QUANTUM STANDARD OPL CONTROL

For laundry managers requiring basic management options,Quantum

Standard comes with four cycle selections, two water levels and manual

programming. It also offers a maximum extraction speed of 100 G-force.

For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The

quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.

Printed in the U.S.A.

speedqueen.com

© 2012 Alliance Laundry Systems LLC AO11-0679R1

ON-PREMISES LAUNDRY HARDMOUNT SCN060GF

FEATURES & BENEFITS

• Advancedwaterprotectionalertsownersifthe

washerhasastuckdrain,slowdrainconditionor

leakinginletvalve,whichhelpsconservewater.

• Ruggeddoorhandleandnewlockmechanism

ensureeasyopeningandclosingandreliablelocking

—nomoredoorlockerrorcodes.

• Newdualtriple-lipsealsandastainlesssteelsleeve

aroundthetrunnion,deliverthestrongestlineof

defenseinprotectingthebearingsagainstthe

damagingeffectsofmoisture.

• Four-compartmentchemicaldispenseradds

chemicalsattherighttime,automaticallysaving

stafftime.Thenewdispenserdesigneliminates

over-sudsingconditions.

PRODUCT SPECIFICATIONS

SCN060GF

Capacity 60 lb

Width 34 1/16”

Depth 42 9/16”

Height 49 7/8”

Cylinder Diameter 30”

Cylinder Depth 22”

Cylinder Volume 9 cu. ft.

Door Opening Size 16 1/4”

Door Bottom to Floor 15”

Wash Speeds 43 RPM

Extract Speed 485 RPM

Distribution Speed 72 RPM

Extract G-Force 100

Water Inlet 2 @ 3/4”

Drain Diameter 1 @ 3”

Drain Height To Floor 4 11/16”

Motor Size 3 HP

Electrical Specs

Voltage/Hz/Phase

X 200-208/220-240/50/60/1/3

Q 200-208/220-240/50/60/3 (electric heat)

P 380-415/50/60-3

N 440-480/50/60/3

Net Weight 743 lb

Shipping Weight 769 lb

Shipping Width 38”

Shipping Depth 49”

Shipping Height 59 3/8”

Agency Approvals cETLus, CE
