Sony MDR-RF845RK Manuel utilisateur

MDR-RF845RK

AEP Model

UK Model

SERVICE MANUAL

WIRELESS STEREO

HEADPHONE SYSYTEM

MDR-RF845RK is composed of the following models.

As for the service manual it is issued for each component

model, then please refer to it.

Headphones MDR-RF845R

Transmitter TMR-RF845R

COMPONENT MODEL NAME FOR MDR-RF845RK

PARTS LIST

The components identified by mark 0or dotted

line with mark 0are critical for safety.

Replace only with part number specified.

Ref. No. Part No. Description Remarks

ACCESSORIES & PACKING MATERIALS

*******************************

01-465-948-11 ADAPTOR, AC (AC-S901K)(AEP)

01-473-590-11 ADAPTOR, AC (AC-S901) (UK)

01-473-606-11 ADAPTOR, PLUG

01-476-179-11 ADAPTOR, AC (AC-S9010) (AEP)

1-559-906-32 CORD, CONNECTION

3-222-708-11 MANUAL,INSTRUCTION (ENGLISH)(AEP,UK)

3-222-708-21 MANUAL,INSTRUCTION

(FRENNCH,GERMAN,SPANISH,DUTCH,ITALIAN,

PORUTGUESE) (AEP)

SPECIFICATIONS

General

Carrier frequency 863.5 – 864.5 MHz

Channel Ch1, Ch2, Ch3

Modulation FM stereo

Frequency response 20 – 20,000 Hz

TransmitterTMR-RF845R

Power source DC 9 V: supplied AC power adaptor

Audio input phono jacks/stereo mini jack

Dimensions Approx. 150 mm dia ×108 mm

(6 ×4 1/3in.) (w/h)

Mass Approx. 190 g (6.2 oz.)

Headphones MDR-RF845R

Power source DC 2.4 V: Built-in rechargeable battery

Mass Approx. 240 g (8.1 oz.) incl.

built-in rechargeable battery

Built-in Ni-Cd rechargeable battery

Model name NC-AA

Voltage 1.2 V

Capacity 700 mAh

Design and specifications are subject to change without notice.

Ver 1.0 2000. 07

MDR-RF845RK

— 2 —

Sony Corporation

Audio Entertainment Group 2000G1646-1

Published by PE General Engineering Dept.

9-927-950-11

SECTION 1

GENERAL This section is extracted

from instruction manual.

-ATurn up the volume to a moderate

level with the VOL control.

Press the TUNING button briefly for

automatic tuning of the headphones.

If you do not receive a clear audio

signal, press it again.

AMDR-RF845R

Auto power on/off function

When you remove the headphones from your

head, the power turns off automatically. Do not

allow the self adjusting band to be pulled up,

otherwise the headphones will be switched on.

The power turns on.

TUNING

button

VOL control

DC IN 9V

OFF ON

FILTERNOISE

123

CHANNEL

RBAL

AUDIO IN

Setting up the

transmitter

Connect the transmitter to audio/video

equipment. Select one of the hookups

below depending on the jack type:

ATo connect to a headphones jack

Transmitter

Left channel

(white)

Right channel

(red)

Unimatch plug

adaptor

(supplied)

CD Walkman,

MD Walkman,

WALKMAN*,

VCR, etc.

to headphones

jack (stereo

mini jack)

Connecting cord

(supplied)

to AUDIO IN

A jacks

to headphones

jack (stereo

phone jack)
