StarTech.com ATXPW400DELL Manuel du système

400 Watt ATX12V 2.01 Dell Replacement Computer PC Power Supply

StarTech ID: ATXPW400DELL

This 400 Watt ATX12V 2.01 Dell PC Power Supply is a reliable upgrade or replacement for many compatible Dell

computers (see compatible models below). It offers dual 12V power rails to deliver stable power to demanding

components, as well as both 20 and 24-pin ATX motherboard power connectors and a generous number of

component connectors to ensure broad system compatibility.

Constructed of high quality components and designed to provide a long-lasting, durable power source for hard-

working PCs, the 400 Watt ATX12V 2.01 Dell PC Power Supply is backed by StarTech.com's 2 year warranty and

free lifetime technical support.

The 400 Watt ATX12V 2.01 Dell PC Power Supply is compatible with standard ATX style versions of

following:

Dimension Series Models: 1100 / 2200 / 2300 / 2350 / 2400 / 4300 / 4400 / 4500 / 4550 / 4600 / 8200 / 8250 /

8300 / 8400 / B100

Optiplex Series Models: 170L / GX60 / GX150 / GX240 / GX260 / GX270

Power Edge Series Models: 400SC / 600SC

Precision Workstation Series Model: Model 340 / 350

Smart Step Series Models: 100D / 150D

Applications

Replacement 400W power supply, compatible with many standard Dell ATX PC's (see model list on

Overview page)

Upgrade current Dell power supply for more power and support of upgraded 24-pin motherboards, SATA

hard drives and PCI-E graphic card

Features

ATX12V version 2.01 compliant

EMI/RFI power filtration system provides low noise/ripple for super clean and stable power to all system

components

80mm fan provides efficient cooling for the system and the power supply

High quality connectors provide minimal resistance and enhanced electric conductivity

Our power supplies are compatible with many of latest Intel P4 and AMD processors

PCI Express Connector for next generation video cards

20/24 split motherboard connector

SATA connectors for SATA Hard Drive support

Technical Specifications

Warranty 2 Years

Fans 1 - 80 mm

Fan Bearing Type Sleeve Bearing

Output Connectors 1 - ATX 12V P4 Power (4 pin; v 2.x) Female

Output Connectors 1 - ATX Split Power (20+4 pin; v 2.x) Male

Output Connectors 1 - PCI Express Power (6 pin; v 1.x) Female

Output Connectors 2 - SP4 (4 pin; Small Drive Power) Female

Output Connectors 4 - LP4 (4 pin; Molex Large Drive Power) Female

Output Connectors 4 - SATA Power (15 pin) Receptacle

Air Flow Rate 32.3 CFM

Output Power 400W

Power Factor Correction No

MTBF 100,000 Hours

Enclosure Type Zinc-Plated Casing

Product Length 5.5 in [140 mm]

Product Width 5.9 in [150 mm]

Product Height 3.4 in [86 mm]

Product Weight 4.8 lb [2.1 kg]

Input Voltage Frequency 50~60 Hz

Current -12.0V (A) 1A

Current +12.0V1 (A) 14A

Current +12.0V2 (A) 15A

Current +3.3V (A) 30A

Current +5.0V (A) 28A

Current +5.0Vsb (A) 2.5A

Input Voltage 115 ~ 230

Input Current 8 ~ 4

Operating Temperature 0° ~ 50°

Storage Temperature -20° ~ 80°

Shipping (Package) Weight 4.9 lb [2.2 kg]

Included in Package 1 - 400W ATX Dell Power Supply

Included in Package 1 - Power Cord (NA)

Included in Package 1 - Instruction Manual
