Please carefully read this entire manual before operating your new tness bike
OWNER’S MANUAL
Fitness Bike
XBR95
Table of Contents
1
2
3
4
9
11
15
26
28
29
Product Registration
Important Safety Instructions
Important Electrical Instructions
XBR95
Assembly Instructions
Product Features
Operation of Your Console
Programmable Features
Using A Heart Rate Transmitter
General Maintenance
Manufacturer’s Limited Warranty
ATTENTION
This tness bike is intended for residential use only and is warranted for this
application. Any other application voids this warranty in its entirety.
2
Fitness Bike
XBR95
1Fitness Bike
XBR95
Record Your Serial Number
Please record the serial number of this tness product
in the space provided below.
Serial Number
Register Your Purchase
The self-addressed product registration card must be completed in full and returned to Spirit
Fitness. You can also go to https://www.spirittness.com/residentialwarrantyregistration.html
to register online.
Thank you for your purchase of this quality group tness bike from Spirit Fitness. Your new
tness bike was manufactured by one of the leading tness manufacturers in the world and is
backed by one of the most comprehensive warranties available. Through your dealer, Spirit Fitness
will do all we can to make your ownership experience as pleasant as possible for many years to
come. If not purchased direct from Spirit Fitness, the local dealership where you purchased this
tness bike is your administrator for all Spirit Fitness warranty and service needs. Their responsi-
bility is to provide you with the technical knowledge and service personnel to make your experi-
ence more informed and any difculties easier to remedy.
Please take a moment at this time to record the name of the dealer, their telephone number,
and the date of purchase below to make any future, needed contact easy. We appreciate your
support and we will always remember that you are the reason that we are in business. Please
complete and mail your registration card today and enjoy your new tness bike.
Yours in Health,
Spirit Fitness
Congratulations on your new tness bike and welcome to the Spirit Fitness family!
Name of Dealer
Dealer Phone #
Purchase Date
XBR95_20110623
Product Registration
2
Fitness Bike
XBR95
Important Safety Instructions
WARNING - Read all instructions before using this appliance.
Do not operate tness bike on deeply padded, plush or shag carpet. Damage to both carpet
and tness bike may result.
Keep children away from the tness bike. There are obvious pinch points and other
caution areas that can cause harm.
Keep hands away from all moving parts.
Never drop or insert any object into any openings.
Do not use outdoors.
Do not attempt to use your tness bike for any purpose other than for the purpose it is
intended.
The hand pulse sensors are not medical devices. Their purpose is to provide you with an ap-
proximate measurement in relation to your target heart rate. Use of a chest transmitter strap
is a much more accurate method of heart rate analysis . Various factors, including the user’s
movement, may affect the accuracy of heart rate readings. The pulse sensors are intended
only as exercise aids in
determining heart rate trends in general.
Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on
your tness bike. Quality athletic shoes are recommended to avoid leg fatigue.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
3Fitness Bike
XBR95
Important Operation Instructions
WARNING!
NEVER expose this tness bike to rain or moisture. This product is NOT designed for use
outdoors, near a pool or spa, or in any other high humidity environment. The operating
temperature specication is 40 to 120 degrees Fahrenheit, and humidity is 95%
non-condensing (no water drops forming on surfaces).
NEVER operate this tness bike without reading and completely understanding the
results of any operational change you request from the computer.
Understand that changes in resistance do not occur immediately. Set your
desired resistance level on the computer console and release the adjustment key.
The computer will obey the command gradually.
Use caution while participating in other activities while pedaling on your tness bike; such as
watching television, reading, etc. These distractions may cause you to lose
balance which may result in serious injury.
Do not use excessive pressure on console control keys. They are precision set to function
properly with little nger pressure.
4
Fitness Bike
XBR95
Assembly Tools
1. Using a razor knife (Box Cutter), cut the banding straps that wrap around the carton. Reach under the bottom
edge of the carton and pull it away from the cardboard underneath, separating the staples that join the two
together. Lift the box over the unit and unpack.
2. Carefully remove all parts from carton and inspect for any damage or missing parts. If damaged parts are
found, or parts are missing, contact your dealer immediately.
3. Locate the hardware package. The hardware is separated into four steps. Remove the tools rst. Remove the
hardware for each step as needed to avoid confusion. The numbers in the instructions that are in parenthesis
(#) are the item number from the assembly drawing for reference.
Pre-Assembly
XBR95
Assembly Instructions
To assist you in assembling your new Spirit Fitness tness bike, we have posted an assembly video at the
following link: http://www.spirittness.com/customerservice/video/tnessbikevideos.html
Assembly Video
#114.Phillips Head
Screwdriver
#115.L Allen Wrench
#112.12/14mm
Wrench
#130.13/14mm
Wrench
#113.13/15mm
Wrench
5Fitness Bike
XBR95
1. Attach the Rear Stabilizer (7) to the Main Frame (1) with the four Hex Head Bolts (65) and four Flat Washers
(84). Tighten completely with the wrench (112).
2. Attach the Seat Back (5) to the Seat Carriage (4) of the main frame. Slide a Hex Head Bolt (67) through each
side, then attach a Nyloc Nut (89) to each bolt. Tighten the bolts just enough so there is no side to side play, but
freedom of movement front to back. Use the wrenches provided (112 & 130).
HARDWARE
STEP 1: Rear Stabilizer & Seat Back
#89.3/8” x 7T
Nyloc Nut
(2 pcs)
#84.3/8” x 25 x 2T
Flat Washer
(4 pcs)
#65. 3/8” x 2-1/4”
Hex Head Bolt (4
pcs)
#67.3/8” x 4”
Hex Head Bolt
(2 pcs)
6
Fitness Bike
XBR95
1. Slide the Computer Cable (44), Handlebar resistance control cable (148), and Hand pulse cable (133) through
the bottom of the Console Mast Cover (31) and then the bottom of the Console Mast (2). Make sure the
Console Mast Cover is correctly oriented (see illustration).
2. Install the Console Mast (2) into the receiving tube (make sure not to pinch cables; damage to the electronics
could occur) of the Main Frame (1). Insert two Hex Head Bolts (68) and two Flat Washers (76) on each side.
Insert two Hex Head Bolts and two Curved Washers (83) on the front. Tighten all six bolts rmly with the
Wrench (112).
3. Remove the white Styrofoam pad (factory installed to prevent bolts from being accidentally dropped into the
console mast tube).
4. Attach the Handle Bar Assembly (3) onto the Console Mast (2) bracket with the two Hex Head Bolts (68),
two Split Washers (82), and two Flat Washers (76). Completely tighten with the wrench (112).
5. Insert the Computer Cable (44), Handlebar resistance control cable (148), and Hand Pulse Cable (133) into
their respective connectors in the back of the Console Assembly (19). Attach the
console onto the mounting plate with four Phillips Head Screws (99). Tighten with the Phillips Head Screw
Driver (114).
HARDWARE
STEP 2: Console Mast
#82.8 x 1.5T
Split Washer
(2 pcs)
#83.5/16” x 19 x 1.5T
Curved Washer
(2 pcs)
#76.5/16” x 18 x 1.5T
Flat Washer
(6 pcs)
#68.5/16” x 15mm Hex
Head Bolt
(8 pcs)
#99.M5 x 12mm
Phillips Head Screw
(4 pcs)
