V1.3 Creation on Jan22nd2013
King Golden Ltd. Speed Passion Reventon Bluetooth Unit User Manual P a g e | 2
1.2 Connect the Bluetooth Unit (RF port) to the Receiver.
1.3 Connect the Bluetooth Unit (ESC port) to the ESC.
1.4 Turn on the ESC. The Blue LED will flash continuously until the Bluetooth Unit is connected
with a smart-phone.
1.5 If the connection to the ESC is OK, the user can open the Speed Passion App and the ESC data
will be sent to the smart-phone. (Reference to point 4)
1.6 The Bluetooth Unit supports ESC security codes for different users. When the user press and
holds the “Setup” key over 3 seconds, the Unit will enter setup mode and the “Red LED” will
flash continuously. User can use the Speed Passion App to set the pin code (Reference to
point 5).
1.7 If the password has been lost or forgotten, the user can press and hold the “Default Setting” key for
3 seconds. The Bluetooth configuration will return to factory settings as shown below:
