Speed Queen SCN080GF Instructions d'installation

QUANTUM STANDARD OPL CONTROL

For laundry managers requiring basic management options,Quantum

Standard comes with four cycle selections, two water levels and manual

programming. It also offers a maximum extraction speed of 100 G-force.

For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The

quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.

Printed in the U.S.A.

speedqueen.com

© 2012 Alliance Laundry Systems LLC AO11-0682R1

ON-PREMISES LAUNDRY HARDMOUNT SCN080GF

FEATURES & BENEFITS

• Advancedwaterprotectionalertsownersifthe

washerhasastuckdrain,slowdrainconditionor

leakinginletvalve,whichhelpsconservewater.

• Ruggeddoorhandleandnewlockmechanism

ensureeasyopeningandclosingandreliablelocking

—nomoredoorlockerrorcodes.

• Newdualtriple-lipsealsandastainlesssteelsleeve

aroundthetrunnion,deliverthestrongestlineof

defenseinprotectingthebearingsagainstthe

damagingeffectsofmoisture.

• Four-compartmentchemicaldispenseradds

chemicalsattherighttime,automaticallysaving

stafftime.Thenewdispenserdesigneliminates

over-sudsingconditions.

PRODUCT SPECIFICATIONS

SCN080GF

Capacity 80 lb

Width 41 1/2”

Depth 51 1/2”

Height 56 3/16”

Cylinder Diameter 36”

Cylinder Depth 22”

Cylinder Volume 12.4 cu. ft.

Door Opening Size 18 1/2”

Door Bottom to Floor 17 3/4”

Wash Speeds 39 RPM

Extract Speed 443 RPM

Distribution Speed 70 RPM

Extract G-Force 100

Water Inlet 2 @ 3/4”

Drain Diameter 1 @ 3”

Drain Height To Floor 5 3/4”

Motor Size 5 HP

Electrical Specs

Voltage/Hz/Phase

X 200-208/220-240/50/60/1/3

Q 200-208/220-240/50/60/3 (electric heat)

P 380-415/50/60-3

N 440-480/50/60/3

Net Weight 1262 lb

Shipping Weight 1275 lb

Shipping Width 48”

Shipping Depth 56”

Shipping Height 65 3/4”

Agency Approvals cETLus, CE
