NEB/3U

Power supply

plug-in module

Product

Manual

________________________________________________________________________________________________________________________________________________________________________________________________________________________

2 Product Manual Type: NEB/3U 07-01-02-02-E-V0605.DOC

Further descriptions, that relate to this document:

UL:07-01-05-06

635 - Product Manual

UL:07-01-01-01

Rack 3U - Product Manual

©SSD Drives GmbH.

consent of the company.

Changes are subject to change without notice.

SSD Drives has registered in part trademark protection and legal protection of designs.

The handing over of the descriptions may not be construed as the transfer of any rights.

Made in Germany, 2005

________________________________________________________________________________________________________________________________________________________________________________________________________________________

07-01-02-02-E-V0605.DOC Product Manual Type: NEB/3U 3

CONTENTS

page

The most important thing first ..........................................................................4

1 Description................................................................................................5

2 Type code..................................................................................................6

2.1 Typical Example..............................................................................................................................6

3 Front view, Power-supply plug-in module.............................................7

4 Technical data...........................................................................................8

5 Assignment / Power connectors.............................................................9

6 Miscellaneous.........................................................................................10

7 Adjustments............................................................................................11

7.1 The ballast power is adjusted in production! ................................................................................11

8 Fuses /Monitorings.................................................................................11

8.1 Fuse for overload protection.........................................................................................................11

8.2 Fuse for conducting path protection.............................................................................................11

8.3 Switching current limiting..............................................................................................................11

8.4 Ballast monitoring .........................................................................................................................11

9 Update list ...............................................................................................12

________________________________________________________________________________________________________________________________________________________________________________________________________________________

4 Product Manual Type: NEB/3U 07-01-02-02-E-V0605.DOC

The most important thing first

Thanks for your confidence choosing our product.

These operating instructions present themselves as an overview of the technical data and

features.

Please read the operating instructions before operating the product.

If you have any questions, please contact your nearest SSD Drives representative.

Improper application of the product in combination with dangerous voltage can lead to

injuries.

In addition, damage can also occur to motors or other products.

Therefore please observe our safety precautions strictly.

Safety precautions

We assume that, as an expert, you are familiar with the relevant safety regulations,

especially in accordance with VDE 0100, VDE 0113,VDE 0160, EN 50178, the accident

prevention regulations of the employers liability insurance company and the DIN

regulations and that you are able to use and apply them.

As well, relevant European Directives must be observed.

Depending on the kind of application, additional regulations e.g. UL, DIN are subject to be

observed.

If our products are operated in connection with components from other manufacturers,

their operating instructions are also subject to be observed strictly.

________________________________________________________________________________________________________________________________________________________________________________________________________________________

07-01-02-02-E-V0605.DOC Product Manual Type: NEB/3U 5

1 Description

The power-supply-plug-in module NEB/3 is connected to 1 or 3 * 230 V AC.

The device makes from the power-supply voltage the rated voltage of 325 V DC for the

intermediate circuit for the servo drive 635 from SSD Drives.

The power supply module is located extremely left in the rack.

The module can only be delivered with ballast circuit.

The ballast input power integrated in the power supply module is ventilated according to the

adjustment 30 W ... 55 W.

The power supply module can also be used for lower power supply voltages by changing the

resistance R 10, required for example when using DC-servo motors.

________________________________________________________________________________________________________________________________________________________________________________________________________________________

6 Product Manual Type: NEB/3U 07-01-02-02-E-V0605.DOC

2 Type code

Standard Specialr

Marking a b c d e f g

Type: NE B XX -XXX /3- XX -X

Marking Description

a NE = Plug-in power supply

b B= Ballast circuit

c Permanent current

10 = 10 Amperes

15 = 15 Amperes

25 = 25 Amperes

d Adjusted ballast input power:

-030 = 30 W internal, at 10 A continuous current - uncooled

-055 = 55 W internal, at 15 A continuous current - cooled

-(100) = 100 W external, at 25 A continuous current - uncooled or cooled

e Heights units:

/3 = 3 U (appr. 128,4mm)

f = Code adjusted ballast input power

A1 Details see chapter 7

A2

B2

C1

g Special:

b= Protection against condensation

c= Additional capacitors

total capacity 900 µF (standard: 450 µF)

h= b + c

The external ballast resistor is not included in the standard delivery ≅accessories

2.1 Typical Example

Example for ordering information corresponding to the type code:

NE B 10 -030 /3 A1

Code ballast input power

3U (appr. 128,4mm)

30W internal ballast input power

10Amperes continuous current

Ballast circuit

Plug-in power supply

________________________________________________________________________________________________________________________________________________________________________________________________________________________

07-01-02-02-E-V0605.DOC Product Manual Type: NEB/3U 7

3 Front view, Power-supply plug-in module

Dimensions:

Width = approx. 40,0 mm (8 HP)

Hight = approx. 128,4 mm (3 U)

Depth = approx. 160,0 mm

plus jutting out H15 strip

Arrangement (standard):

left rack socket

________________________________________________________________________________________________________________________________________________________________________________________________________________________

8 Product Manual Type: NEB/3U 07-01-02-02-E-V0605.DOC

4 Technical data

Power-supply

plug-in modu: Module

width Output current Adjusted

ballast input power Ohmic resistance

of the ballast

Type not ventilated * ventilated int. ext. resistance

(-) (HP) (A) (A) (W) (-) (-) (Ω)

NEB 10-030/3 -A1 8 10 25 30 x - 54

NEB 15-055/3 -B2 8 - 15 55 x - 54

NEB 25-(100)/3 -A2 8 25 25 100 - x 33

NEB 25-(100)/3- C1 8 25 25 100 - x 22

Specifications concerning supply voltage 230 V AC!

* Fan: L220 K

Air flow rate 80 m³ / h,

Supply voltage 230 V / 50 Hz

General data minimum nominal maximum dimension

Power connector - 230 255 Veff

Mains frequency 45 50 60 Hz

Feed-in 3-phase or 1-phase

Output voltage: - 325 360 V DC Ucc

Ballast res. On 370 376 380 V DC Ub

Ballast res. Off - - 370 V DC Ub

Mounting position: vertical in free stream of air 150 mm free

space towards the bottom and the top

Weight: 0,5 kg

Type of protection: IP 00 according to DIN 40 050

Permissible ambient temperature:

¾Operation: 0°C ... + 40°C

¾in case of power reduction: up to + 55°C

¾storage and transport: - 25°C ... + 85°C

________________________________________________________________________________________________________________________________________________________________________________________________________________________

07-01-02-02-E-V0605.DOC Product Manual Type: NEB/3U 9

5 Assignment / Power connectors

View from the rear of the rack:

Clamps Function descriptin

4 +Ucc

6 +Ucc

8 +Ucc

DC - bus voltage

10 L1

12 L1

14 L2

16 L2

18 L3

20 L3

Supply voltage

1* or 3* 230 V AC

22 -Ucc

24 -Ucc

26 -Ucc

DC bus voltage

28 +RB

30 -RBExternal

Ballast resistor

32 GND Ground

Attention:

With 1-phase connection clamps 14 and 16 are used as zero conductors "N".

________________________________________________________________________________________________________________________________________________________________________________________________________________________

10 Product Manual Type: NEB/3U 07-01-02-02-E-V0605.DOC

6 Miscellaneous

Guarantee:

Only when using original SSD Drives component racks, drives and ballast resistors SSD Drives guarantees

for 1 years .

Plug in and out the module:

The module may only be plugged in i.e. out when there is no voltage.

Attention:

The power-supply plug-in module may only be plugged out 30

seconds after the green LED "Ucc ok", mounted on the front, is

out. (Discharge time of the capacitor)

ISO 9001:

The devices are produced in accordance with DIN ISO 9001.

All devices are subject to a 100% final test.

VDE-guidelines:

The device meets the requirements of the VDE 0100 and VDE 0160.

EG-certificate of conformity given for:

EN 50 081-2 interference emission high frequency emission

pr EN 50 082-2 immunity to interference against HF and impulses

vfg 242/1991 "barrage" jammer

The low-voltage guidelines are not met yet.

further information see:

•EG-certificate of conformity 16.7.1.2 and

•Enclosure I.1 to the EG-certificate of conformity 16.7.1.2
