General Features

• Auto SAP

• Auto Mute (Tuner)

• DAC Speaker System

• Steady Sound® Auto Volume

Control

• Fixed/Variable Audio Out

• Speakers On/Off

• Auto Channel Program

• Caption Vision (CC)

• Channel Fix

• Channel Label

• Channel Skip/Add

• Clock/Timer (Two Event)

• Demo Mode

• Energy Star® Compliant

• Favorite Channel

• Channel Jump

• On Screen Display

English/Spanish/French

• Program Palette™ Presets

• Sleep Timer

• Speed Surf™ Channel

Selection

• V Chip Parental Control

• Video Label

• XDS Banner

• Auto Pedestal Clamp

• Auto White Balance

• Dynamic Picture™ Processor

Circuitry

• Tilt Correction

• Trinitone® Color Temperature

• Vertical Aperture

Compensation

• S Video Detection

• Headphone Jack

• Component Video Input

(Y/Pb/Pr): 1 Rear

• Composite Input:

1 Rear, 1 Front

• S Video Input: 1 Rear

• RF Input: 1 Rear

• 24" FD Trinitron® Picture Tube

• 3-Line Digital Comb Filter

• Velocity Modulation™ Scanning (Off/Low/High) Control

• Component Video Input (Y/Pb/Pr)

STruSurround® SRS® Sound Processing

SWOW™ Audio Effect (10W x 2)

SSteady Sound® Automatic Volume Control with BBE® Audio Effect

KV-24FV300

FD Trinitron® WEGA® TV

Key Features

Additional Features

Preliminary and Confidential

S= Step-Up Feature

FD Trinitron® Picture Tube

Flat-Glass Screen Minimizes the Reflection of room lights,

reducing glare and geometric distortion.

Fine Pitch Aperture Grille Allows more electrons to reach

the screen surface for brighter, clearer, sharper images.

High-Focus Electron Gun The focal length of the gun is

30% greater than conventional televisions for better corner

focus.

High-Precision Deflection Yoke Guides the electrons

more accurately for superb image clarity.

3 Line Digital Comb Filter-

Compares each horizontal scanning line with the lines above and

below. The result is superb horizontal resolution, pure colors and

minimized video noise

WOW™ Audio Effect-

Is an audio circuit technology that improves both the low, and mid-

level frequency responses. This feature, combined with BBE® tech-

nology (for further audio improvement), Dynamic Acoustic

Chamber Speaker Enclosures (for better bass), and the subwoofer

(on 27"-36" FV models), results in noticeable audio improvement in

this series.

Specifications

Inputs and Outputs

• Component Video Input

(Y/Pb/Pr): 1 Rear

• Composite Input:

1 Rear/1 Front

• S Video Input: 1 Rear

• RF Input: 1 Rear

General

• Power Requirements:

AC120V, 60Hz

• Power Consumption:

(In Operation): 115W

In Standby): 1W

Accessories

Supplied Accessories

• Instruction Manual

• Remote Control

(RM-Y180)

• AA Battery x 2

Weights & Measures

• Approx. Dimensions

(w/h/d):

KV-24FV300:

27" x 201/2" x 191/2"

(687 x 522 x 494mm)

• Approx. Weight:

KV-24FV300:

81 lbs. 9 oz. (36.4 kg)

Key Technology

Specifications

Steady Sound, BBE, Trinitone and WEGA are trademarks of Sony. Any other trademarks referenced herein are either the property of Sony or their respective owners.

KV-24FV300

FD Trinitron® WEGA® TV
