Stack ST8110 Instructions d'installation et d'utilisation
542035-002
ST8110 Race Turbo
Display System
User’s Guide Addendum
STACK ST8110 Display System Preface
User Guide Addendum iii
Preface
Congratulations
Congratulations on choosing the Stack ST8110 Display System. This
system will give you a wealth of information to enable you to obtain the
maximum safe performance from your vehicle.
Purpose of this addendum
In conjunction with the ST8100 User Guide, this addendum will help you
install and use the Stack ST8110 Display System. It explains how to set
up and configure the system for your vehicle.
Edition Notice
This edition is for all versions of the ST8110 Display System distributed
to customers world wide. The units of measurement used to illustrate the
use of the Display System in this edition are for the UK version. Units
used in the various versions are shown in the following table.
Parameter Type UK Version US Version EC Version
Boost psi/Bar psi/Bar psi/Bar
Speed mph mph km/h
Wheel
Circumference millimetres inches millimetres
Temperature Degrees C Degrees F Degrees C
Pressure psi psi Bar
Stack is a registered trademark of Stack Limited.
Information in this publication is subject to change without notice and does not represent
a commitment on the part of Stack Limited. No responsibility is accepted for error or
omission.
Copyright 2000 Stack Limited
United Kingdom Telephone Numbers:
Sales: 01869 240404.
Fax : 01869 245500
Chapter 1. Introducing the Display System STACK ST8110 Display System
iv User Guide Addendum
Technical Support : 01869 240420
STACK ST8110 Display System Preface
User Guide Addendum v
Contents
PREFACE III
CONTENTS V
Chapter 1. Introducing the Display System 1
How to Use this Manual 2
Chapter 2. Getting Started 3
Wiring Harness 5
Chapter 3. Operating the Display System 6
Changing the display layers 6
Peak Values (Tell Tales) 8
Alarms 9
Lap times 9
Chapter 4. Configuring the Display System 10
Configuration mode 10
Leaving configuration mode 13
Chapter 5. Installing the Display System 14
Boost Pressure sensor 14
Chapter 6. Troubleshooting 15
Appendix B. Wiring Harness Schematic Diagram 16
Index 17
STACK ST8110 Display System Chapter 1. Introducing the Display System
User Guide Addendum 1
Chapter 1. Introducing the Display System
The Stack ST8110 Display System monitors and displays a range of
values, known as performance parameters, needed for effective car and
driver management in most competitive situations.
The system combines an analog tachometer with a digital display for the
following performance parameters:
1. Engine speed (RPM)
2. Boost pressure
3. Oil pressure
4. Oil temperature
5. Water temperature
6. Fuel pressure
7. Battery voltage
8. Wheel speed (optional)
9. Lap times (optional)
You can view the peak values (tell-tales) for all the parameters.
The system provides a range of warning messages based on preset alarm
values for the following performance parameters:
1. Oil pressure
2. Oil temperature
3. Boost pressure
4. Fuel pressure
5. Water temperature
6. Battery voltage
You can enable or disable the warning system for each parameter
individually.
Chapter 1. Introducing the Display System STACK ST8110 Display System
2User Guide Addendum
You can redefine the preset alarm value for each parameter to a value
that is more suitable for your vehicle.
The system provides a gear shift warning light that is based on an RPM
value that you define for your vehicle.
How to Use this Manual
Stack recommends that you unpack and connect the components in the
system before you install it in your vehicle. This will enable you to
familiarize yourself with operating the display and configuring it for the
vehicle in which you intend to install it.
Please use the ST8100 User Guide to install the system, referring to the
corresponding section in this addendum to see whether there are special
requirements for the ST8110 system.
STACK ST8110 Display System Chapter 2. Getting Started
User Guide Addendum 3
Chapter 2. Getting Started
The sensors supplied with the ST8110 system differ from those supplied
for the ST8100.
Standard ST8110 Display System Items
The ST8110 Display System is supplied with the following standard
components:
Quantity Description
1Display Module (ST867 ) with 2 mounting brackets
1Wiring Harness (ST872)
1Oil Pressure Sensor (ST744, ST745, ST746)
1Fuel Pressure Sensor (ST741, ST742, ST744, ST745, ST746)
2Temperature Sensors (ST760, ST761, ST762, ST764)
10-3.5 Bar Boost Sensor with interface (ST453)
11.4m Extender Cable for Boost Sensor
4Switches (supplied with and to be connected to the wiring
harness)
Chapter 2. Getting Started STACK ST8110 Display System
4User Guide Addendum
Optional ST8110 Display System Items
The ST8110 Display System can be used with the following optional
components:
Quantity Description
1RPM Sensor (ST696 Opto Isolator or ST697 H.T. Pick-up)
1Wheel Speed Sensor (ST670 or ST671)
1Infra-red Lap Time Receiver (ST543)
1Infra-red Lap Time Beacon (ST544)
1External Gear Shift Warning Lamp
1External Alarm Warning Lamp
1Corner Speed option. Note: The ST8109 Corner Speed option
is delivered prefitted in the Display Module
