Amplifiers
SPL introduces the all new E-FLUX amplifiers
with a stunning tri-color pulse lightning dish that
moves with the music. We have coupled our
high output mosfet power supplies with 24db.
Subwoofer crossovers and dash mounted bass
controls, on 1000 watt and up two channel
models. Check out our new “rough sand”
finished amplifier heat sinks for a stunning new
look!
|01
spl06 2006-4-9 15:19 Page 2
Remote Dash Mount Bass Knob
Control
• Full Mosfet Power Supply
• PWM Circuitry
• Full Selectable Crossover Hi/Full/Low
• Three Way Protection Circuit
• 2 Ohm Stable Stereo
• Tri-Mode Capable
• Variable Low Pass 40Hz-250Hz
• Variable Hi Pass 40Hz-250Hz
• Variable 24 dB Bass Boost @ 40Hz
• Frequency Response: 10Hz to 30KHz
• S/N Ratio: 98 dB
• THD: 0.02%
• System Distress Indicator
• 4 Guage Power/Ground Connection
• Platinum Plated RCA Connectors
• Line Output
• High/Low Level Inputs with Floating Ground
• Optional Accessories: METER-4
• This Series Has Direct Coupling For
METER-4
Common Features:
Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD” Bass Knob
AX2-620 2 150x2 180x2 360 620 14x2.3x11.5 No
AX2-1000 2 220x2 280x2 560 1000 15.2x2.3x11.5 Yes
AX2-1500 2 300x2 380x2 760 1500 21x2.3x11.5 Yes
AX2-2000 2 370x2 450x2 900 2000 23x2.3x11.5 Yes
AX4-720 4 85x4 100x4 200x2 720 14x2.3x11.5 No
AX4-1000 4 100x4 125x4 250x2 1000 15.2x2.3x11.5 No
SYNCHROIZED TRI-COLOR PULSE LIGHTING DISH
02|
END CAPS
NEW HYPER BASS
spl06 2006-4-9 15:19 Page 3
PHANTOM
Amplifiers
SPL introduces the new Phantom series
amplifiers with stylish wedge shape case with
cool blue back-lit mesh logo plate. Once again
we have coupled this with our proprietary mosfet
power supply and 18db. Subwoofer slopes with
dash mounted bass controls on 1000 watt and up
versions. All connectors are tri-angular crystalline
terminal blocks for simplified installation.
|03
• Variable Subsonic Filter 15Hz-40hz
• Variable Subwoofer EQ @ 45Hz
• Phase Switch 0-180
• Remote Dash Mount Low Level Gain
Control With Cable
• Frequency Response: 15Hz to 150hz
• S/N Ratio: 100 db
• Hi Speed Digital Circuitry
• Fully Regulated PWM Power Supply
• Four Way Protection Circuit
• 1 Ohm Stable
• Bridging Synchronization
• Variable Low Pass 50Hz-150Hz
• THD: 0.5%
• System Distress Indicator
• Inputs Sensativity: 200mv-8v
• Dual Mono Speaker Output Connectors
• Gold Plated Heavy Duty Power &
Speaker Terminals
Common Features For Class D Series:
spl06 2006-4-9 15:19 Page 4
Remote Dash Mount Bass Knob
Control
• Full Mosfet Power Supply
• PWM Circuitry
• Full Selectable Crossover Hi/Full/Low
• Three Way Protection Circuit
• 2 Ohm Stable Stereo
• Tri-Mode Capable
• Variable Low Pass 40Hz-250Hz
• Variable Hi Pass 40Hz-250Hz
• Variable 18 dB Bass Boost @ 40Hz
• Frequency Response: 10Hz to 30KHz
• S/N Ratio: 98 dB
• THD: 0.02%
• System Distress Indicator
• 4 Guage Power/Ground Connection
• Platinum Plated RCA Connectors
• Line Output
• High/Low Level Inputs with Floating Ground
Common Features:
Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD” Bass Knob
DK2-340 2 80x2 95x2 190 340 8x2.3x10.3 No
DK2-460 2 95x2 120x2 240 460 9x2.3x10.3 No
DK2-620 2 150x2 180x2 360 620 12x2.3x10.3 No
DK2-1000 2 220x2 280x2 560 1000 14.7x2.3x10.3 Yes
DK2-1500 2 300x2 380x2 760 1500 19x2.3x10.3 Yes
DK2-2000 2 370x2 450x2 900 2000 20.2x2.3x10.3 Yes
DK4-680 4 80x4 95x4 190x2 680 10.7x2.3x10.3 No
DK4-1000 4 100x4 125x4 250x2 1000 12.7x2.3x10.3 No
Cool Blue Back Lit Mesh Logo Plate
04|
chrome END CAPS
NEW HYPER BASS
Model 2ch/4ch 4ohm RMS 2ohm RMS 1ohm RMS Max Dimension W”xH”xD” Bass Knob
DK-2000D 1 800 1300 1600 2000 12.7X2.7X11 Yes
DK-2600D 1 1100 1600 2000 2600 15X2.7X11 Yes
DK-3400D 1 1400 2100 2600 3400 16.75X2.7X11 Yes
For Class D Series:
For Class A/B Series:
spl06 2006-4-9 15:20 Page 5
SERIES V
Amplifiers
The Series V are designed to rock your world
with the stunning bright cool blue lighting and
still deliver clean power loud enough to quench
competitors thrists.
|05
spl06 2006-4-9 15:20 Page 6
Remote Dash Mount Bass Knob
Control
• Full Mosfet Power Supply
• PWM Circuitry
• Full Selectable Crossover Hi/Full/Low
• Three Way Protection Circuit
• 2 Ohm Stable Stereo
• Tri-Mode Capable
• Variable Low Pass 40Hz-250Hz
• Variable Hi Pass 40Hz-250Hz
• Variable 18 dB Bass Boost @ 40Hz
• Frequency Response: 10Hz to 30KHz
• S/N Ratio: 98 dB
• THD: 0.02%
• System Distress Indicator
• 4 Guage Power/Ground Connection
• Platinum Plated RCA Connectors
• Line Output
• High/Low Level Inputs with Floating Ground
Common Features:
Model 2ch/4ch 4ohm RMS 2ohm RMS Mono RMS Bridged Max Dimension W”xH”xD” Bass Knob
ST2-360 2 85x2 100x2 200 360 7.25x2.3x11 No
ST2-480 2 100x2 125x2 250 480 9x2.3x11 No
ST2-620 2 150x2 180x2 360 620 11.25x2.3x11 No
ST2-980 2 220x2 280x2 560 980 13x2.3x11 Yes
ST2-1440 2 300x2 360x2 720 1440 18.7x2.3x11 Yes
ST2-1920 2 370x2 440x2 880 1920 20.7x2.3x11 Yes
ST4-720 4 85x4 100x4 200x2 720 11.25x2.3x11 No
ST4-960 4 100x4 125x4 250x2 960 13x2.3x11 No
Cool Blue Illumination
06|
spl06 2006-4-9 15:20 Page 7
Amplifiers
The SPL Series II amplifiers were designed
and built with the Competition (SPL) enthusiast
in mind. Especially built to withstand the rigors
of competition testing, the upgraded
components used throughout the Series II will
serve you well.
|07
• Variable Low Pass 40Hz-120Hz
• Variable Hi Pass 150Hz-1.5Khz
• 18dB Bass Boost @ 40Hz.
• Frequency Response: 10Hz to 30Khz
• S/N Ratio: 97 db
• THD: 0.02%
• Full Mosfet Power Supply
• PWM Circuitry
• Full Selectable Crossover Hi/Full/Low
• Three Way Protection Circuit
•
2 Ohm Stable Stereo
•
Tri-Mode Capable
• System Distress Indicator
• High/Low Level Inputs With Floating Ground
• 4 Gauge Power/Ground Connection
• Gold Plated RCA Connectors
• Line Output
Common Features For Class A/B Series:
SERIES II
spl06 2006-4-9 15:20 Page 8
Model 2Ch/4Ch 4 Ohm Rms 2 Ohm Rms Mono Rms Bridged Max imensions (LxWxH)
Z4X-600 4 70 x 4 85 x 4 170 X 2 600 11.25” x 11.25” x 2.25”
Z4X-800 4 85 x 4 105 x 4 210 x 2 800 14” x 11.25” x 2.25”
Z2X-1600 2 310 x 2 370 x 2 740 1600 22” x 11.25” x 2.25”
Z2X-400 2 85 x 2 105 x 2 210 400 8.5” x 11.25” x 2.25”
Z2X-520 2 125 x 2 150 x 2 300 520 11.25” x 11.25” x 2.25”
Z2X-820 2 180 x 2 230 x 2 460 820 14” x 11.25” x 2.25”
Z2X-1200 2 250 x 2 300 x 2 600 1200 20.5” x 11.25” x 2.25”
Z2X-300 2 70 x 2 85 x 2 170 300 7.25” x 11.25” x 2.25”
Model Ch 4 Ohm Rms 2 Ohm Rms 1 Ohm Rms Max Dimensions (LxWxH) Bass Knob
Z1X-3000D 1 1100 1800 2300 3000 16.8” x 11.25” x 2.25” Yes
Z1X-2400D 1 900 1400 1800 2400 15” x 11.25” x 2.25” Yes
• Variable Subsonic Filter 15Hz-40hz
• Variable Subwoofer EQ @ 45Hz
• Phase Switch 0-180
• Remote Dash Mount Low Level Gain
Control With Cable
• Frequency Response: 15Hz to 150hz
• S/N Ratio: 100 db
• Hi Speed Digital Circuitry
• Fully Regulated PWM Power Supply
• Four Way Protection Circuit
• 1 Ohm Stable
• Bridging Synchronization
• Variable Low Pass 50Hz-150Hz
• THD: 0.5%
• System Distress Indicator
• Inputs Sensativity: 200mv-8v
• Dual Mono Speaker Output Connectors
• Gold Plated Heavy Duty Power &
Speaker Terminals
08|
Common Features For Class D Series:
For Class D Series:
For Class A/B Series:
spl06 2006-4-9 15:21 Page 9
• Cloth laminated paper cone with MD6 coating
• Dual 1 ohm voice coil
• Die cast aluminum basket
• Aluminum/chrome dust cap for extra rigidity
under extreme conditions
• Black wrinkle finish with Diamond cut
• Chrome finish front & back plate
• Large roll treated foam surround
• One piece, 360º rubber gask
• Dual conex spider
• Woven tinsel lead through spider
• Chrome binding post terminals
SPLW-10
• 2200 watts power handling
• 1000 watts RMS
• 270 oz. magnet
• 3” BASV/Kapton hybrid 18 AWG voice coil
• FS 32(Hz)
• Vas 0.5 cu.ft.
• Qes: 0.359 • Qms: 3.53 • Qts: 0.23
• Xmax: 0.4”
• SPL89 dB
• Sealed box: N/A
• Ported box: 1.65 cu. ft.
• Tuning: 45 Hz
• Port size: 3” (dia) x 9.25” (length)
• # of ports: 2
• Mounting Depth:6.4”
SPLW-12
• 2200 watts power handling
• 1100 watts RMS
• 340 oz. magnet
• 4” BASV/Kapton hybrid 18 AWG voice coil
• FS 33.5(Hz)
• Vas 0.8 cu.ft.
• Qes: 0.34 • Qms: 5.668 • Qts: 0.32
• Xmax: 0.47”
• SPL90 dB
• Sealed box: N/A
• Ported box: 2.4 cu. ft.
• Tuning: 40 Hz
• Port size: 4” (dia) x 16.75” (length)
• # of ports: 2
• Mounting Depth:7.25”
SPLW-15
• 2800 watts power handling
• 1400 watts RMS
• 340 oz. magnet
• 4” BASV/Kapton hybrid 18 awg voice coil
• FS 29.1(Hz)
• Vas 1.6 cu.ft.
• Qes: 0.52 • Qms: 4.06 • Qts: 0.31
• Xmax: 0.59”
• SPL92 dB
• Sealed box: N/A
• Ported box: 3.4 cu. ft.
• Tuning: 40 Hz
• Port size: 4” (dia) x 10” (length)
• # of ports: 2
• Mounting Depth:8.9”
Common Features:
wood case packaging
|09
subwoofers If you want bass that leaves a lasting
impression with your friends and neighbors, the
SPLW line of woofers does it all. Specifically
designed for use in a ported box to give you
the ultimate in heart pounding, vision-blurring
bass.
SPLW
Dual 1ohm Extreme competition Subwoofers
