STATESMAN BU60LF Manuel de référence

BU60LF

Built-under Fridge

Manual for Installation , Use and Maintenance

Before ﬁrst use

You must allow the fridge to settle for at least twenty four hours prior to switching the power on.

It is recommended that you clean the interior of the appliance prior to ﬁrst use, using a solution of bicarbonate of soda

and warm water and then thoroughly drying the interior.

The fridge may have an odour to it at ﬁrst use. This will disappear as the appliance cools.

Please note:

• The appliance will work continuously until it gets down to the correct temperature.

• If the appliance is switched off, you should allow ﬁve minutes before switching it on again to prevent unnecessary

damage to the compressor.

Defrosting the fridge

The fridge is self-defrosting. Any water created will run out of the fridge through the channel at the back of the fridge.

It is important to keep the channel clear at all times. The defrosted water is collected in the evaporating tray at the back

of the appliance.

Use

• Never put liquids in the refrigerator uncovered.

• Never put hot foods in the refrigerator. Warm food should be allowed to cool to room temperature before being

put into the refrigerator.

• Nothing should rest against the internal rear wall of the refrigerator, as this will cause frost and possible

condensation problems which will be difﬁcult to remove.

Setting the temperature

You must allow the fridge to settle for at least twenty four hours prior to switching the power on.

To adjust the temperature turn the thermostat control knob clockwise (from off) to the required level. The temperature

becomes colder the higher the number on the control.

FF221 Fridge Freezer Manual.indd 3 28/4/09 17:00:43

Care and cleaning

Always disconnect the appliance from the power before any cleaning or maintenance.

• The refrigerator section should be cleaned using a solution of bicarbonate of soda and lukewarm water.

• Do not use abrasive products or detergents. After washing, rinse and dry thoroughly.

• Clean the shelves and balconies separately by hand using soap and water. Do not put them in the dishwasher.

• The evaporating tray and water drain hole (at the back of the refrigerator compartment) should be cleaned

periodically to prevent the defrosted water from collecting inside the refrigerator compartment. The drain

plug can be used to clear the drain hole.

• Once cleaning is complete, reconnect the mains power supply.

• If the appliance is not used for prolonged periods of time, unplug and clean the appliance. The doors should be left

slightly open to prevent the formation of mildew and smell.

Changing the light bulb

Disconnect the appliance from the power.

• Remove the light cover.

• Unscrew the light bulb to remove it and replace with a new bulb (not more than 15W).

• Replace the light cover and reconnect the power after ﬁve minutes’ delay as explained on page 3.

FF221 Fridge Freezer Manual.indd 4 28/4/09 17:00:43

Troubleshooting

If you have any problems with your appliance, you should check the troubleshooting prior to calling Customer Care

to prevent unnecessary service calls and potential cost.

If the appliance is not working

•Checkthere is power to the appliance:

•The house fuses are intact and the fuse in the plug has not blown.

•The thermostat is not set to 0 (off position).

•The plug socket is functioning ﬁne. To check this, plug another electrical appliance in to see if the socket is working.

•The temperature of the room is adequate (10 o

C or above).

The appliance is working, but not very well

•The appliance is not overloaded.

•The thermostat is set to an appropriate temperature.

•The door is closing properly.

•The cooling system at the rear of the appliance is clean and free of dust, and not touching the rear wall.

•There is enough ventilation at the side and rear walls.

•The temperature of the room is adequate (10o

C or above).

The appliance is noisy

•The appliance is level and stable.

•The side and rear walls are clear, and there is nothing resting on the appliance.

•The cooling gas in the refrigerator will make a slight bubbling noise, even when the compressor is not running.

There is water in the lower part of the refrigerator compartment

•The drain hole in the channel at the back of the compartment is clear.

Installation

This appliance must never be installed close to heat sources i.e. heating elements, cookers or in damp places

The appliance should be mounted on a piece of wood (for example a section of worktop or kitchen carcass) if a

raised ﬂoor is to be ﬁtted, if the kitchen ﬂoor is to be tiled after installation, or if the installation height of the

appliance is greater than 850 mm.

Fig. 1 - Dimensions of the appliance.

Fig. 2 - Dimensions for installation in

adjacent units.

Instructions for fitting the refrigerator in

Fig.A-Volume of the under the counter ap-

pliance

Fig.A1-Volume of the under the counter

appliance in the event of adjacent

Instructions for fitting the refrigerator in

Fig.A-Volume of the under the counter ap-

pliance

Fig.A1-Volume of the under the counter

appliance in the event of adjacent

ﬁg. 1

ﬁg. 2

FF221 Fridge Freezer Manual.indd 6 28/4/09 17:00:43

Reversing the door

It is possible to reverse the door on this appliance, if required.

To do so, follow the steps below:

• Loosen the hinge ﬁxing screws (1).

• Open the door.

• Lever off the corner caps (3) with a knife blade.

• Insert the hinge ﬁxing screws (1) on the opposite side.

• Remove the door ﬁxing screws (2) and relocate the hinges

according to ﬁgure 3.

• Locate the door on the hinge ﬁxing screws (1) and tighten.

Do not turn the door upside down.

• Insert the corner caps (3) in the exposed holes.

ﬁg. 3

FF221 Fridge Freezer Manual.indd 7 28/4/09 17:00:44

Installing the decor door

• Screw mounting bracket (1) onto decor door using the

screws supplied (as show in ﬁgure 4).

• Fit the correct side towards the hinges.

• Ensure there is a 5mm clearance between

the underside of the worktop and upper edge (X) of the

decor panel.

• Screw the four adjusting pins (2) fully into the

appliance door.

• Position the decor door on the appliance

door, introduce the locating pins at top into the

slots in the mounting plate and open out

according to detail in ﬁgure 5 (about 9mm).

ﬁg. 4

ﬁg. 5

FF221 Fridge Freezer Manual.indd 8 28/4/09 17:00:44

Installing under a worktop

• Adjust the feet to the required height.

• Push the appliance into the niche until the decor door

is ﬂush with the adjacent furniture items, adjust the

feet if necessary.

• Pre-adjust the appliance at slots (4) as shown in ﬁgure 8,

into the mounting plate on the worktop.

Adjusting the plinth depth (ﬁgure 6)

• Lift out the decor door.

• Grip the plinth at the ventilation grille and align until

ﬂush with adjacent furniture items, or join up to the

continuous plinth if ﬁtted. Cut away the continuous plinth

trim as illustrated for ventilation.

Never cover over the ventilation slots.

Once installed the plinth must not block the

ventilation slots in the appliance. This may require

cutting the plinth down. Failure to ensure adequate

ventilation may invalidate the warranty.

• Attach the appliance plinth at screws (5),

turning screws clockwise until considerable resistance

is felt (ﬁgure 7).

• To adjust the plinth height, turn the screws anti-clockwise

through approximately 8 to 10 revolutions.

Adjusting the decor door

• Position the decor door on the appliance. Open loose

locking nuts.

• Adjust height Y at locating pin (14mm wrench) as shown in

ﬁgure 8, Y=max +/- 3.5mm.

• Adjust side measurement X at slots on mounting bracket at

top, X=max, +/- 3mm.

• Open out lower locating pins until contact is made with the

mounting plate. Secure with locking nuts.

• If necessary, adjust the alignment of the lower decor panel

edge at 10x12 hole in mounting bracket, Z= +/- 2MM.

Then tighten the locking nuts again.

• Push on cover trim (6) and engage (to remove, lever out

the trim strip with a screwdriver as illustrated in ﬁgure 9).

• When aligned, secure the appliance to the worktop at

retaining slots.

Important: The cover trim (6) must be ﬁtted as this

turns off the light when the door is closed.

ﬁg. 6

ﬁg. 7

ﬁg. 8

ﬁg. 9

FF221 Fridge Freezer Manual.indd 9 28/4/09 17:00:45

Electrical information

Warning! This appliance must be earthed.

The mains lead of this appliance has been ﬁtted with a BS 1363A 13 amp fused plug. To change a fuse in this type of plug,

follow the steps below:

1. Remove the fuse cover and fuse.

2. Fit replacement 13A fuse, ASTA approved to BS 1362 type, into the fuse cover.

3. Replace fuse cover.

Important: Do not use the appliance without the fuse cover in position.

How to connect an alternative plug

If the ﬁtted plug is not suitable for your socket outlet, then it should be cut off and disposed of safely to avoid possible shock

hazard. A suitable alternative plug of at least 13 Amp rating to BS 1363 should be used.

As the colours of the wires in the mains lead of this appliance may not correspond with the

coloured markings identifying the terminals in your plug, proceed as follows:-

• The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with letter (E) or

by the Earth symbol or coloured GREEN and YELLOW.

• The wire which is coloured BLUE must be connected to the terminal which is marked with the letter (N), or

coloured BLACK.

• The wire which is coloured BROWN must be connected to the terminal which is marked with the letter (L) or

coloured RED.

If in doubt regarding the electrical connection of this appliance, consult a qualiﬁed electrician. Do not shorten the

supply cable, the appliance may require removing for servicing.

N.B. Ensure that the plug socket is situated in an easily accessible place.

FF221 Fridge Freezer Manual.indd 10 28/4/09 17:00:46
