Not for general waste. Please contact your local authority on how to dispose correctly.
Installation & Maintenance instructions for S16WLED 16W.
Important Information
If you do not feel fully confident when dealing with electrical procedures, seek the advice of a qualified electrician.
This product must be installed in accordance with the current building and IEE wiring regulations.
Switch off the mains before commencing installation. These products are designed for connection to a 240V 50Hz
supply. Any broken or damaged parts should be replaced as soon as possible. We will not accept responsibility for any
claims arising from a poor installation. This product is suitable for outdoor use IP65.
Please note emergency packs/batteries carry a 12 month warranty.
LEDs are an inductive lead and may have higher inrush currents, it may be necessary to update your MCBs to
compensate.
Specification
Installation:
●Isolate supply voltage before working with electrics.
●Remove trim and diffuser by turning anti-clockwise.
●Loosen but do not remove the three LED gear tray supporting screws, rotate the tray and allow it to hang on the
support strap.
●Pass supply wires through grommet into the base section, taking care to ensure they are not trapped between the
fitting and mounting surface.
●Fix base section to the wall or ceiling. Use adequate fixings with regard to type of surface being fixed to.
FIG 1 - Wiring instructions for non-emergency units.
●Connect incoming neutral cable (blue wire) to the neutral terminal on connector block.
●Connect incoming live cable (brown wire) to the live terminal on the connector block.
●Connect incoming neutral cable (blue wire) to the neutral terminal on connector block.
●Connect incoming live cable (brown wire) to the switch live terminal on the connector block.
●Connect incoming permanent live cable (black wire) to the permanent terminal on the connector block.
●You must complete a FULL discharge and then a further 24 hour recharge prior to testing & full operation.
Microwave Technical Specification
2lux / 10lux / 50lux / disable
Neutral - Blue
Earth
Live - Brown
Neutral - Blue
Earth
Live - Brown
Mains Supply Luminaire
FIG 2 – Wiring Instructions for emergency units
Neutral
Earth
Switched Live
Live
Neutral
Earth
Switched Live
Live
Mains Supply Luminaire
318mm
82mm
Installation & Maintenance
S16WLED-WH, S16WCCT-WH, S16W EME CCT,
S16W SEN WH CCT, S16W EM SENS CCT
Unit 7/8 Ashbourne Business Centre, Ballybin Road, Ashbourne, Co. Meath, Ireland, A84 YP58,
Phone: 00353 1 835 7447
Unit 32 Junction One Business Park, Valley Road, Birkenhead, Merseyside, UK, CH41 7ED,
UK Ph: 0330 551 7000
Website: www.sgd.ie
For more information contact:
Detection area, hold time and daylight sensor can be set by using DIP switches
on the sensor. Note that reducing the detection area will also reduce the sensitivity.
Question
SETTINGS
1, Detection area
I: up to 100%
II: up to 75%
III: up to 50%
IV: up to 25%
V: up to 10%
2, Hold time
Refers to the time period the lamp remains at
100% illumination after no motion is detected.
I: 5s
II: 30s
III: 90s
IV: 3min
V: 20min
VI:30min
3,Daylight sensor
The sensor can be set to only allow the lamp to
illuminate below a defined ambient brightness
threshold. The settings are as follows:
I: 2lux, darkness operation only
II: 10lux, darkness operation only
III:25lux, twilight operation
IV:50lux, twilight operation
V:Disable
*When set to Disable, the daylight sensor will switch on the lamp when motion
is detected regardless of ambient light levels.
The load will
not illuminate
Incorrect daylight
sensor setting selected.
Load has failed.
Power is switched off. Switch on.
Adjust setting.
Replace load.
Continuous movement in the
detection area.
The lamp (containing sensor) is
installed in an area too close to
reflective surfaces, i.e. metal,
glass or concrete walls.
Check detection area setting.
1, Make sure installation area
suitable with at least 30cm space
between lamp and surrounding
reflective surfaces.
2, Reduce sensitivity (detection area).
The load is
permanently
illuminated.
The load will
not illuminate
despite
movement.
Speed of moving object is not in
the range of 0.5-3m/s or the
detection radius is too small.
Check detection area setting.
Cause Remedy
FAQ
ON O N O N
ON O N
ON O N
ON
ON
Ⅰ
Ⅱ
Ⅲ
Ⅳ
Ⅴ
1 2 3
100%
75%
50%
25%
10%
ON O N O N
ON O N
ON O N
ON
ON O N
ON
Ⅰ
Ⅱ
Ⅲ
Ⅳ
Ⅴ
4 5 6
Ⅳ
5s
30s
90s
3min
20min
30min
ON ON ON
ON O N
ON
ON
ON
Ⅰ
Ⅱ
7 8 9
Disable
50lux
10lux
2lux
25lux
Ⅲ
Ⅳ
Ⅴ
Not for general waste. Please contact your local authority on how to dispose correctly.
Installation & Maintenance instructions for S16WLED 16W.
Important Information
If you do not feel fully confident when dealing with electrical procedures, seek the advice of a qualified electrician.
This product must be installed in accordance with the current building and IEE wiring regulations.
Switch off the mains before commencing installation. These products are designed for connection to a 240V 50Hz
supply. Any broken or damaged parts should be replaced as soon as possible. We will not accept responsibility for any
claims arising from a poor installation. This product is suitable for outdoor use IP65.
Please note emergency packs/batteries carry a 12 month warranty.
LEDs are an inductive lead and may have higher inrush currents, it may be necessary to update your MCBs to
compensate.
Specification
●Isolate supply voltage before working with electrics.
●Remove trim and diffuser by turning anti-clockwise.
●Loosen but do not remove the three LED gear tray supporting screws, rotate the tray and allow it to hang on the
●Pass supply wires through grommet into the base section, taking care to ensure they are not trapped between the
fitting and mounting surface.
●Fix base section to the wall or ceiling. Use adequate fixings with regard to type of surface being fixed to.
FIG 1 - Wiring instructions for non-emergency units.
●Connect incoming neutral cable (blue wire) to the neutral terminal on connector block.
●Connect incoming live cable (brown wire) to the live terminal on the connector block.
●Connect incoming neutral cable (blue wire) to the neutral terminal on connector block.
●Connect incoming live cable (brown wire) to the switch live terminal on the connector block.
●Connect incoming permanent live cable (black wire) to the permanent terminal on the connector block.
●You must complete a FULL discharge and then a further 24 hour recharge prior to testing & full operation.
Microwave Technical Specification
2lux / 10lux / 50lux / disable
Microwave Settings
Neutral - Blue
Earth
Live - Brown
Neutral - Blue
Earth
Live - Brown
Mains Supply Luminaire
FIG 2 – Wiring Instructions for emergency units
Neutral
Earth
Switched Live
Live
Neutral
Earth
Switched Live
Live
Mains Supply Luminaire
318mm
82mm
Specication CCT Version
Power Supply 240V 50Hz
Operating Temp 0°C-+30°C
IP Rating IP65
Colour Temp 3000k, 4000k, 6000k
Multi Wattage 9w, 12w, 16w
Lumens 954lm, 1236lm, 1600lm
CRI Ra80
Life Time 50000H
Specication Standard Version
Power Supply 240V 50Hz
Operating Temp 0°C-+30°C
IP Rating IP65
Colour Temp 4000k
Multi Wattage 9w, 12w, 16w
Lumens 954lm, 1236lm, 1600lm
CRI Ra80
Life Time 50000H
Product end of life instruction.
This Lighting product is in the scope of EU 2019/2020 directive on Waste Electrical and Electronic Equipment (WEEE). This
product must be disposed according to the legislation. This document is intended for use by end of life recyclers or treatment
facilities. It provides the basic information to assure an appropriate end of life treatment for the components and materials of
the product. Please follow pictured diagram on the back of this manual showing how to dismantle the product into different
components which should be disposed correctly. These components would consist of plastic, metal and electronic materials.
It is the responsibility of the end user to dispose of this product correctly. www.weeeireland.ie or contact your local council for
further information.
Disassembly Diagram
ErP
COMPLIANT
IP65
Quality
Assurance
years
1.
2. 3.
4. 5.
