Speco Technologies is constantly developing product improvements. We reserve the right to modify product

design and specifications without notice and without incurring any obligation. Rev. 11/10/09.

DVR4WM/8WM/16WM

Setup Guide

Speco Technologies

200 New Highway

Amityville, NY 11701

800-645-5516

www.specotech.com

DVR4WM/8WM/16WM

Setup Guide

Package Content

Inspect the DVR’s packaging. Make sure that the DVR-4WM/8WM/16WM is packed properly.

Remove all items from the box and make sure it contains the following items.

DVR-4WM/8WM/16WM Remote

Control Power

Adaptor Power Cord Quick

Guide

Internal Connections

1 LAN 10/100M

(RJ-45) The DVR is capable of networking. Once the unit is connected to the LAN network, users can

remotely access the DVR through the remote software and SpecoRemote on a PC.

2 USB Port The USB 2.0 port allows users to connect an external USB device to the unit, such as a USB

ThumbDrive or Flashdrive.

3 Alarm I/O &

RS-485

The DVR provides alarm I/O and RS485 ports that offer users the flexibility required to connect

the DVR to other devices.

4 Main

Monitor-

BNC The DVR can connect to a monitor via a BNC connector.

5 Call Monitor

(BNC) The call monitor is used to display full screen video of all installed cameras in sequence. The

BNC Call Monitor connector allows users to connect the DVR with an optional call monitor.

6 Video In

(BNC) A group of BNC connectors is provided for video input streams from installed cameras.

1 3 4 5 6

2 7 8 9 10

7 Main Monitor

Audio Out Main Monitor Audio Out RCA connector is provided for the DVR to connect an audio output

device (e.g. an amplified speaker).

8 Call Monitor

Audio Out

Call Monitor Audio Out RCA connector is provided for the DVR to connect an audio output

device (e.g. an amplified speaker).

9 Audio In

Audio In connectors are for the DVR to connect audio source devices. For DVR-4WM, 4 RCA

Audio In connectors will be provided; whereas for DVR-8WM and DVR-16WM, a D-Sub Audio

In connector is provided.

10 Power Jack The DVR has a free voltage DC power connection jack. Please connect the power supply

adapter shipped with the unit.

Pin Definition of Alarm I/O & RS-485, and Audio In

Alarm I/O & RS-485:

DVR-4WM:

Pin Definition Pin Definition Pin Definition Pin Definition

1 Alarm Out Open 5 Alarm In 1 9 Alarm Out Close 13 GND

2 Alarm Out COM 6 Alarm In 2 10 GND 14 GND

3 RS485 D+ 7 Alarm In 3 11 GND 15 GND

4 RS485 D−8 Alarm In 4 12 GND

15pin D-sub connector I/O cable for 4TL: Speco # DVR4TLALMCBL

DVR-8WM & DVR-16WM:

Pin Definition Pin Definition Pin Definition

1 Alarm Out Open 10 Alarm In 5 19 Alarm In 10

(DVR-16WM)

2 Alarm Out COM 11 Alarm In 6 20 Alarm In 11

(DVR-16WM)

3 RS485 D+ 12 Alarm In 7 21 Alarm In 12

(DVR-16WM)

4 RS485 D−13 Alarm In 8 22 Alarm In 13

(DVR-16WM)

5 Reserved 14 Alarm Out Close 23 Alarm In 14

(DVR-16WM)

6 Alarm In 1 15 Reserved 24 Alarm In 15

(DVR-16WM)

7 Alarm In 2 16 Reserved 25 Alarm In 16

(DVR-16WM)

8 Alarm In 3 17 Reserved

9 Alarm In 4 18 Alarm In 9 (DVR-16WM)

25p D-sub I/O cable for 8/16TL: Speco # DVR816TLALMCBL

Audio In (DVR-8WM & DVR-16WM only):

Pin Definition Pin Definition Pin Definition

1 Audio 1 10 GND 19 Audio 12 (DVR-16WM)

2 Audio 3 11 GND 20 Audio 14 (DVR-16WM)

3 Audio 5 12 GND 21 Audio 16 (DVR-16WM)

4 Audio 7 13 Reserved 22 GND

5 Audio 9 (DVR-16WM) 14 Audio 2 23 GND

6 Audio 11 (DVR-16WM) 15 Audio 4 24 GND

7 Audio 13 (DVR-16WM) 16 Audio 6 25 Reserved

8 Audio 15 (DVR-16WM) 17 Audio 8

9 GND 18 Audio 10 (DVR-16WM)

25p D-sub Audio cable for 8/16TL: Speco # DVR816TLAUDCBL

Power On the DVR

Please follow the proper power on procedures to avoid damaging the DVR.

•Connect all necessary components, e.g. monitor and cameras, before powering the DVR.

•Check the type of power source before connecting the power adaptor to the DVR. The

acceptable power input is between AC110V ~ AC240V.

Basic Setup

Enter the OSD main menu to setup some basic configurations of the DVR. The basic configuration

must be set with the OSD on the DVR.

Enter OSD Main Menu:

•Press MENU button on the remote controller to enter the OSD main menu.

•Enter username and password. The default username and password is admin and 1234.

•Press MENU again to quickly input the default username “admin”.

•It is strongly suggested to change the password to prevent unauthorized access.

Date / Time Setting:

Follow steps below to setup date/time before the recording starts.

•Select <Date/Time> in System Setup menu.

•Select the date and time using LEFT/RIGHT keys; then adjust the value using UP/DOWN

keys.

•The new date and time settings take effect after the changes are confirmed.

Language Setting:

If users wish to change language of the DVR system, follow the steps below.

•Select <Language> in System Setup menu and press ENTER.

•Press the UP/DOWN keys to select the desired language.

Hard Drive Format

After users have finished changing the time, they must format the drive or they will not be able to

review recorded data.

•Select <Database Setup> in the System Setup and press ENTER.

•Select <Internal Disks> and press ENTER.

•Press ENTER on the Device Name. <None> will begin to flash.

•Use the UP/DOWN keys to change <None> to <Format>.

•Press ENTER again and the drives will format.

•Press ESC to escape the menu when the drives have reached 100%.

Network Setup

Configure the LAN setup for the DVR to properly function with Ethernet connection.

•From OSD main menu, select <System Setup> Æ<Network Setup>, set the <LAN Select>

item to <LAN> or <PPPoE> according to the network application, and enter <LAN Setup>.

•For DHCP, set the DHCP to <ON>. The IP address, Netmask, Gateway and DNS settings are

retrieved from network servers. DHCP is dynamic and the settings change from time to time.

•For Non-DHCP users, set the DHCP to <OFF>. Enter an IP address, Netmask, Gateway, and

DNS settings. Please obtain the information from the network service provider.

•To change the IP address, Netmask, Gateway and DNS value, press UP/DOWN keys to move

the cursor to the item. Use LEFT/RIGHT keys to access each section of the value and press

ENTER, then change the value using UP/DOWN keys.

•PPPoE users must set the <PPPoE Account>, <PPPoE Password> and <PPPoE Max Idle>

as well.

•When the settings are complete, press ENTER to confirm and save the settings; or ESC to

abort.

Dome Camera Control

Dome Camera Connection & Settings:

•See section Pin Definition of Alarm I/O & RS-485, and Audio In for RS-485 port pin definition.

•Connect the R+, R- terminals on the dome camera to the D+, D- terminals on the RS-485 port

by RS-485 cable respectively.

•To set up dome camera’s protocol and ID, press MENU to access the OSD main menu or

change the protocol and ID by using SpecoRemote, and select <Camera Setup>. The available

protocols include <Speco>, <DSCP>, <AD422>, <Pelco D>, <Pelco P>, <Fastrax 2>, <JVC>,

<Panasonic_C>, and <Panasonic_N>. The default is <None>. Note that ID number must

match the ID address defined by the dome camera.

•To configure the RS-485 parameters, select <System Setup> from OSD main menu or through

SpecoRemote, and then select <RS485 Setup>. The default RS-485 settings are 9600 Baud, 8

Data Bits, 1 Stop Bit and No Parity.

Connect the DVR via SpecoRemote

Setup Requirements:

•Make sure the PC is connected to the Internet.

•Obtain IP address of the DVR-4WM/8WM/16WM. To check the DVR’s IP address, press MENU

on the remote controller and select <System Setup> Æ<Network Setup> Æ<LAN Setup> Æ

<IP> to check the IP.

Changing Internet Setting:

•Start the IE; select <Tools> from the main menu of the browser, then <Internet Options> and

then click the <Security> tab.

•Select <Trusted sites> and click <Sites> to specify its security setting.

•Uncheck “Require server verification (https:) for all sites in this zone”. Type the IP address of the

unit in field and click <Add> to add this website to the zone.

•In the Security Level area, click <Custom Level>. Under <ActiveX controls and plug-ins>,

set all items to <Enable> or <Prompt>.

•Click <OK> to accept the settings and close the <Security Settings> screen.

Using SpecoRemote:

•Start IE and enter the IP address of the DVR-4WM/8WM/16WM in the address bar.

•The ActiveX controls and plug-ins dialog will show twice for confirmation; click <YES> to accept

ActiveX plug-ins. The SpecoRemote plug-ins will be downloaded and installed on the PC

automatically when the connection is successfully made.

NOTE: Do not enter any leading “0” characters in the address, for example,

“192.068.080.006” should be entered “192.68.80.6”.

NOTE: If the default trigger port 80 is changed into another one, port 81 for example,

then the IP address should be entered as “192.68.80.6:81”.

•Version verification starts automatically to verify whether SpecoRemote was installed. This

process may take up to 30 seconds.

•When the software is completely downloaded and installed, the Login Screen is displayed.

•Enter the username and password. The default usernames and passwords are admin / 1234

and user / 4321.

The following picture shows the display window of the SpecoRemote:

Refer to the table below for brief description of functional items:

Item Description Item Description

1 Instant Recording 10 Search Event List

2 Smooth the Image 11 Capture Snapshot

3 Deflicker On/Off at Playback 12 4:3 Viewing Aspect

4 Audio On/Off 13 HDD Status

5 Select Camera 14 Playback Control

6 Display Mode 15 Select Picture Size

7 View Live Camera 16 Select Bandwidth Speed

8 Playback Video 17 Download DVRPlayer

9 Setup Menu

For more information on SpecoRemote, see User’s Manual.

SpecoRemote Playback

Playback Remote Video:

•Click <Play> on the main window toolbar, and then <Remote Playback> tab.

•The <From> and <To> on top of the screen display the date and time from which recorded

video is available for playback.

•Choose <Playback> in <Select> field for playback recorded video.

•Select the date and time of the segment to playback from the <Start> field. The date and time

can be changed either by typing desired numbers direcWMy or using the arrow buttons.

•Click <OK> to start the playback, or click <Close> to abort.

Playback Local *.drv File:

•Click <Play> on the main window toolbar, and then <Local Playback> tab.

•Click <Open> and the file selection screen is displayed. Select the *.drv video file to playback

and click <OK>.

•Click <OK> to start the playback, or click <Cancel> to abort.

•View the video playback using the Playback controls.

•To end the playback, click <Live> to return to live video.

Playback Local *.avi Files:

•Start the windows media player or other media player from <Start> menu (or any other possible

access).

•Select <File> and then <Open>.

•Select the wanted *.avi file, and click <Open>.

NOTE: The *.avi files for each channel are stored separately. Therefore the video can

be played back in single channel, full screen mode only.

Playback Event Video

•Click SEARCH on the main window toolbar. The Event List appears.

•Scroll through the Event List and highlight the interested events.

•Double-click on the desired event to view the event video.

Playback Controls:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Speco DVR

Speco

Speco D16DS Manuel utilisateur

Speco

Speco EZVR4 Manuel utilisateur

Speco

Speco NRL Manuel utilisateur

Speco

Speco D8HT Manuel utilisateur

Speco

Speco DVR-4TH Series Manuel utilisateur

Speco

Speco DVR-IP4CF Manuel utilisateur

Speco

Speco DVRPC16P48 Manuel utilisateur

Speco

Speco DVR-T4IP Manuel utilisateur

Speco

Speco DVR-16 Manuel utilisateur

Speco

Speco H.264 4-Channel Mobile D4M Manuel utilisateur

Speco

Speco N32NRE Manuel utilisateur

Speco

Speco N16NRN Manuel utilisateur

Speco

Speco DVRM42 Manuel utilisateur

Speco

Speco D4CX Manuel d'instructions

Speco

Speco D8HU Manuel utilisateur

Speco

Speco PC Pro Series Manuel utilisateur

Speco

Speco DVR-16 Manuel utilisateur

Speco

Speco N32NRN Manuel utilisateur

Speco

Speco DVR-16 Manuel utilisateur

Speco

Speco N64NR24TB Manuel utilisateur

Speco

Speco H16HRL Manuel utilisateur

Speco

Speco DVR-4TN Series Manuel utilisateur

Speco

Speco D8DS Manuel utilisateur

Speco

Speco DVR-16 Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur

DIGIFUSION

DIGIFUSION FVRT150 Manuel utilisateur
