Sony Trinitron Wega KV-LS21 Manuel utilisateur

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

Tr initron Color TV

KV-LS21

2-891-306-11 (1)

Operating Instructions

•Before operating the unit, please read this manual thoroughly and retain

it for future reference.

N60

01GB01COV-SOEMPhi.p65 1/08/06, 9:30 AM1

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

ASpecifications

Power requirements

Power consumption (W)

Television system

Color system

Stereo/Bilingual system

Channel coverage

8 (Antenna)

Audio output (Speaker)

Number of terminal

(Video)

(Audio)

(S Video)

(Component

Video)

i(Headphone)

FM Radio

Tuning Range

Intermediate

Frequency

Picture tube

Tube size

Viewing screen size

Dimensions (w/h/d)

Mass

Design and specifications are subject to change without notice.

Note

KV-LS21N60

110-240 V AC, 50/60 Hz

Indicated on the rear of the TV

NTSC3.58, PAL*, PAL 60*, SECAM*, NTSC 4.43* * AV IN only

MTS

VHF : 2 to 13 /UHF : 14 to 69 /CATV : 1 to 125

75-ohm external terminal

10 W + 10 W

Input: 2 Output: 1 Phono jacks; 1 Vp-p, 75 ohms

Input: 3 Output: 1 Phono jacks; 500 mVrms

Input: 1 Y: 1 Vp-p, 75 ohms,

unbalanced, sync negative

C: 0.286 Vp-p, 75 ohms

Input: 1 Phono jacks;

Y: 1 Vp-p, 75 ohms,

sync negative

CB: 0.7 Vp-p, 75 ohms

CR: 0.7 Vp-p, 75 ohms

Output: 1 Stereo minijack

87.5 - 108.0 MHz

7.9 MHz

21 in.

545 mm

Measured diagonally

507 mm

Measured diagonally

646 ×485 ×484 mm

26 kg

01GB02WAR-SOEMPhi.p65 1/08/06, 9:31 AM2

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

Clean the TV with a dry and soft

cloth. Do not use benzine, thinner,

or any other chemicals to clean the

TV. Do not attach anything (e.g.,

adhesive tape, cellophane tape,

glue) on the painted cabinet of the

TV. Do not scratch the picture

tube.

BWARNING

• Dangerously high voltages are present inside the TV.

• TV operating voltage: 110 – 240 V AC.

•Do not plug in the power cord until you have completed making all other

connections; otherwise a minimum leakage current might flow through the antenna

and other terminals to ground.

•To avoid battery leakage and damage to the remote, remove the batteries from the

remote if you are not going to use it for several days. If any liquid leaks from the

batteries and touches your skin, immediately wash it away with water.

Install the TV on a stable TV stand

and floor which can support the

TV set weight. Ensure that the TV

stand surface is flat and its area is

larger than the bottom area of the

TV.

Do not plug in too many

appliances to the same power

socket. Do not damage the power

cord.

For children’s safety, do not leave

children alone with the TV. Do not

allow children to climb onto it.

For your own safety, do not touch

any part of the TV, the power cord

and the antenna cable during

lightning storms.

Do not place any objects on the TV.

The apparatus shall not be

exposed to dripping or splashing

and that no objects filled with

liquids, such as vases, shall be

placed on the apparatus.

Do not operate the TV if any liquid

or solid object falls into it. Have it

checked immediately by qualified

personnel only.

Do not block the ventilation

openings of the TV. Do not install

the TV in a confined space, such

as a bookcase or built-in cabinet.

Do not open the cabinet and the

rear cover of the TV as high

voltages and other hazards are

present inside the TV. Refer

servicing and disposal of the TV

to qualified personnel.

Pull the power cord out by the

plug. Do not pull the power cord

itself. Even if your TV is turned

off, it is still connected to the AC

power source (mains) as long as

the power cord is plugged in.

Unplug the TV before moving it

or if you are not going to use it for

several days.

To prevent fire or shock hazard, do

not expose the TV to rain or

moisture.

Your TV is recommended for

home use only. Do not use the TV

in any vehicle or where it may be

subject to excessive dust, heat,

moisture or vibrations.

01GB02WAR-SOEMPhi.p65 1/08/06, 9:31 AM3

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

CSecuring the TV

To prevent the TV from falling, use the supplied screws, clamps and band to

secure the TV. Use only the supplied screws. Use of other screws may damage

the TV.

Screw the band to the TV stand and to the

provided hole at the rear of your TV.

(1) Put a cord or chain through the clamps.

(2)

Screw one clamp to a wall or pillar and

the other clamp to the provided hole at

the rear of your TV.

20 mm

3.8 mm

screws clamps band

End

Select Confirm

Insert the batteries (supplied) into the remote.

Note

•Do not use old or different types of batteries together.

Connect the antenna cable (not supplied) to 8

(antenna input) at the rear of the TV.

Tips

•Your TV can receive both TV and FM radio signals from the appropriate

connections through the 8(antenna input) terminal (see G).

•You can also connect your TV to other optional components (see G).

Plug in the power cord, then press 1on the TV to turn it on.

Note

•The 1(standby) indicator flashes green for a few seconds when

turning on the TV. This does not indicate a malfunction.

Set up the TV by following the instructions of the “Initial

Setup” menu (see E).

DGetting Started

Step 1

Step 2

Step 3

Step 4

01GB02WAR-SOEMPhi.p65 1/08/06, 9:31 AM4

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

Program Edit

Off

Edit:

PROG

SkipLabel

Exit

Select Confirm

1Off

End

Select Confirm

End

Select Confirm

Exit

Select Confirm

Program:

Searching...

End

Setting up your TV (“Initial Setup”)

When you turn on your TV for the first time, the “Initial Setup” menu will

appear. You may change the menu language, preset the TV channels

automatically, edit the channels and adjust the picture position using the

buttons on the remote control or TV front panel.

1Press V or vto select the desired menu

language, then press .

The selected menu language appears.

2Press V or vto select “Yes”, then press to

preset the channels automatically.

The screen will indicate automatic

presetting is in progress.

After all available channels have been tuned

and stored, the “Program Edit” menu

appears automatically on the screen.

To skip automatic channel presetting, select

“No”, then press .

If the message “No channel found. Please

connect cable/antenna” appears, check your

TV connections, then press .

3The “Program Edit” menu enables you to

edit the channels.

a) If you wish to keep the channels in the current

condition, press WEGA GATE to exit.

b) Press Vor vto select the program

number with the channel you wish to

change. The selected channel will appear

on the screen.

c) If you wish to edit the channels, press

to enter edit mode.

Press buntil the mode that you wish to edit

is highlighted: Label, Skip, (block symbol).

Then press .

1) To label, press Vor vto select the

alphanumeric characters for the label.

Then press .

01GB02WAR-SOEMPhi.p65 1/08/06, 9:31 AM5

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

2) To skip the program number, press Vor vto

select “On”. Then press .

You can skip this program number when

using PROG +/–.

3) To block unwanted program number,

press Vor vto select . Then press .

d) Repeat step b) to c) if you wish to change other

channels.

Press WEGA GATE to exit.

4Press B or bto adjust the bars on the top

and bottom of the menu if they are

slanted, then press .

If no adjustment is necessary, then press .

5To prevent this “Initial Setup” menu from

appearing again when you turn on the TV

by pressing 1, press V or vto select “No”,

then press .

To allow this menu to appear again, select

“Yes”, then press .

Tip

•You can immediately go to the end of the ”Initial Setup” menu by pressing WEGA GATE.

End

Select Confirm

Exit

Select Confirm

Exit

Select Confirm

Setting up your TV (“Initial Setup”) (continued)

01GB02WAR-SOEMPhi.p65 1/08/06, 9:31 AM6

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

TV front and rear panels

Button/Terminal Function See

11Turn off or turn on the TV. D

2Remote control sensor. -

3Wake Up indicator. I

31Standby indicator. D

4iHeadphone jack. -

5t2Video input terminal 2. G

6PROG +/– Select program number. -

72+/– Adjust volume. -

8tSelect TV or video input. G

WEGA GATE menu operations

6,7

, , ,

Select and adjust items. J

8Confirm selected items. J

9WEGA GATE Display or cancel WEGA GATE menu. J

0FM Listen to FM Radio. Q

qa 8Antenna input terminal. G

qs TMonitor output terminal. G

qd Component video input terminal. G

qf t1Video input terminal 1. G

L(MONO) R

PROG

(MONO)

qsqdqf

PROG

(MONO)

542

9870

TV front panel

TV rear panel

01GB03INS-SOEMPhi.p65 1/08/06, 9:33 AM7

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

(

MONO)

(MONO)

GConnecting optional components

Connecting to the video input terminal ( t)

Note

• When both (S video) and (video) for t1 are connected at the same time,

(S video) is automatically selected. To view (video), disconnect the S video cable.

TV front panel

Camcorder

Audio/Video cable

(not supplied)

TV rear panel

Audio/Video

cable

(not supplied)

Antenna cable

(not supplied) TV, CATV, Satellite

When there is no

FM signal

Antenna

selector

Antenna cable

(not supplied)

TV signal

VCR

DVD Player

S Video

cable

(not supplied)

01GB03INS-SOEMPhi.p65 1/08/06, 9:34 AM8

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

DVD player

TV rear panel

Component video

cable

(not supplied)

Audio cable

(not supplied)

(

MONO)

Connecting to the component video input terminal ( )

Notes

•If your DVD player can output interlace and progressive mode signals, select the interlace

output when connecting to (component video input) on your TV. Your TV can receive

either 525i/60Hz or 625i/50Hz interlace signals.

•The component video terminals on your DVD player are sometimes labeled Y/CB/CR, Y/PB/

PR, Y/Cb/Cror Y/B-Y/R-Y.

• If you select “DVD” on your TV screen, the signal from the T(monitor output) jacks will not

be output properly. This does not indicate a malfunction.

Connecting optional components (continued)

TV rear panel

Audio system

VCR

Audio/Video

cable

(not supplied)

Connecting to the monitor output terminal ( T )

(

MONO)

01GB03INS-SOEMPhi.p65 1/08/06, 9:34 AM9

Black

Sony KV-LS21N60 Group B49 (GB)_2-891-306-11 (1)

HTroubleshooting

If you find any problem while viewing your TV, you can either use the

“Factory Settings” function or check the Troubleshooting guide below. If the

problem persists, contact your Sony dealer.

“Factory Settings” function

Press the WEGA GATE button. Choose “Settings” and go to “Setup” ( )

menu. From “Setup” menu, select “Factory Settings”. Then select “Yes” and

press . Your TV will go blank for a few seconds, then the “Initial Setup”

menu will appear. Your TV will be set to factory settings, but certain problems

may be solved.

Snowy picture,

noisy sound

Distorted picture,

noisy sound

No picture,

no sound

Good picture,

no sound

Dotted lines or

stripes

Double images

or “ghosts”

No color

Symptom Solutions

•Check the antenna cable and connection on the TV, VCR and at the wall

(see G).

•Check the antenna setup. Contact a Sony dealer for advice.

•Preset the channel again (see N).

•Display the “Channel Setup” menu and set the “Signal Booster” to “Auto”

(see N).

•Try using an external booster.

•Turn off or disconnect the external booster if it is in use.

•Display the “Channel Setup” menu and set the “Signal Booster” to “Off”

(see N).

•Check the power cord, antenna and VCR connections (see G).

•Press ?/1 (power) to turn on the TV (see I).

•Press 1(main power) on the TV to turn off the TV for about five seconds,

then turn it on again (see F).

•Press 2+ to increase the volume level (see I).

•Press to cancel the muting (see I).

•Press A/B until “Stereo” or “Mono” appears on the screen (see P).

• Do not use a hair dryer or other equipment near the TV.

•Check the antenna setup. Contact a Sony dealer for advice.

•Use a highly directional antenna.

•Check the antenna setup. Contact a Sony dealer for advice.

•Turn off or disconnect the external booster if it is in use.

•Display the “Picture” menu and select “Custom” from “Picture Mode”,

then adjust the “Color” level from “Picture Adjustment” (see L).

•Display the “Setup” menu and check the “Color System” setting

(usually set this to “Auto”) (for video input only) (see O).

•Check the antenna setup. Contact a Sony dealer for advice.

01GB03INS-SOEMPhi.p65 1/08/06, 9:34 AM10

Black

Table des matières

Autres manuels Sony TV

Sony

Sony Trinitron KV-29CS60B Manuel utilisateur

Sony

Sony TRINITRON KV-J14P2S Manuel utilisateur

Sony

Sony FD Trinitron KV-28LS35B Manuel utilisateur

Sony

Sony TRINITRON KV-LX34M50 Manuel utilisateur

Sony

Sony TRINITRON KV-36FS13H Manuel utilisateur

Sony

Sony KLV-32M1 - 32" Lcd Wega Color Tv Manuel utilisateur

Sony

Sony TRINITRON KV-21C5B Manuel utilisateur

Sony

Sony XBR-52LX905 Manuel utilisateur

Sony

Sony KD-34XBR960 - 34" Fd Trinitron Wega Manuel utilisateur

Sony

Sony TRINITRON KV-AR29M61 Manuel utilisateur

Sony

Sony M91 Manuel utilisateur

Sony

Sony Trinitron KV-13VM21 Manuel utilisateur

Sony

Sony BRAVIA KD-65A9F Manuel utilisateur

Sony

Sony TRINITRON KV-25X5A Manuel utilisateur

Sony

Sony TRINITRON KV-29FS105 Manuel utilisateur

Sony

Sony XR-65A80L Manuel utilisateur

Sony

Sony TRINITRON KV-PG21P10 Manuel utilisateur

Sony

Sony FD Trinitron KV-28FQ86E Manuel utilisateur

Sony

Sony TRINITRON KV-S3411A Manuel utilisateur

Sony

Sony Trinitron KV-20S90 Instructions d'utilisation

Sony

Sony Bravia KD-75X9400C Manuel utilisateur

Sony

Sony Bravia i-XBR-79X900B Manuel utilisateur

Sony

Sony BRAVIA KDL-55W800C Manuel utilisateur

Sony

Sony KV-27V26 - 27" Trinitron Color Television Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur
