STEINEL IS 3180-24 Manuel utilisateur

110011484 11/2011 Technical changes subject to no prior notiﬁ cation.

STEINEL America Inc.

9O51 Lyndale Avenue South

USA - Bloomington, MN 55420

Tel: +1-952-888-5950

Fax: +1-952-888-5132

www.steinel.net

Installation Instructions

Commerical Occupancy Sensor

Consignes d'installation

Détecteur de présence à usage commercial

English

Français

Made in

Romania

RoHS

Compliant

IS 3180-24 IS 3360-24 IS 345-24

www.steinel.net (800) 852-4343

In this package

Ř IS 3180-24

occupancy sensor

Ř Accessory pack

containing: plastic

nipple, plastic

washer, lock nut,

lens cover

Ř Installation

instructions

Ř IS 345-24

occupancy sensor

Ř Accessory pack

containing: plastic

nipple, plastic

washer, lock nut,

lens cover

Ř Installation

instructions

Ř IS 3360-24

occupancy sensor

Ř Accessory pack

containing: plastic

nipple, plastic

washer, lock nut,

lens cover

Ř Installation

instructions

Installation Overview

WARNING

Ř Turn power off at the circuit breaker before installing the sensor

Ř Sensor must be installed and used in accordance with appropriate

electrical codes and regulations

Ř Installation by a qualiﬁed electrician is recommended

Intended uses

Ř Suitable for automatic

switching of lights

Environmental considerations

For indoor use only

Needed for installation

Ř Recommended wire: 18

AWG, 3 conductor

Ř For use with a STEINEL

power pack

IS 3180-24 IS 3360-24 IS 345-24

www.steinel.net (800) 852-4343

Product Overview

24VDC PIR

IP20

Product description

The IS 3180-24, IS 3360-24

and IS 345-24 are part of the

STEINEL family of German-

engineered, high performance

commercial occupancy

sensors. They provide

exceptional lighting control in a

wide range of building spaces.

The sensors turn lighting ON either

automatically with occupancy or

manually using a low voltage wall

switch and the manual on mode

of a STEINEL power pack. After a

period of time where no occupancy

has been detected, the sensors

switch lighting OFF.

Applications

Ř Wall or ceiling mount

applications where

180° coverage is

needed

Ř Classrooms, ofﬁces,

conference rooms

Ř Ceiling mount

coverage where aisle

way coverage is

needed

Ř Corridors

Ř Ceiling mount

applications where

360° coverage is

needed

Ř Open and cubicle

spaces

Ř Lobbies

IS 3180-24 IS 3360-24 IS 345-24

www.steinel.net (800) 852-4343

Product Overview

1 - Back housing

2 - Front housing

3 - Shroud

4 - Lens

5 - Decorative cover

6 - Light level setting

7 - Time delay setting

8 - Lock nut

9 - Washer

10 - Snap in threaded nipple

www.steinel.net (800) 852-4343

Speciﬁcations

Product Overview

24 VDC, 12 mA

Wall/ceiling mount

5 sec to 15 min

.2 - 200 fc

2 - 2000 lux

180° horizontal

90° vertical

up to 65 ft *T

up to 42 ft *R

448

IP20

-4°F to +122°F

-20° C to +50°C

3.74x3.74x2.56 in

9 5 x 9 5 x 6 5 m m

Voltage

Mounting

Time Delay

Light Level

Coverage

Detection

levels

Switching

zones

Environment

Dimensions

5 Year Warranty

UL and CUL Listed, RoHS Compliant

*T = tangential reach

*R = radial reach

24 VDC, 12 mA

Ceiling mount

5 sec to 15 min

.2 - 200 fc

2 - 2000 lux

360° horizontal

180° vertical

up to 130 ft *T

up to 25 ft *R

1416

IP20

-4°F to +122°F

-20° C to +50°C

3.74x3.74x2.56 in

9 5 x 9 5 x 6 5 m m

24 VDC, 12 mA

Ceiling mount

5 sec to 15 min

.2 - 200 fc

2 - 2000 lux

180° horizontal

45° vertical

65 x 13 ft *T

40 x 13 ft *R

280

IP20

-4°F to +122°F

-20° C to +50°C

3.74x3.74x2.56 in

9 5 x 9 5 x 6 5 m m

IS 3180-24 IS 3360-24 IS 345-24

www.steinel.net (800) 852-4343

Mounting

Placement guidelines

Ř Detection lens must have a

clear, unobstructed view of

the detection area; the sensor

does not detect from behind

obstacles, such as walls or

panes of glass

Ř Ideal mounting height is 8-12

feet

Ř The site of installation should

be at least 20 inches away

from another light because

heat radiated from it may

activate the system

Ř An optional corner wall mount

(product no. 648015 black or

648114 white) is available for

installing the IS 3180-24 in

corners.

IS 3360-24 IS 345-24

IS 3180-24

www.steinel.net (800) 852-4343

Installation

Installation - wall or ceiling

mount with screws

Ř Conﬁrm power is off at the

circuit breaker

Ř Install power pack and run

low voltage wire to the sensor

location

Ř Remove the decorative cover

Ř Remove the screws securing

the front and back housings

Ř Separate the top housing from

the back housing

Ř Fasten the back housing to

the wall with screws through

the pre-punched holes (60 mm

or 2 3/8 in apart)

Ř Connect wiring

Ř Reattach the front housing to

the back housing and secure

with screws

Ř Snap the decorative cover back

in place

wires 200 mm

www.steinel.net (800) 852-4343

Installation

Installation - ceiling mount

with threaded nipple

Ř Conﬁrm power is off at the

circuit breaker

Ř Install power pack and

run low voltage wire to the

sensor location

Ř Run low voltage wires from

the sensor through the

provided threaded nipple and

snap threaded nipple in back

of sensor

Ř Cut 7/8” hold in ceiling tile

Ř Place threaded nipple

through hole in ceiling tile,

add washer and secure with

locknut

Ř Wire sensor to STEINEL

power pack

Ceiling Tile Washer

Locknut

Sensor

Threaded Nipple

Ceiling Tile

Locknut

Washer

Sensor

www.steinel.net (800) 852-4343

Operation

The IS 3180-24, IS 3360-24 and

IS 345-24 work with a STEINEL

power pack to control lighting

based on occupancy and daylight.

Manual operation

A line voltage or low voltage

switch may be used for manual off

control when the power pack is in

automatic on mode.

For manual on only operation, a

low voltage momentary switch is

required along with a STEINEL

power pack set in manual on

mode.

Light level function

The sensors incorporate a built-in

light level sensor which keeps

lighting off during daylight hours,

regardless of occupancy.
