READ THIS FIRST
BEFORE YOU START:
• ParaGlo cables can be shortened to suit individual installation requirements. Spa Electrics
recommends all cabling is protected by conduit and that a junction box (or similar) is
incorporated into pool cabling design to avoid siphoning.
• Ensure that the lighting system is installed by a qualified person (e.g. Registered pool builder
and/or licenced electrician), in accordance with the most current edition and/or amendment of
the NEC wiring code.
• For safe and proper installation, ensure that only those parts supplied with the system are used.
• Maximum installation depth for the ParaGlo 6” Light (WN950) is 1M (40”) below nominal water
level (to top of light)
• The ParaGlo 6“ Light (WN950) Must be correctly installed in or on the wall of the pool with the top
of the lens no less than 4” below the nominal water level.
• All lights should be mounted in a location that is easily accessible without the need for entering
or lowering the pool water.
• At least 2.5ft of cable must remain stored within the Niche to ensure the light can be accessed
above the waterline. (Maximum cable within niche :18AWG /16AWG = 8ft).
CLEANING
• Only use warm water and a soft brush or cloth to clean ParaGlo series lights. DO NOT use
detergents or spirits as this can damage the light and void your warranty.
USE
• Do not operate light unless completely submerged in water.
• Operating the light for at least 15 minutes every week is advised (all year round).
• ParaGlo lights are suited for both domestic and commercial installations and can be operated
continuously (24/7) if required.
•Temperature range for installation, operation and servicing: +32oF ~ +104oF (0oC ~ +40oC)
The ParaGlo 6” Light must only be used with a UL listed 12V AC Class 2 power supply or a
power source intended for swimming pool use (not included).
Minimum power source wattage requirement - 15 Watts per light.
• DO NOT use electronic or switch-mode power supplies with WN950-series lights. These power
supplies will damage the light and void your product warranty.
• Pool chemicals & PH levels: Due to the corrosive nature of unbalanced pool chemicals, Spa
Electrics strongly recommend that your pool water is balanced prior to installing your pool lights or
any plastic or stainless steel components, and tested weekly to maintain these levels. pH levels
should be maintained between 7.2 – 7.6 at all times to ensure the longevity of these components.
> Failure to do so can result in chemical damage to the light housing and pool fittings,
including stainless steel components.
> Please note: Lights or components found to have excessive chemical damage will not
be covered under our manufacturer’s warranty policy
• This light contains no user-serviceable parts; opening the light will void the product warranty.
WARNING
Congratulations on your purchase of a ParaGlo underwater lighting system.
All ParaGlo lights are manufactured by Spa Electrics in Australia from only the highest quality
materials and exclusively distributed through Paramount Pool & Spa Systems, USA.
