StarTech.com ST124HDVW Manuel utilisateur

Manual Revision: 11/22/2019

User Manual

For the latest information and specications visit

www.startech.com/ST124HDVW

4-Port HDMI®Audio/Video Splitter with 2x2

Video Wall Function - 4K

Actual product may vary from photos

SKU#: ST124HDVW

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorientorrelocatethereceivingantenna

• Increasetheseparationbetweentheequipmentandreceiver

• Connecttheequipmentintoanoutletonacircuitdi󱐯erentfromthatto

whichthereceiverisconnected

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (B)/NMB-3(B)

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

iii

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiringterminationsshouldnotbemadewiththeproductand/or

electriclinesunderpower.

• Cables(includingpowerandchargingcables)shouldbeplacedand

routedtoavoidcreatingelectric,trippingorsafetyhazards.

Mesures de sécurité

• Lesterminaisonsdecâblâgenedoiventpasêtree󱐯ectuéeslorsquele

produitet/oulescâblesélectriquessontsoustension.

• Lescâbles(ycomprislescâblesd’alimentationetdechargement)

doiventêtreplacésetacheminésdefaçonàévitertoutrisque

électrique,dechuteoudesécurité

安全対策

• • 電源が入っている状態の製品または電線の終端処理を行わないでく

ださい。

• • ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引

き回しを行い、電気障害やつまづきの危険性など、安全上のリスクを回避す

るようにしてください。

Misure di sicurezza

• Iterminialideilielettricinondevonoessererealizzateconilprodotto

e/olelineeelettrichesottotensione.

• Icavi(inclusiicavidialimentazioneediricarica)devonoessere

posizionatiestesiinmododaevitarepericolidiinciampo,rischidi

scosseelettricheopericoliperlasicurezza.

Säkerhetsåtgärder

• Monteringavkabelavslutningarfårintegörasnärproduktenoch/eller

elledningarnaärströmförda.

• Kablar(inklusiveelkablarochladdningskablar)skadrasochplaceraspå

såsättattriskförsnubblingsolyckorochandraolyckorkanundvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................i

Safety Statements..................................................................................iii

Product Diagram ....................................................................................1

Front View.................................................................................................................................................... 1

Rear View...................................................................................................................................................... 2

Connection Guide..................................................................................................................................... 3

Requirements .........................................................................................4

Installation ..............................................................................................4

Operation ................................................................................................6

VideoWallApp PC Tool ............................................................................................................................. 6

Serial Control .............................................................................................................................................. 7

Telnet Control............................................................................................................................................. 8

Serial and Telnet Commands ................................................................................................................ 9

Warranty ..................................................................................................15

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Front View

1HDMI Display

Device LED

Indicators

• Solid Green when an HDMI

Display Device is detected

2HDMI Source

Device LED

Indicator

• Solid Green when an HDMI

Source Device is detected

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Rear View

1DC 24V Power

Port

• Connect a Power Source

2Service Port • For manufacturer use only

3Network Control

Port

• Connect to a Computer directly, or

through a Network Switch using a

Network Cable

4HDMI Output

Port

• Connect four HDMI Display Devices

using HDMI M/M Cables

5RS-232 Control

Port

• Connect to a Computer using a Serial

Cable for Serial Control

6HDMI Input Port • Connect an HDMI Source Device

using an HDMI M/M Cable

2 3 4

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Connection Guide

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Requirements

For the latest requirements and to view the full User Manual,

please visit www.startech.com/ST124HDVW.

• HDMI Source Device x 1

• HDMI Display Device x 4

• HDMI M/M Cables (sold separately) x 5

• RS-232 Enabled Computer x 1

• RS-232 Cable x 1

• Network Device (ex. router, network switch) x 1

• Network Cable x 1

• (Optional) HDMI Locks x 4

Installation

Note: Ensure the HDMI Display Devices and the HDMI

Source Device are powered o before you begin the

installation.

All HDMI Ports on the Splitter feature port locking capa-

bilities. HDMI Locks (sold separately) are required to use

this feature.

1. Connect an HDMI M/M Cable to the HDMI Output Port on

the HDMI Source Device and to the HDMI Input Port on

the Splitter.

2. Connect four HDMI M/M Cables to the HDMI Output

Ports on the Splitter and to the HDMI Input Ports on the

HDMI Display Devices. See Figure 1 to determine the HDMI

Output Port conguration (ex. HDMI Output Port A on

the Splitter corresponds with the top-left HDMI Display

Device).

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

3. Connect an RS-232 Cable to the RS-232 Enabled

Computer and to the RS-232 Control Port on the Splitter.

See Figure 2 for pinout and default details.

Figure 1

Figure 2
