SPORTS AFIELD SA-HD4 Manuel utilisateur

IMPORTANT:

Please read this information and follow all safety rules carefully before

operating your security vault. Failure to do so will void your warranty.

073021

DUAL QUICK ACCESS BIOMETRIC SECURITY VAULT

INSTRUCTION MANUAL FOR SA-HD4

DUAL ACCESS

TABLE OF CONTENTS

www.saproducts.com 1

IMPORTANT INFORMATION ............................................................................................... 2

1. REGISTRATION ................................................................................................................ 3

2. UNDERSTANDING YOUR VAULT ...................................................................................... 4

3. INITIAL ENTRY .................................................................................................................. 5

4. BATTERY INSTALLATION................................................................................................... 5

5. PROGRAMMING YOUR FINGERPRINT ............................................................................. 6

6. OPENING VAULT WITH PROGRAMMED FINGERPRINT ....................................................7

7. PROGRAMMING ADDITIONAL FINGERPRINTS ................................................................ 7

8. TROUBLE SHOOTING ..................................................................................................... 8

9. CLEARING ALL PROGRAMMED FINGERPRINTS .............................................................. 9

10. E-LOCK SECURITY CODE SETUP..................................................................................... 10

11. LOW BATTERY WARNING............................................................................................ 11

12. LOCKOUT MODE/ TAMPER PROTECTION......................................................................11

13. SILENT ENTRY MODE...................................................................................................11

14. PROPER PLACEMENT AND MOVING OF VAULT......................................................... 12

15. SECURING YOUR VAULT .............................................................................................. 12

16. LOADING YOUR VAULT .................................................................................................14

17. MAINTAINING HINGES AND INTERNAL MECHANISMS .............................................. 14

WARRANTY ................................................................................................................... 15

DISCLAIMER - READ BEFORE VAULT SETUP

WEAPON STORAGE

SAFETY

Thank you for choosing a Sports Aﬁeld vault to protect your valuables. We are

commied to securing, organizing and protecng your most important documents,

valuables and keepsakes.

If you experience problems or challenges with your vault, please contact us.

Many issues can be quickly resolved without the product being returned.

Be sure to keep backup keys stored in a safe place away from unauthorized users

Do not put anything in your vault that will put pressure against the door when

it is closed.

If you choose to ulize this vault to store a weapon always follow proper weapon and

local laws.

SA Consumer Products strongly recommends that you do not store loaded ﬁrearms.

Always follow the ﬁrearm safety rules set out by the ﬁrearm’s manufacturer.

Store ammunion separately from valuables.

A Sports Aﬁeld vault or any other ﬁrearm storage device cannot take the place

of other safety procedures including advising children of the dangers of ﬁrearms.

SA Consumer Products and its distributors of the Sports Aﬁeld vaults do not

recommend, suggest, advise, promote, or otherwise condone the ownership or use of

ﬁrearms. We believe the decision to own or use a ﬁrearm is a serious decision that

should only be made by an adult who has carefully considered the risks and beneﬁts

of such a decision.

PLEASE READ THIS INFORMATION CAREFULLY BEFORE OPERATING YOUR

SPORTS AFIELD VAULT.

DO NOT LOCK THIS MANUAL OR THE OVERRIDE ACCESS KEYS IN YOUR VAULT.

Contact Customer Service at [email protected] or (888) 792-4264

PURCHASE DATE:

PURCHASE PRICE (BEFORE TAX):

MODEL NUMBER:

SERIAL NUMBER:

KEY NUMBER (IF APPLICABLE):

1. REGISTRATION

RETAILER NAME:

By registering your Sports Aﬁeld vault we will be able to expedite and address

any problems or challenges you may havewhich would otherwiserequirea

notary leer and proof of payment.

Theinformaon you record onto this page will be required in the event you

cannot access thecontents of your Sports Aﬁeld vault. Pleaseﬁll out all the

required informaon below and retain for your records and safe keeping.

PLEASE HAVE THIS INFORMATION READY PRIOR TO CALLING FOR TECHNICAL

ASSISTANCE AT:

Contact Customer Service at [email protected] or (888) 792-4264

REGISTRATION INFORMATION

2. UNDERSTANDING YOUR VAULT

Biometric

Scanner

(opens top

of vault)

Electronic

Touch Pad

(opens bottom

drawer of vault)

Bottom Drawer Key Entry

(Underneath Foam)

For Backup Key Set #1

19"

INTERIOR OF FRONT PANEL

Battery

Compartment

(4) AA Reset Button

LED Light

Security Cable Port

(on back panel)

Locking

Latch

7.10 "

10.60"

12.60"

Backup Key Lock

(Underneath Cover)

For Backup Key Set #2

Battery

Compartment

(inside)

Reset Button

(inside)

LED Light

(inside)

3. INITIAL ENTRY

Step 3

WARNING: Thebaeries must be inserted with the correct polarity. Exhausted baeries

must be removed from theproduct and discarded safely. Do not mix old and new

baeries. Do not mix alkalineor standard (carbon – zinc) baeries. Do not use recharge-

able (nickel – cadmium) baeries.

Step 2

1. Locate the TWO SETS of

override key aached to the

product packaging.

Locate the key cover and

press down near the right side

of the SPORTS AFIELD logo.

The cover will pop up on one

side so that it can be

removed.

Match the number on your

key to the numbers engraved

on the lock. Once matched,

insert the key, Turn and hold

the key clockwise, and your

vault door will open.

The second set of keys will

access the boom of your

vault. The key hole can be

found under the foam in the

top of vault. Turn this key

counter-clockwise and the

slide out

drawer will open.

TURN KEY

COUNTER-CLOCKWISE

Step 1

LOCK UNDER

KEY COVER

4. BATTERY INSTALLATION

KEY HOLE FOR BACKUP

KEY SET #1 IS LOCATED

UNDER FOAM

Locate the (4) AA baeries

and insert in the baery

compartment on the inside

front right of the vault.

Keypad will beep once when

baeries are successfully

installed. Replace baery

cover.

1234U

MATCH THE NUMBERS FROM BACKUP KEY SET #2 TO THE LOCK.

5. PROGRAMMING YOUR FINGERPRINT- BIO SCANNER

3. Place and hold the pad of your

ﬁnger on the scanner unl it ﬂashes

green and beeps one me.

4. Repeat at least 3 more mes unl

there are 2 consecuve beeps and

the indicator ring lights up green.

BEEP

HOLD FOR BEEP

LIFT FINGER

Step 3Step 4

2 BEEPS + GREEN LIGHT = SUCCESS!

Step 1

1. Inside of the vault, you will ﬁnd a

reset buon on the right side of

the front panel.

Press the reset buon to start the

programming process. You will

hear one beep and the indicator

ring will illuminate on the front of

the door

NOTE: Programming mode will me

out aer 10 seconds of inacvity. If

this occurs press reset buon and

begin again.

Step 2

BEEP

THIS SECTION IS TO PROGRAM YOUR FINGERPRINT ON THE BIO SCANNER

THAT OPERATES THE TOP PORTION OF YOUR VAULT.

Battery

Compartment

(4) AA

Reset Button

LED Light

6. OPENING VAULT WITH PROGRAMMED FINGERPRINT

7. PROGRAMMING ADDITIONAL FINGERPRINTS

INDIVIDUALLY MAPPING ALL

ZONES OF YOUR FINGERPRINT

WILL ENSURE A RELIABLE

READING BY THE SCANNER.

To ensure each programming

sequence is properly captured, it

needs to read the exact same place

on your ﬁnger four mes in a row,

once successful you can move onto

the next zone of your ﬁngerprint.

This counts as one programmed

ﬁngerprint of 100 ﬁngerprints this

unit can keep in memory.

Once programming sequence has

been successfully completed, you

can move onto the next zone of your

ﬁngerprint.

TIP

RIGHT

TOP

MIDDLE

LEFT

If your ﬁngerprint is not accepted:

FLASH

RED

LIGHT

INDICATOR RING

TRY AGAIN REPROGRAM

With keys in hand, close the door. Place and

hold the PROGRAMMED ﬁnger on the scanner,

indicator ring will illuminate green and vault

door will open.

When accessing your vault quickly, there is a chance you might press

the scanner with a part of your ﬁnger that you have not registered before.

For this reason, we recommend programming addional areas of your

ﬁngerprint to ensure fast and reliable entry to your vault.

Indicator ring will ﬂash 1 me

and sound 1 me. This means

the scanner did not read your

ﬁngerprint (try again).

If you see 5 red ﬂashes with 5

sounds, the scanner read your

ﬁngerprint but did not accept it.

Follow secon 6 to reprogram

your ﬁngerprint.

8. TROUBLE SHOOTING

7. PROGRAMMING ADDITIONAL FINGERPRINTS (CONTINUED)

Press the reset buon and follow

Secon 5 instrucons again, for

each ﬁngerprint zone you would

like to program.

If you experience any problems

reading your ﬁngerprint, including

inconsistent readings, note the

area of your ﬁngerprint that

doesn’t work properly, and

speciﬁcally re-program that area.

This scanner will hold up to 100

unique ﬁngerprints.

BEEP

HOLD FOR BEEP

LIFT FINGER

2 BEEPS + GREEN LIGHT = SUCCESS!

In the event that you run into issues with programming and accessing your

vault, please read through this secon for answers to your quesons.

Placing a poron of a ﬁngerprint on the scanner that has

not been programmed can result in an error. We

recommend programming mulple areas of each

ﬁngerprint.

Make sure baeries are fresh. We suggest high grade

alkaline. Do not mix old and new baeries. No not use

rechargeable baeries.

Make sure you are placing the same part of your ﬁnger

print on the scanner that you use for programming. If not

make not of the area that is not scanning and program

that area speciﬁcally.

SOLUTIONPROBLEM

YOUR PROGRAMMED

FINGERPRINT IS NOT

READING AT ALL TIMES

9. CLEARING ALL PROGRAMMED FINGERPRINTS

8. TROUBLE SHOOTING (CONTINUED)

Locked Out Of Your Vault

In the event you are locked out your vault, use your backup keys to gain access and

follow the secon 3 Inial Entry instrucons.

If you have lost your backup keys, or are sll having any diﬃcules, contact customer

service at the number below. Proof of purchase is required to obtain keys.

SOLUTION

2 x

RED

LIGHT

NOTE: If 100 max ﬁngerprints have already been programmed indicator ring will ﬂash

5 mes and beep 5 mes. We recommend clearing all programmed ﬁngerprints and starng

the programming process over.

Hold reset buon for 5 seconds, the

keypad ﬂashes twice and will beep twice.

Battery

Compartment

(4) AA

Reset Button

LED Light

Contact Customer Service at [email protected] or (888) 792-4264

Make sure to hold down your ﬁnger on the scanner

instead of tapping, as the scanner needs me to

complete the scanning process.

Fingerprints may lack deﬁnion due to excessive dryness.

We recommend applying moisturizer or slide your

ﬁngerprint against your forehead before scanning

process.

Pressing and releasing the reset buon will not erase

ﬁngerprints already recorded. It simply places the

scanner in programming mode to allow for addional

ﬁngerprints to be programmed. This unit will hold up

to 100 unique ﬁngerprints.

SOLUTIONPROBLEM

YOUR FINGERPRINT IS NOT

READING

WILL PRESSING THE

RESET BUTTON CLEAR

THE MEMORY

Table des matières

Autres manuels SPORTS AFIELD Sûr

SPORTS AFIELD

SPORTS AFIELD SA5932P-BG Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD FOR SA5524-BG Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD HAVEN Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA55-36V Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD INSTINCT BIOMETRIC Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD YOSEMITE SA55-12MYX, Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD PRESERVE BIOMETRIC Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD Gun Safe Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD PRESERVE SA72-60WD Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD2-BIO Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD6-BIO-DP Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD PRESERVE Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD YOSEMITE Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD2 Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD PRESERVE Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA5520INS-BIO Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD6-BIO Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA55-24V Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD1X Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD HAVEN Series Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD6-MEL Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD 18 Gun Safe Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA30SM Manuel utilisateur

SPORTS AFIELD

SPORTS AFIELD SA-HD1-BIO Manuel utilisateur

Manuels Sûr populaires d'autres marques

Squire

Squire Stronghold Keysafe Manuel utilisateur

Phoenix

Phoenix FS0352C Fiche d'information produit

Phoenix

Phoenix KS0030E Series Manuel utilisateur

Vaultek

Vaultek 10 Series Fiche technique

Arregui

Arregui CLASS Manuel utilisateur

Beaumont

Beaumont SMART KEYBOX Manuel utilisateur

Honeywell

Honeywell 2077D - 1.21 Cubic Foot Anti-Theft Safe Manuel utilisateur

Hornady

Hornady SnapSafe Trunk Safe II Manuel utilisateur

Honeywell

Honeywell 5912 Manuel utilisateur

Phoenix

Phoenix FS1280F Manuel utilisateur

Phoenix

Phoenix SS0992K Fiche d'information produit

Technomax

Technomax Trony Series Manuel

RICHTER CZECH

RICHTER CZECH LA Manuel d'utilisation

Olymp

Olymp GOsafe 110 Manuel utilisateur

Phoenix

Phoenix SS0100E Fiche d'information produit

Clarke

Clarke Strong-Arm CS1000K Mode d’emploi

Ankaro

Ankaro ANK EZ I Manuel utilisateur

Phoenix

Phoenix FS1270E Series Manuel utilisateur
