Sportline SL708 Manuel utilisateur
Introduction......................................................................................................................3
Caution ............................................................................................................................3
Button Overview ..............................................................................................................4
Operation.........................................................................................................................6
Specifications..................................................................................................................14
Battery Usage .................................................................................................................15
Display Viewing..............................................................................................................15
2
Table of Contents
SP4425IS01ENB.indd 2SP4425IS01ENB.indd 2 3/18/08 4:39:35 PM3/18/08 4:39:35 PM
Head H1 or H2
3
Introduction
The Sportline®Heart Rate Watch with LED Beats Per Minute accurately measures ECG
heart rates without a chest strap. It operates as a basic analog watch and features digital
time, calendar and heart-rate monitor functions.
Read all instructions carefully before use. Save these instructions for future reference.
Caution
• Avoid exposing the watch to extreme conditions.
• Avoid rough use and severe impacts.
• Do not attempt to repair, disassemble or modify the watch in any way.
• Clean the watch occasionally with a soft damp cloth.
• Store the watch in a dry place when not in use for an extended period.
• To avoid the possibility of damage, we recommend that you take the watch to a specialist
for battery replacement. 3
SP4425IS01ENB.indd 3SP4425IS01ENB.indd 3 3/18/08 4:39:36 PM3/18/08 4:39:36 PM
4
Button Overview
• Time Button
• Heart Rate Button
• Crown
• Daily Alarm Button
• Sensor Contact 1
• Back Cover (Sensor Contact 2)
4
SP4425IS01ENB.indd 4SP4425IS01ENB.indd 4 3/18/08 4:39:36 PM3/18/08 4:39:36 PM
Head H1 or H2
5
Button Overview
Time Button: Press to view Current Time Display, date, day of week and seconds.
Hold down to enter the Current Time Setting mode.
Heart Rate Button: Hold down in conjunction with the Sensor Contacts to measures heart
rate. Press to select among different settings.
Crown: Pull out to set analog time.
5
Time Button
Sensor
Contact 1
Heart Rate
Button
Crown
Daily Alarm
Button
SP4425IS01ENB.indd 5SP4425IS01ENB.indd 5 3/18/08 4:39:36 PM3/18/08 4:39:36 PM
6
Button Overview
Daily Alarm Button: Displays alarm setting. Press to increase/change setting value.
Sensor Contact 1: Heart-rate sensor contact. Hold down button in conjunction with Heart
Rate button to measure heart rate.
Back Cover (Sensor Contact 2): Heart-rate sensor contact. Battery door.
Operation
Setting the Analog Watch
1. To set the analog time, gently pull the Crown out, until you feel a click. The second
hand stops and the digital time flashes.
2. Turn the Crown clockwise/counterclockwise until the desired time is set. The digital
time can be used as a reference for setting the analog time.
3. To display the hour, minute or second digitally, press any button.
6
SP4425IS01ENB.indd 6SP4425IS01ENB.indd 6 3/18/08 4:39:37 PM3/18/08 4:39:37 PM
Head H1 or H2
7
Operation
4. Once the time is set, to resume normal operation, gently push the Crown back to its
original position.
Setting Date and Time
1. Press and hold down the TIME button until the digital display starts to flash.
2. To browse through the different formats (second, minute, hour, year, month, day, date
and time), press the HEART RATE button.
3. To select a format, press the DAILY ALARM button; to change the setting values, press
the button again; to increase the rate of change, hold down the button.
4. With digital seconds selected, to zero out (reset) the watch and synchronize the analog
and digital seconds, press the DAILY ALARM button.
5. When complete, press the TIME button to save the settings and return to the Current
Time Display.
7
SP4425IS01ENB.indd 7SP4425IS01ENB.indd 7 3/18/08 4:39:37 PM3/18/08 4:39:37 PM
8
Operation
Note: The watch exits setting mode and shuts off automatically after 60 seconds of
inactivity.
Synchronizing Analog and Digital Time
The analog and the digital time of the LED Heart Rate Watch will differ because they are
two independent systems. You will need to set both time functions manually to synchronize
the time.
Setting Alarm Time
1. Hold down the DAILY ALARM button; the digital display flashes.
2. To browse through the different settings (alarm ON/OFF, alarm hour, alarm minute),
press the HEART RATE button.
3. To select a setting, press the DAILY ALARM button.
4. To save the selected setting, press the TIME button.
SP4425IS01ENB.indd 8SP4425IS01ENB.indd 8 3/18/08 4:39:37 PM3/18/08 4:39:37 PM
Head H1 or H2
9
Operation
Heart-Rate Mode (Precautions and Tips)
• There are two heart-rate sensor contacts on the watch: Sensor Contact 1 and the Back
Cover (Sensor Contact 2). The Back Cover must make firm contact with the user’s skin
(wrist) during measurement.
• Do not take heart-rate measurements while diving or under water.
• Do not use with hand cream. It will insulate the signal between the skin and
Sensor Contacts.
• Do not use the fingertips where the skin is dry and thick. For those with extremely dry
skin, moisten the fingers and wrist with tap water or a conductive gel.
• Clean the Back Cover occasionally, using a damp cloth. Wipe dry to remove any residue.
• To ensure better signal transmission, clean your skin and fingers with soap and water.
SP4425IS01ENB.indd 9SP4425IS01ENB.indd 9 3/18/08 4:39:38 PM3/18/08 4:39:38 PM
10
Operation
• Hold the watch firmly when taking measurements in motion.
• Avoid awkward motions during measurement. They may create inaccurate heart-
rate readings.
Heart-Rate Measurement
1. To measure heart rate, press the HEART RATE button with your index finger for about
5 seconds.
2. Ensure the Back Cover of the watch sits firmly on the skin.
3. Press SENSOR CONTACT 1 with your thumb.
Note: To obtain a heart-rate reading, both Sensor Contact buttons must be pressed
simultaneously.
SP4425IS01ENB.indd 10SP4425IS01ENB.indd 10 3/18/08 4:39:38 PM3/18/08 4:39:38 PM
