VID2VGATV

VID2DVIDTV

Composite and S-Video to VGA Video Converter

Composite and S-Video to DVI Video Converter

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction .......................................................................................................................................................1

Features .................................................................................................................................................................1

Before You Begin..............................................................................................................................................1

Package Contents.....................................................................................................................................1

Site Preparation..........................................................................................................................................1

Connecting Devices to the Video Scaler...........................................................................................2

Using the Manu Options ............................................................................................................................3

Selecting a video source ......................................................................................................................3

Using the menu system........................................................................................................................3

Troubleshooting...............................................................................................................................................5

Specications.....................................................................................................................................................6

Supported Video Output Modes...........................................................................................................7

Technical Support...........................................................................................................................................8

Warranty Information....................................................................................................................................8

Instruction Manual 1

Introduction

Thank you for purchasing a StarTech.com video scaler. This device is designed to convert the

output from a video source (DVD, video game console, VCR) and scale it for output to high-

denition displays--including plasma TVs and LCD monitors--while maintaining the clarity of

the image.

Features

• Get the most out of your existing video equipment by maximizing its performance on a

high-denition display.

• Easy to use interface gets you up and running in minutes.

• Supports common video input standards, including NTSC and PAL.

• Adaptive digital comb lter, high-speed algorithms, and vertical temporal lter combine to

provide crystal-clear output with virtually no de-interlacing artifacts.

• Choose between two models depending on your display: VGA (VID2VGATV) or

DVI (VID2DVIDTV).

Before You Begin

Package Contents

• 1 x Video Scaler Unit (VGA Output: VID2VGATV DVI Output: VID2DVIDTV)

• 1 x RCA Video Cable

• 1 x YCbCr RCA to 8-pin DIN converter

• 1 x HD-15 male/male VGA cable (VID2VGATV only)

• 1 x HD-15 male to YPbPr 3-prong RCA cable (VID2VGATV only)

• 1 x DVI-D male/male DVI cable (VID2DVIDTV only)

• 1 x AC Power Adapter

• 1 x User Manual

Site Preparation

Ensure you have the necessary cables to connect your video source (such as a DVD player) to the

video scaler. Note that if you have previously used the device with a standard television, you can

most likely use those cables to connect the item to the video scaler. The video scaler should be

in close proximity to the video source and be connected using high-quality cables for the best

possible results.

Need more cables? Contact your dealer or visit www.startech.com for more information.

Instruction Manual 2

Connecting Devices to the Video Scaler

1. Disconnect your high-resolution display from its existing video connection.

2. Disconnect your video source (i.e. DVD player) from its existing video connection.

3. Place the video scaler near the video source and connect the power adapter to a suitable wall

outlet. Connect the opposite end to the DC 5V connector on the rear of the video scaler.

4. Connect the cable you used to connect your video source to its previous video display

(usually labeled as VIDEO OUT, or similar) as removed in step 2 to the YCbCr IN, SV IN, or CV IN

connector on the rear of the video scaler as appropriate. The connector you use will depend

on the type of cable the video source uses. If your device uses a YCbCr cable, you will need to

use the provided adapter to convert the connectors to the 8-pin DIN connector on the YCbCr

IN port on the video scaler.

5. Using the provided HD-15 male/male VGA cable, connect one end to the PC/HD OUTPUT

port on the front panel of the video scaler.

6. Connect the opposite end of the VGA cable to the VIDEO IN (or similar) connector that you

removed in step 1.

7. Using the provided DVI-D male/male cable, connect one end to the DVI OUT port on the front

panel of the video scaler.

8. Connect the opposite end of the DVI cable to the VIDEO IN (or similar) connector that you

removed in step 1.

If you are using the VGA model (VID2VGATV):

If you are using the DVI model (VID2DVIDTV):

Rear Panel (VID2VGATV)

Rear Panel (VID2DVIDTV)

Front Panel (VID2VGATV)

Front Panel (VID2DVIDTV)

Instruction Manual 3

Using the Menu Options

The video scaler uses an intuitive on-screen display (OSD) system that allows you to ne-tune the

video output to the display you are using.

Selecting a video source

By default, the video scaler selects an output setting of XGA (1024 x 768 pixels, 60 Hz). While this

setting should display an image on most computer monitors, high-denition televisions often

support a dierent set of resolutions. The video scaler automatically detects and adjusts to NTSC

(North America) or PAL (Europe and elsewhere) inputs For easy setup, the video scaler supports a

combination-key setting that can allow you set the unit to a widely-supported output resolution

so that the OSD will be visible on your display:

For computer monitors: Press + and - at the same time to force the unit to XGA.

For HD televisions: Press MENU and - at the same time to force the unit to 480p.

1. After you have connected the video source and display to the video scaler using the

directions in the previous section, power on both the device and the display.

2. The display should show a bright-blue screen. Be sure that the video source is sending a

video signal to the video scaler (i.e. for a DVD player, insert a disc) for testing purposes.

3. Press the INPUT button on the front of the video scaler. The on-screen display (OSD) will

show which connection is active in the upper righthand corner of the screen. Press INPUT

repeatedly until the OSD matches the input you are using on the rear panel of the video

scaler. This is the correlation between menu settings and input connectors:

YCbCr: YCbCr IN

RBgS: YCbCr IN

S-Video: SV IN

Composite: CV IN

NOTE: RBgS is a type of composite video that carries a specic signal on the green channel.

Consult the documentation of the video source to determine if you need to use this option.

4. Once the correct signal source is selected, the device will display the image source on the

screen. Depending on the requirements of the high-denition display, you may need to

adjust the output settings on the video scaler for best image quality. See the instructions

below for more information.

Instruction Manual 4

Using the menu system

The video scaler automatically interprets the input resolution and scales it to the output

resolution selected in the menu system. While the default settings will provide an image, the

video scaler oers several settings that will allow you to adjust the output signal for the best

possible result.

NOTE: Changing the settings below may cause the signal to become unusable if the settings you

select are incompatible with your display. Should this occur, repeat the steps you followed under

“Selecting a video source” to reset the video scaler back to a compatible setting.

To activate the menu system, press the MENU key on the front of the video scaler once. The OSD

will display the available option on the lefthand side of the screen. To navigate the menu system:

1. Use the + and - keys on the front of the video scaler to movebetween options.

2. Use the MENU key to select an item to adjust or display a sub-menu.

3. Once an item is selected, use the + and - keys to adjust the setting.

4. When you are satised with your changes, press MENU to activate the setting.

5. You can continue to adjust other settings, or select Exit from the OSD menus until the OSD

disappears.

The following options can be adjusted from the OSD menu system:

Picture Adjust

Brightness

Contrast

Color

Tint

H. peaking lter

Sharpness

V. peaking gain

Reset

Exit

Display

Timing

C S C (RGBH/YPbPr)

Advanced

Film Mode (Auto/OFF)

OSD Display (ON/OFF)

No Signal (Blue/Black)

System Information

INPUT Mode

Display Timing

The video scaler will store your changes until it is reset to a default setting.

Instruction Manual 5

NOTE: The System Information OSD menu does not allow you to modify any settings and shows

the current state of the video scaler settings.

NOTE: The Timing option under the Display menu allows you to adjust the output resolution and

frequency of the video scaler. You should exercise caution in adjusting this setting, since a setting

that exceeds the capabilities of your display could cause damage in some situations. Consult the

documentation for your display to determine if the setting you wish to use is supported.

Troubleshooting

Problem: I can’t see an image from the video source or the OSD.

Cause: The input setting or output timing (resolution and refresh rate) is incorrect.

Resolution:

a) Adjust the settings back to the default setting for your display type (see page 4) and reselect

the input type as necessary.

b) Ensure all cables are securely connected in the proper connectors.

Problem: The image is distorted or blurry.

Cause: The output timing settings/image quality settings are not optimized, or there is

interference degrading the cable signal.

Resolution:

a) Adjust the timing settings and image settings using the menu system to improve image

quality and ensure the video source is working normally.

b) Use the shortest cable length possible, and ensure that they are of a high quality. Heavily-

shielded cables with gold-plated connectors oer superior performance and signal protection.

Do not use converters or extension cables unless they were supplied with the video scaler.

Instruction Manual 6

Specications

VID2VGATV VID2DVIDTV

Input Signal Levels Video @ 1V p-p, 75 ohm, Y @ 1V p-p, 75ohm

Color @ 0.7V p-p, 75 ohm, YCbCr, RGBH

Output Format YPbPr / HDTV RGBHV

Output Connector HD15 female 29-pin D-Shell

Output Signal RGB @ 0.7v p-p, H&V Sync @ 3V p-p,

Y @ 1V p-p, Pb, Pr @ 0.7V p-p, 75 ohm

Digital

Weight 8.5 oz. (240 g) 9.5 oz. (270 g)

Dimensions 5.7 x 3.0 x 1.2 in.

146 x 77 x 30 mm

6.3 x 3.0 x 1.2 in.

161 x 77 x 30 mm

Power Source 5VDC, 2A

Instruction Manual 7

PC Resotultions Vert Rate Format Scan Type

VGA 640 x 480

SVGA 800 x 600

XGA 1024 x 768

WXGA 1280 x 768

SXGA 1280 x 1024

50/60/72/75/85 Hz.

50/56/60/72/75/85 Hz.

50/60/70/75/85 Hz.

50/60 Hz.

RGBHV

Progressive

HDTV Resolutions Vert Rate Format Scan Type

480p 720 x 480

576p 720 x 756

720p 1280 x 720

1080i 1920 x 1080

50/60 Hz.

YPbPr, RGBHV

Progressive

Pseudo Interlace

Supported Video Output Modes

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels StarTech.com Convertisseur de média

StarTech.com

StarTech.com ST124HD202 Manuel utilisateur

StarTech.com

StarTech.com VGA2HDMIPRO Manuel utilisateur

StarTech.com

StarTech.com SPDIFCOAXTOS Manuel utilisateur

StarTech.com

StarTech.com ICUSBAUDIO Manuel du système

StarTech.com

StarTech.com CONVERGEAV CPNTA2HDMI Manuel utilisateur

StarTech.com

StarTech.com MDP2DVID Manuel utilisateur

StarTech.com

StarTech.com ET91000LC Manuel du système

StarTech.com

StarTech.com MCM10GSFP Manuel utilisateur

StarTech.com

StarTech.com SDI2HD Manuel utilisateur

StarTech.com

StarTech.com VGA2VID Manuel utilisateur

StarTech.com

StarTech.com MCS110SC20 Manuel utilisateur

StarTech.com

StarTech.com VGA2HDMIPRO Manuel utilisateur

StarTech.com

StarTech.com USB32DVCAPRO Manuel utilisateur

StarTech.com

StarTech.com USB3HDCAP Manuel utilisateur

StarTech.com

StarTech.com 25SAT35HDD Manuel utilisateur

StarTech.com

StarTech.com VID2VGATV3 Manuel utilisateur

StarTech.com

StarTech.com 8STMCM10GSFP Manuel utilisateur

StarTech.com

StarTech.com ET90110ST Manuel du système

StarTech.com

StarTech.com 8ST25SAT22MSAT Manuel utilisateur

StarTech.com

StarTech.com 8STET91000SFP2C Manuel utilisateur

StarTech.com

StarTech.com MMC110MMST Manuel utilisateur

StarTech.com

StarTech.com HD2VID2 Manuel utilisateur

StarTech.com

StarTech.com DVI2DVI Manuel utilisateur

StarTech.com

StarTech.com ET90110WDM2 Manuel utilisateur

Manuels Convertisseur de média populaires d'autres marques

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuel utilisateur

SPROLINK

SPROLINK VA1 Manuel utilisateur

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuel utilisateur

Nikon

Nikon AF-S TC-20E III Manuel utilisateur

Axis

Axis AXIS Q7406 Manuel utilisateur

Omega

Omega TAC80B-J Manuel utilisateur

Zoom

Zoom Thunderbolt TAC-2R Manuel utilisateur

OST

OST iConverter 10/100M Manuel utilisateur

Vertiv

Vertiv Netsure Manuel utilisateur

birddog

birddog MINI Manuel utilisateur

Roland

Roland GI-10 Manuel utilisateur

Wallenstein

Wallenstein WX310 Manuel utilisateur

Pace

Pace MSS 200-1 Manuel utilisateur

Solar Converters

Solar Converters EQ 12/24-50 Manuel utilisateur

CYP

CYP EL-7400V Manuel utilisateur

TIE

TIE MIDI 1i1o Manuel utilisateur

DCS

DCS Vivaldi Upsampler Manuel utilisateur

Westermo

Westermo MCW-211 SERIES Manuel utilisateur
