Sony WHG-SLK1i - Audio System Component Manuel utilisateur

SERVICE MANUAL

Published by Sony Techno Create Corporation

Sony Corporation

Audio&Video Business Group

WHG-SLK1i/SLK2i

AUDIO SYSTEM COMPONENT

9-889-895-01

2010F05-1

US Model

Canadian Model

AEP Model

Chinese Model

Saudi Arabia Model

Singapore Model

Korean Model

Thai Model

WHG-SLK1i

Mexican Model

Brazilian model

Argentina model

WHG-SLK2i

E Model

WHG-SLK1i/SLK2i

Ver. 1.0 2010.06

• WHG-SLK1i/SLK2i are composed of following models.

As service manuals are issued for each component model, please

refer to them.

SPECIFICATIONS

COMPONENT MODEL NAME

WHG-SLK1i WHG-SLK2i

DVD Receiver HCD-SLK1i HCD-SLK2i

Speaker System SS-SLK1i SS-SLK2i

General

Power requirements

North American model:

AC 120 V, 60 Hz

Mexican model:

AC 127 V, 60 Hz

Brazilian model:

AC 127 V 240 V, 60 Hz

European, Korean, Argentine and

Thai models:

AC 220 V 240 V, 50/60 Hz

Other models:

AC 120 V 240 V, 50/60 Hz

Power consumption

WHG-SLK2i:

80 W

WHG-SLK1i:

60 W

Dimensions (W/H/D) (excl. speakers)

WHG-SLK2i:

Approx. 330 mm × 203 mm ×

141 mm

WHG-SLK1i:

Approx. 330 mm × 203 mm ×

138 mm

Mass (excl. speakers)

WHG-SLK2i:

Approx. 3.7 kg

WHG-SLK1i:

Approx. 3.6 kg

Supplied accessories:

Remote Commander (1)

AM loop antenna (1)

FM lead antenna (1)

Video cord (1) (WHG-SLK2i only)

R6 (Size AA) batteries (2)

Wall-mount bracket (3) (WHG-SLK2i

only)

Bracket lock levers (3) and screws (3)

(WHG-SLK2i only)

Leaet “Installing the system on the

wall” (1) (WHG-SLK2i only)

Design and specications are subject to change without notice.

Standby power consumption: 0.5 W

Halogenated ame retardants are not used in the certain printed wiring boards.

iPod models

You can use the following iPod models on this system. Update your iPod with the latest

soware before using it.

iPod nano

5th generation

(video camera)

iPod touch

2nd generation

iPod classic

120 GB

160 GB (2009)

iPod nano

4th generation

(video)

iPod classic

160 GB (2007)

iPod touch

1st generation

iPod nano

3rd generation

(video)

iPod classic

80 GB

iPod nano

2nd generation

(aluminum)

iPod is a trademark of Apple Inc., registered

in the U.S. and other countries.

“Made for iPod” means that an electronic

accessory has been designed to connect

specically to iPod and has been certied by

the developer to meet Apple performance

standards.

Apple is not responsible for the operation of

this device or its compliance with safety and

regulatory standards.

– Refer to next page for accessories list –

WHG-SLK1i/SLK2i

• Abbreviation

AR : Argentina model

BR : Brazilian model

CH : Chinese model

CND : Canadian model

E2 : 120 V AC area in E model

E3 : 240 V AC area in E model

E51 : Chilean and Peruvian models

EA : Saudi Arabia model

KR : Korean model

MX : Mexican model

SP : Singapore model

TH : Thai model

ACCESSORIES

1-487-836-11 REMOTE COMMANDER (RM-AMU086)

1-754-102-41 ANTENNA, LOOP (LW.MW) (AM loop antenna)

1-793-184-41 CONNECTOR (F TYPE ADAPTOR)

(FM lead antenna)

1-838-116-11 CORD, CONNECTION (Video cord) (SLK2i)

4-187-068-13 MANUAL, INSTRUCTION (ENGLISH)

(US, CND, AEP, E2, E3, E51, EA, SP)

4-187-068-23 MANUAL, INSTRUCTION (FRENCH)

(CND, AEP, E2, E3, EA)

4-187-068-33 MANUAL, INSTRUCTION (SPANISH)

(US, AEP, E2, E51, AR)

4-187-068-43 MANUAL, INSTRUCTION (GERMAN, DUTCH)

(AEP)

4-187-068-53 MANUAL, INSTRUCTION (ITALIAN, SWEDISH)

(AEP)

4-187-068-63 MANUAL, INSTRUCTION (POLISH) (AEP)

4-187-068-73 MANUAL, INSTRUCTION (PORTUGUESE) (BR)

4-187-068-82 MANUAL, INSTRUCTION (SPANISH) (MX)

4-187-069-13 MANUAL, INSTRUCTION (ARABIC) (E3, EA)

4-187-069-33 MANUAL, INSTRUCTION (TRADITIONAL CHINSE)

(SP)

4-187-069-43 MANUAL, INSTRUCTION (THAI) (TH)

4-187-069-53 MANUAL, INSTRUCTION (KOREAN) (KR)

4-187-069-61 MANUAL, INSTRUCTION

(ENGLISH, SIMPLIFIED CHINESE) (CH)

4-187-070-12 INSTRUCTION (Installing the system on the wall)

(ENGLISH, FRENCH, SPANISH, PORTUGUESE)

(SLK2i)

501 4-168-707-01 BRACKET (WH) (Wall-mount bracket) (1 piece)

(SLK2i)

502 4-195-473-01 CUSHION (WH) (SLK2i)

503 4-182-889-01 SCREW (HOOK) (for Wall-mount bracket of

speaker) (1 piece) (SLK2i)

504 4-193-085-01 LOCK (WH) (Bracket lock lever) (1 piece) (SLK2i)

505 4-198-670-01 SCREW, FLAT HEAD (TP) (for Bracket lock lever)

(1 piece) (SLK2i)

Ref. No. Part No. Description Remark

For main unit: For front speakers (2):

(Unit: mm)

61.5

37.5 37.5

Do not remove fastened screws.

61.5

37.5 37.5

Main unit

Speaker

Left speaker Right speaker

Main unit

(Unit: mm)

Holes on main unit/speaker

Push to unlock.

Main unit/Speaker Bracket

Lever

Screw

Bracket hole

Wall

330 330 330

350 1300350 1300

501

502

× 4

501

504

505

502

× 4

Lever

Screw

503

For WHG-SLK2i

WHG-SLK1i/SLK2i

MEMO

WHG-SLK1i/SLK2i

REVISION HISTORY

Checking the version allows you to jump to the revised page.

Also, clicking the version at the top of the revised page allows you to jump to the next revised page.

Ver. Date Description of Revision

1.0 2010.06 New
