Adjusting the magnetic brake
Eventually the cable winch to adjust the distance between the magnets and the wheel can lengthen because
of heavy use, so the magnet rocker has to be readjusted from time to time. Please adjust the rocker so that
the distance of the magnets to the aluminium ring is 3-5 mm for the first and last magnet. To clamp the cable,
turn the adjusting screw outwards first.
Before you align the magnet rocker, put a piece of cardboard between the magnet rocker and the fly-
wheel. This is to make sure that the magnets don’t touch the flywheel, because it would be very diffi-
cult to detach them again.
To adjust the upper catch you need to loosen the cable with a 10 mm ring wrench and the attachment of the
magnet rocker with an 8mm hexagon wrench (don’t unscrew completely), and then move the magnet rocker
as far as needed. Then retighten the screws. The lower catch can be adjusted by turning the allen screw.
Special Features
The magnet for switching on the PowerMeter is attached by a cable-tie and heat shrink tubing under the bot-
tom bracket. If you do not see power or cadence displayed, first check if the magnet is present and positioned
properly.
Speed is sent from a speed sensor on the rear frame of the Indoortrainer and a magnet on the flywheel. If you
do not see speed displayed, first check if the magnet is present and positioned properly.
Since the NuVinci N360 sprocket wider than normal, the use of a KMC X-8-99 chain or equivalent is recom-
mended.
