintenance...................................................................................................................................................25
2 Periodic maintenance....................................................................................................................................................25

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions



Troubleshooting.................................................................................................................................................................26
Parts list...............................................................................................................................................................................27
1 Explode drawing and parts list.....................................................................................................................................27
2 Transverse beam and parts list...................................................................................................................................29
3 Power-side runway and parts list................................................................................................................................31
4 Hydraulic line and parts list..........................................................................................................................................33
Special notes....................................................................................................................................................................34
1 Environmental damage...............................................................................................................................................34
2 Dismantling...................................................................................................................................................................34
3 Disposal........................................................................................................................................................................34
4 Noise declaration.........................................................................................................................................................35

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

Foreword

Notes on the operating instructions

The present ORIGINAL OPERATING INSTRUCTIONS are designed to provide sufficient instruction for the

safe operation of the product. The information is provided clearly and concisely. The chapters are arranged by

letter and the pages are numbered continuously.

Our products are subject to ongoing development. Our company reserves the right to alter the design,

equipment and technical features of the system. No guarantee of particular features of the product should

therefore be assumed from the present operating instructions.

Safety notices and text mark-ups

Safety instructions and important explanations are indicated by the following graphics:

Indicates an extremely hazardous situation. Failure to comply with this instruction will result in

severe irreparable injury and even death.

Indicates an extremely hazardous situation. Failure to comply with this instruction may result in

severe irreparable injury and even death.

Indicates a hazardous situation. Failure to comply with this instruction may result in

slight to medium injury.

Indicates a material hazard. Failure to comply with this instruction may result in material damage.

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

1. Packing, transport and storage

All packing, lifting, handling, transport and unpacking operations are to be performed exclusively by expert

personnel with knowledge of the lift and the contents of this manual.

1.1 Packing

The packing of the lift is delivered in following components:

•1 base unit packed in a steel frame, wrapped up in non-scratch material, including all the accessories.

•1 power unit packed in a carton box.

1.2 Transport

See Fig 1, packing can be lifted or moved by lift trucks, cranes or bridge cranes. In case of slinging, a second

person must always take care of the load, in order to avoid dangerous oscillations.

During loading and unloading operation, goods must be handled by vehicles or ships.

At the arrival of the goods, verify that all items specified in the delivery notes are included. In case of missing parts,

possible defects or damage due to transport operations.

If finding missing parts, possible defects or damage due to transport, one should examine damaged cartons

according to <<Packing List.>> to verify the condition of damaged goods and missing parts, also the person in

charge or the carrier must be immediately informed.

The machine is heavy goods! Don’t take manpower load and unload and transporting way into consideration, the

safety of working is important.

Furthermore, during loading and unloading operation goods must be handled as shown in the picture. (Fig 1)

Fig 1

1.3 Storage

The machine equipment should be stocked in the warehouse, if stocked outside should do the disposal well of

waterproof.

Use box truck in the process of transport, use container storage when shipping.

The control box should be placed perpendicularly during the transport; and prevent other goods from extrusion.

The temperature for machine storage: -10ºC -- 40ºC

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

2. Description of the machine

The lift is suitable for lifting motor vehicles having maximum weight as described in the nameplate on the power

side column of the lift. The electro hydraulic operation is described in detail in chapter 8.

This chapter describes the lift’s principal elements, allowing the user to be familiar with the machine. As shown in

figure 2, the lift is composed of four columns: 1 power-side column (1), 3 off-side columns (2), two platforms: the

power-side platform (3) and the off-side platform (4), and two transverse beams (5), anchored to the ground by

means of the column base plates.

Raising motion is carried out by pushing the lifting button on the power unit (6) to operate a power unit delivering

the hydraulic fluid to cylinders to act on cable lifting system. Lowering motion is controlled by pressing the lowering

lever on the power unit and carried out under the weight of the load lifted.

The automatic back-up lock holds on the lift in the elevated position, can be released by pressing the latch release

lever (7). The slack cable lock in each end of transverse beam can hold on the lift in event of cable slackening

and/or failure. The caster kit (8) can be ordered as an option to move the lift.

Fig. 2

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

3. Technical specifications

CAPACITY

8,000 lbs (3,600kg)

Max. lifting height with no pad extension

86 15/16”(2209mm)

Min. adaptor height

4 15/16” (125mm)

Overall height

96 1/16”(2440mm)

Overall width

113 3/4”(2890mm)

Lifting time

≤60

Lowering time

30-40

Noise level

＜85 dB(A)/1m

Working temperature

41°F - 104°F

Voltage

110V/60Hz/1PH

Power

2.2KW /3HP

Breaker

30A

Hydraulic Fluid Requirement

3-5 Gallons AW32/AW46

Average weight of package

1587 lbs (720kg)

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

Fig.5 Layout

Fig. 3

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

4. Safety

Read this chapter carefully and completely because it contains important information for the safety of the operator

and the person in charge of maintenance.

The lift has been designed and built for lifting vehicles and making them stand above level in a closed area,

any other use is forbidden.

The manufacturer is not liable for possible damages to people, vehicles, or objects resulting from an

improper or unauthorized use of the lift.

For operator and people safety, a safety area at least 3 feet away from the lift must be vacated during lifting and

lowering. The lift must be operated only from the operator’s control site in this safety area.

Operator’s presence under the vehicle, during working, is only admitted when the vehicle is lifted and the safety

lock is engaged.

Never use the lift when safety devices are off-line. People, the lift and the vehicles lifted can be seriously

damaged if these instructions are not followed.

4.1 General warnings

The operator and the person in charge of maintenance must follow accident-prevention laws and rules in force in

the country where the lift is installed.

Any use of the lift other than that herein specified can cause serious accidents to people in close proximity

of the machine.

They also must carry out the following:

•Neither remove nor disconnect hydraulic, electric or other safety devices;

•Carefully follow the safety indications applied on the machine and included in the manual;

•Observe the safety area during lifting;

•Be sure the motor of the vehicle is off, the gear engaged and the parking brake put on;

•Be sure only authorized vehicles are lifted without exceeding the maximum lifting capacity;

•Verify that no one is on the runways during lifting or standing.

4.2 Risks for people

All risks the personnel could run, due to an improper use of the lift, are described in this section.

4.3 Personnel crushing risks

During lowering of runways and vehicles, personnel must not be within the area covered by the lowering trajectory.

The operator must be sure no one is in danger before operating the lift.

Fig. 4

4.4 Risk of the vehicle falling from lift

Vehicle falling from the lift can be caused when the vehicle is improperly placed on platforms, and when its

dimensions are incompatible with the lift or by excessive movement of the vehicle.

In this case, keep immediately away from the working area.

STRATUS 4 post parking Lift Installation & Operation & Maintenance Instructions

Fig. 5

4.5 Slipping risks

The risk of slipping can be caused by oil or dirt on the floor near the lift.

Keep the area under and around the lift clean. Remove all oil spills.

4.6 Electrocution risks

Avoid use of water, steam, and solvent, varnish jets in the lift area where electric

cables are placed and, in particular, next to the electric panel.

Fig. 6

4.7 Risks resulting from improper lighting

Make sure all areas next to the lift are well and uniformly lit, according to local regulations.

4.8 Risks of breaking component during operation

Materials and procedures, suitable for the designed parameters of the lift, have been

used by the manufacturer to build a safe and reliable product. Operate the lift only for

the use it has been designed for and follow the maintenance schedule shown in the

chapter “Maintenance”.

Fig. 7

4.9 Risks for unauthorized uses

The presence of unauthorized persons next to the lift and on the platforms is strictly

forbidden during lifting as well as when the vehicle has been already lifted

Fig. 8

4.10 Risks during vehicle lifting and working

To avoid overloading and possible breaking during lifting and working, the following safety devices have been used:

•A pressure valve placed inside the hydraulic unit to prevent excessive weight.

•Automatic mechanical back-up safety holds on the lift in the elevated position.

•Slack safety in event of cable slackening and/or failure.

The maximum pressure valve has been preset by the manufacturer to a proper pressure. DO NOT try to

adjust it to overrun the rated lifting capacity.

It is strictly forbidden to modify any safety device. Always ensure the safety device for proper operation

during the service.

Table des matières

Autres manuels Stratus Système de levage

Stratus

Stratus SAE-P410 Manuel utilisateur

Stratus

Stratus SAE-C14X Mode d’emploi

Stratus

Stratus SAE-C9P Mode d’emploi

Stratus

Stratus SAE-C10C Mode d’emploi

Stratus

Stratus SAE-F12X Mode d’emploi

Stratus

Stratus SAE-UT9000 Mode d’emploi

Stratus

Stratus SAE-F10P Mode d’emploi

Stratus

Stratus SAE-F14X Mode d’emploi

Stratus

Stratus SAE-C12X Mode d’emploi

Stratus

Stratus SAE-C12XE Mode d’emploi

Stratus

Stratus SAE-C10XE Mode d’emploi

Stratus

Stratus SAE-UT8000 Mode d’emploi

Stratus

Stratus SAE-S66M Manuel utilisateur

Stratus

Stratus SAE-P166M Mode d’emploi

Stratus

Stratus SAE-F10S Instructions d'installation

Stratus

Stratus MS9000XT Manuel utilisateur

Stratus

Stratus SAE-C10P Mode d’emploi

Manuels Système de levage populaires d'autres marques

morse

morse 82H-124 Manuel utilisateur

Braun

Braun NL955 Series Manuel utilisateur

haacon

haacon 1889.10 Manuel utilisateur

Protekt

Protekt AT 252 Manuel utilisateur

R. Beck Maschinenbau

R. Beck Maschinenbau HS 600 Manuel utilisateur

Nova Technology International, LLC

Nova Technology International, LLC NAS Series Manuel utilisateur

Genie

Genie Z-60/34 Manuel utilisateur

Screen Technics

Screen Technics INTERFIT Vertical Up Lift Manuel utilisateur

Mortuary Lift

Mortuary Lift ULTIMATE 1000 Manuel utilisateur

Custom Equipment

Custom Equipment Hy-Brid 3 Series Manuel de programmation

Custom Equipment

Custom Equipment Hy-Brid Lifts 2 Series Manuel de programmation

Hy-Brid Lifts

Hy-Brid Lifts HB-P3.6 Manuel de programmation

BERG

BERG BeNomic EasyLeaf Manuel utilisateur

Powermate

Powermate LiftGate LG-3 Manuel utilisateur

Snorkel

Snorkel TM12 Series Manuel utilisateur

Terberg

Terberg OMNIDEKA Manuel utilisateur

Harmar Mobility

Harmar Mobility AL625 Mode d'emploi

Rotary

Rotary SPO16 Manuel utilisateur
