StarTech.com 35FCREAD20 Manuel utilisateur

USB 2.0 Flash Card Reader

35FCREAD20

35FCREAD20BK

Instruction Manual

Actual product may vary from photo

3.5” Multi-Flash Card Reader

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Panel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Using Your Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Inserting a Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Removing a Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Permanently removing the Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com 3.5” Multi-Flash Card Reader. This panel

works with a wide variety of flash cards (see Features for detailed compatibility list) and

can be installed in an open 3.5” bay or used as a standalone. The card reader plugs into

any USB port and makes it easy to transfer files, images, and music between your

computer and your MP3 player, digital camera, cell phone, or PDA.

FFeeaattuurreess

• Supports the following types of flash cards: Compact Flash Type I, Compact Flash

Type II, MicroDrive, MultiMedia Card (MMC), Reduced Size Multimedia Card (RS-

MMC), Memory Stick, Memory Stick Pro, Memory Stick Duo, Memory Stick Pro Duo,

Secure Digital card (SD), Mini Secure Digital card (mini-SD), SmartMedia card (SM),

• Can be used as a standalone or a 3.5” front panel USB 2.0 multi card reader.

• Provides an activity and status LED for each of the four card slots.

• Compliant with USB 2.0 to support transfer rates of 480Mbps

• Powered by USB for use as a standalone card reader

• Supports drag and drop between cards

• Fits into any 3.5” drive bay

BBeeffoorreeYYoouuBBeeggiinn

To ensure a quick and easy installation, please read through this section carefully before

attempting to install the Flash Card Reader.

WARNING! Flash cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your card. StarTech.com recommends that you wear an anti-static strap when

installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds.

System Requirements

• Windows 98SE (or higher) with a Pentium-class (or compatible) processor, or Mac

OS X with a Power PC (or above).

• A CD drive

• An available USB port

Instruction Manual

Contents

• 1 x Multi-Card Reader

• 1 x User Manual

• 1 x USB Type A to B cable (for Standalone use)

• 1 x USB Type B to motherboard header cable

• Four Screws

• Four Rubber Pads

IInnssttaallllaattiioonn

Panel Installation

Note: The instructions below outline how to install the card reader into a 3.5” drive bay.

Alternatively, you can use your card reader externally by plugging the USB cable into an

open USB port.

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system and remove the cover from a 3.5” drive bay (see

your computer’s user manual for details, if necessary).

3. Gently insert the panel into the open 3.5” bay (after threading the attached USB

cable into the computer) until it is flush with the front of the case. Make sure the

bracket is lined up with the screwholes in the case, and screw the panel into place.

4. Connect the reader to the mainboard, using the 1 x 4 pin header to USB Type ‘B’

cable. Based on the following table, please ensure that the pin assignments are

correct:

5. Replace the cover on the computer.

6. Your computer will display a message saying new hardware has been found.

Windows 98SE and 2000 users follow the on-screen prompts and direct Windows

to the appropriate folder on the driver disk. Windows will install the necessary drivers.

Instruction Manual

Pin 1 (Red) Pin 2 (White) Pin 3 (Green) Pin 4 (Black)

USB 5V DATA- DATA+ GND

UUssiinnggYYoouurrCCaarrddRReeaaddeerr

The following table illustrates the designation for each card port on the reader. Be sure

to use the correct slot as indicated, to avoid damaging your Flash Cards or the data that

they contain:

Inserting a Card

1. Turn on your computer.

2. Insert your memory card into the proper slot on the card reader, with the top of the

card facing upwards..

3. Mac users: A new icon will appear on your desktop.

Windows users: A new icon will appear in “My Computer.”

4. The card can now be accessed as an extra disk.

LED Indicators

The LEDs on the card reader are your best indication of the reader’s activity. The red

light indicates whether or not your card reader is receiving power. Each card slot has a

corresponding LED as indicated by the designated letters for each slot.

A solid green light, indicates that a card is detected in the corresponding slot.

A flashing green light indicates that data is being accessed from the card in the

corresponding slot.

Removing a Card

1. Make sure that none of the LEDs on the front of the card reader are flashing. If you

remove the card when the LEDs are flashing, data may be lost from your card.

2. Mac users: drag the memory card icon to the Trash bin.

Windows users: right-click on the drive icon and choose to eject the card.

3. Physically remove the card from the reader.

Permanently removing the Card Reader

Use this procedure to permanently uninstall the card reader.

Instruction Manual

SLOT A SLOT B SLOT C SLOT D

SMC/Others CF/MD/Others SD/MMC/Others MS/MSPro/Others

Windows users:

1. Make sure there is no card reader connected to the USB port.

2. Click on the “Uninstaller” icon in the taskbar.

3. Click on “USB Storage Device - Change/Remove.”

4. Remove all installed components and click Next.

5. Choose to restart your computer and click Finish.

Mac users:

1. If there is a memory card connected to the card reader, drag the memory card icon

into the Trash. Wait until the icon has disappeared.

2. Disconnect the card reader.

TTrroouubblleesshhoooottiinngg

The card reader is not detected

The reader has not been properly connected or is not receiving enough power. Make

sure that the reader’s USB cable is firmly seated in the USB port. If you are connecting

the card reader to a hub, make sure that it is a powered hub.

The card doesn’t fit in the reader

Make sure you are installing the card in the proper slot and that the card is facing the

right direction. Check with the card manufacturer’s instructions.

A drive letter is shown for the card, but it can’t be accessed

The card has not been formatted or is formatted incorrectly. Follow the instructions

provided by the manufacturer of your digital media device (i.e. Your MP3 player, digital

camer, etc.) to format the card using your digital media device.

No icon appears when a card is inserted into the reader (Mac OS X)

The card may have been formatted in Windows’ FAT-32 format. Using a PC or digital

device, re-format the card using the OS X compatible FAT or FAT-16 format.

Instruction Manual

TTeecchhnniiccaallSSppeecciiffiiccaattiioonnss

USB Ports 1 x 4 pin USB (Type A)

Standards USB 2.0

Data Transfer Rate USB 2.0 devices: Up to 480 Mbits/sec

USB 1.1 devices: Up to 12 Mbits/sec

Flash Cards: 700 Kbits/sec to 480 Mbits/Sec

SATA devices: 150 Mbits/sec

Firewire devices: 400 Mbits/sec

Compatibility CF Slot: CF I, II, CF Ultra (high speed), IBM MicroDrive,

Magicstor MD.

SD Slot: Secure Digital Card, SD Ultra (high speed), Mini SD

(adapter needed), MMC, MMC 2.0, MMC 4.0, RS-MMC, T-flash

adapter needed.

SM Slot: Smart Media Card, SM-ROM.

MS Slot: Memory Stick, Magic Gate, MS Pro, MS Ultra II, MS

Select, MS Duo, MS Pro Duo, Magic Gate Duo, MS Duo Magic

Gate (These six require an adapter)

LED Indicators Power & Activity

System

Requirements

An available 3.5” bay, Windows 98SE or higher, or Mac OS X

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

139466EXT6

6 ft. i.Link IEEE-1394 FireWire Extension Cable 6 to 6 pin M/F

1394_10

10 Ft IEEE-1394 Firewire Cable 6-6 M/M

139444EXT6

6 ft. IEEE-1394 FireWire Extension Cable 4 to 4 pin M/F

USBEXTAA_6

6 ft. Fully Rated USB Extension Cable A-A

USB2FAAEXT15

16 Foot (5 Meter) USB 2.0 Active Extension Cable

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Autres manuels pour 35FCREAD20

Ce manuel convient aux modèles suivants

Autres manuels StarTech.com Lecteur de cartes

StarTech.com

StarTech.com 35FCREADBK2 Manuel du système

StarTech.com

StarTech.com 35FCREAD Manuel du système

StarTech.com

StarTech.com FCREADU2OTGB Manuel utilisateur

StarTech.com

StarTech.com HB30A4AIB Manuel utilisateur

StarTech.com

StarTech.com 525FCREADAL Manuel du système

StarTech.com

StarTech.com 35FCREADBK2 Manuel utilisateur

StarTech.com

StarTech.com 52535FCREADB Manuel utilisateur

StarTech.com

StarTech.com 35FCREAD20BK Manuel du système

StarTech.com

StarTech.com FCREADHC Manuel utilisateur

StarTech.com

StarTech.com FCREADMINI Manuel

StarTech.com

StarTech.com 525FCREAD Manuel du système

StarTech.com

StarTech.com FCREADMICRO Manuel utilisateur

StarTech.com

StarTech.com 4SD4FCRU31C Manuel utilisateur

StarTech.com

StarTech.com 2SD4FCRU3C Manuel utilisateur

StarTech.com

StarTech.com 35FCREADREM Manuel du système

StarTech.com

StarTech.com 35FCREADAL Manuel du système

StarTech.com

StarTech.com 35FCREAD Manuel

StarTech.com

StarTech.com 35FCREADREM Manuel

StarTech.com

StarTech.com FCREADU3HC Manuel utilisateur

StarTech.com

StarTech.com 35FCREADBK Manuel utilisateur

StarTech.com

StarTech.com 525FCREAD Manuel

StarTech.com

StarTech.com 35FCREAD20 Manuel du système

StarTech.com

StarTech.com 525FCREADREM Manuel du système

StarTech.com

StarTech.com MSTCDP122DP Manuel utilisateur

Manuels Lecteur de cartes populaires d'autres marques

Lindy

Lindy 43185 Manuel utilisateur

Lindy

Lindy 43185 Manuel utilisateur

ViziT

ViziT RD-4F Manuel utilisateur

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manuel utilisateur

AVID ID

AVID ID AVID1043 Manuel utilisateur

Conrad

Conrad PCMCIA Manuel utilisateur

Rosslare

Rosslare DR-6255 Manuel utilisateur

Lindy

Lindy 51541 Manuel utilisateur

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manuel utilisateur

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manuel utilisateur

ACS

ACS ACR122L Manuel utilisateur

Secukey

Secukey S2-MF Manuel utilisateur

Elecom

Elecom MR-SMC07 series Manuel utilisateur

Alien

Alien ALR-9800 Manuel utilisateur

ACS

ACS ACR310 Manuel utilisateur

Datamars

Datamars R-IN1300 MID Manuel utilisateur

Alarm Lock

Alarm Lock AL-PRE2 Manuel utilisateur

xpr

xpr B100PROX-AH Guide de l'utilisateur
