Corso
USER MANUAL
Electric Assist Bicycle
Please read the manual carefully before riding.
Please store the manual well in case needed in the future.
ENGLISH
FIRST EDITION BIKE
Corso
About Manual
Thanks for purchasing our products.
To make sure that you can use the product correctly, please
carefully read the full manual before driving it.
This manual contains important safety use instructions.
Spinta Corso Brief Introduction ................................................................................................. 04
Spinta Corso Specications .......................................................................................................05
Products Diagram ........................................................................................................................06
Meter Function ..............................................................................................................................07
Meter Operation ............................................................................................................................08
Initial Assembly Steps .................................................................................................................09
How to connect Bluetooth Speaker ..........................................................................................10
Safety Usage .................................................................................................................................11
Spinta Corso Daily Maintenance ...............................................................................................13
Common Troubleshooting .........................................................................................................17
After-sales service .......................................................................................................................19
Warranty Record ...........................................................................................................................20
Warranty Process .........................................................................................................................21
Catalogue
Package including
Spinta Corso bike x 1, charger x 1, tool kit x 1, user manual x 1,
warranty card x 1, certicate x 1
Corso
4 Spinta Corso Brief Introduction
With the trends of internet+objects, articial intelligence, and low-carbon environment protection, our
transportation methods are changing. Combining leading industrial technology, modern innovative
processes, we accomplished a top quality Spinta Corso e-bike. We’re dedicated to producing
intelligent, multifunctional, fashionable and stylish stylish products with compact design, bringing
you a healthier, more fashionable transporter, helping more riders enjoy an enviroinmentally-friendly
and enjoyable.
SPINTA CORSO
BRIEF INTRODUCTION
5Spinta Corso Specications
SPINTA CORSO
SPECIFICATIONS
Item
Nominal Voltage
Battery
Max Mileage
Motor Power
Motor Type
Motor Torque
Battery Type
Charger
Charging time
Electricity consumption per charge
Frame Material
Net Weight
Max Loading Weight
Waterproof Level
Controller Over - curren protection
Controller Under - voltage protection
Tyre
Controller power tube
Brake method
Product Dimension
Package Dimension
Specications
36V
36V/5.8AH
50-60KM
240W
German technology high speed brushless gear motor
10N.M
18650 Lithium battery
110-240V; 50-60Hz
2.5 - 5H
0.27 K W H
Aluminum 6061 - T6
16.5kg
120kg
IPX4
13 A
31.5 V
20 inch inflatable tyre
6 tubes
Mechanical disc brake
1590 x 1015 x 595mm
1400 x 230 x 850mm
6 Products Diagram
PRODUCTS
DIAGRAM
Smart meter
Handle bar
Mechanical brake
lever
Aluminum frame
Front relector/light
Front fork
Power on/off
Bluetooth speaker
(Option)
Quick-release
front wheel
Charging port
Controller
Sensor
Saddle
Rear reflector/light
Seat Post
Mud guard
Disc brake
Brushless gear
motor
Kickstand
Magnesium alloy
integrated wheel
(Option spoked
wheel)
Inflatable tyre
Chain
7Meter Function
METER
FUNCTION
Brake
Motor error
Controller error
Speed
Riding time
Total mileage
Single trip mileage
Odometer
Sensor error
Battery 1
Battery 2
Miles per hour
Kilometres per hour
Gear
Mile
Kilometre
Power
8 Meter Operation
Turn on power switch, and the meter will light up.
Press on the left side of the meter button to choose power output mode.There are 4 gears
to shift, as follow:
• “0” gear - 0% assist
Fitness mode: motor power output 0%, suitable for sport and exercising.
• “1” gear - 25% assist
Aerobic mode : motor power output 25%, lower consumption, longer range, suitable for aerobic
ride exercising .
• “2” gear - 50% assist
ECO mode: motor power output 50%, moderate consumption, suitable for outdoor leisure or
riding on flat roads.
• “3”gear - 90% assist
Climbing mode : motor power output 90%, suitable for slope climbing or fast trips.
Press on the right side meter button to choose ‘meter display’, as follow:
• , single trip riding mileage (km)
• , total riding mileage (km), once press the right side meter button
• , single trip riding time(h), twice press the right side meter button
• Long press the right side meter button for 2 seconds, can display plug-in battery capacity
(applicable for bike with plug-in battery pack).
METER
OPERATION
Please note
1. Please shut off the battery when the bike is unused.
2. Please charge the bike every 60 days if you do not use it, to
prevent the battery from breaking down and ceasing to function.
9Assemble Steps
INITIAL
ASSEMBLY STEPS
Step 1
In the packaging of the Spinta Corso you will nd
the handlebar in parallell position to the front
Wheel.
Step 2
Turn the handlebar perpendicular to the front
Wheel.
Step 3
Fix the steering screws (right and left).
10 How to connect Bluetooth Speaker
1. The valid range for the bluetooth speaker is 0-10m and and is normally best within 5 m.
2. How to connect the bluetooth speaker: Turn on the bluetooth of your mobile/pad, search nearby
Bluetooth devices, nd “E-scooter” and connect it (once connected it only accepts one phone/pad).
HOW TO CONNECT
BLUETOOTH SPEAKER
