Sony STR-DB780 Manuel utilisateur

FM Stereo

FM-AM Receiver

Operating Instructions

4-241-673-12(1)

STR-DB780

WARNING

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To prevent fire, do not cover the ventilation of the

apparatus with news papers, table-cloths, curtains,

etc. And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the apparatus.

Don’t throw away the battery with

general house waste, dispose of it

correctly as chemical waste.

Do not install the appliance in a confined space, such

as a bookcase or built-in cabinet.

Except for European model

ENERGY STAR®is a U.S.

registered mark.

As an ENERGY STAR®partner,

Sony Corporation has determined

that this product meets the ENERGY

STAR®guidelines for energy

efficiency.

This receiver incorporates Dolby* Digital and Pro

Logic Surround and the DTS** Digital Surround

System.

* Manufactured under license from Dolby

Laboratories.

“Dolby”, “Pro Logic” and the double-D symbol are

trademarks of Dolby Laboratories.

**“DTS” and “DTS Digital Surround” are registered

trademarks of Digital Theater Systems, Inc.

About This Manual

• The instructions in this manual are for model

STR-DB780. Check your model number by looking

at the lower right corner of the front panel. In this

manual, the models of area code U is used for

illustration purposes unless stated otherwise. Any

difference in operation is clearly indicated in the

text, for example, “Models of area code U only”.

• The instructions in this manual describe the controls

on the receiver. You can also use the controls on the

supplied remote if they have the same or similar

names as those on the receiver. For details on the

use of your remote:

– Models of area code U, CA

RM-PP506L: See the separate operating

instructions supplied with the remote.

– Models of other area codes

RM-U305C: See pages 53–56.

About area codes

The area code of the receiver you purchased is

shown on the lower portion of the rear panel (see

the illustration below).

Any differences in operation, according to the

area code, are clearly indicated in the text, for

example, “Models of area code AA only”.

Area code

4-XXX-XXX-XX AA

SUB

WOOFER

AC OUTLET

PRE OUT

FRONT CENTER

SURROUND

OUT

MPEDANCE

SELECTOR

4 Ω8 Ω

Table of Contents

List of Button Locations and

Reference Pages

Main unit ............................................... 6

Getting Started

1: Check how to hookup your

components ..................................... 8

1a: Connecting components with

digital audio output jacks .......... 10

1b: Connecting components with multi

channel output jacks .................. 13

1c: Connecting components with only

analog audio jacks ..................... 15

2: Connecting the antennas.................. 17

3: Connecting speakers........................ 18

4: Connecting the AC power cord ....... 20

5: Setting up the speakers .................... 21

6: Adjusting the speaker levels and

balance (TEST TONE).................. 23

Amplifier/Tuner Operation

Selecting the component ..................... 24

Listening to multi channel sound

(MULTI CH DIRECT) ................. 24

Listening to FM/AM radio .................. 25

Storing FM stations automatically

(AUTOBETICAL)*1..................................... 26

Presetting radio stations....................... 26

Using the Radio Data System

(RDS)*1........................................................................ 27

Changing the display ...........................30

About the indications in the display ....31

Enjoying Surround Sound

Automatically decoding the input audio

signal (AUTO DECODING)......... 33

Using only the front speakers

(2CH STEREO) ............................ 33

Selecting a sound field ........................ 34

Enjoying Dolby Pro Logic II

(2CH MODE)................................ 36

Advanced Adjustments and

Settings

Switching the audio input mode for

digital components

(INPUT MODE)............................ 37

Customizing sound fields .................... 37

Adjusting the equalizer........................ 39

Advanced settings................................ 40

Other Operations

Naming preset stations and functions.. 47

Using the Sleep Timer ......................... 47

Recording ............................................ 48

CONTROL A1 control system......... 49

*1Models of area code CEL, CEK only.

*2Except for models of area code U, CA.

Operations Using the Remote

RM-U305C*2

Before you use your remote ................ 53

Remote button description................... 53

Changing the factory setting of a function

button ............................................ 56

Additional Information

Precautions .......................................... 57

Troubleshooting................................... 57

Specifications ...................................... 60

Index .................................................... 63

List of Button Locations and Reference Pages

How to use this page

Use this page to find the location of buttons and other

parts of the system that are mentioned in the text.

Illustration number

PLAY MODE qg (9, 13, 14)

Name of button/part Reference page

Main unit

ALPHABETICAL ORDER

A – L

AUTO DEC qs (33)

CINEMA STUDIO EX A/B/C qg

(34)

Cursor buttons ( / ) wh (21,

37–40, 47)

CUSTOMIZE wl (40, 47)

Digital Cinema Sound indicator

DIMMER ed (30)

DISPLAY ql (30)

Display 4

DOOR OPEN 7

ENTER wg (47)

EQ wj (39)

EQUALIZER e; (39)

FM/AM qf (25, 26)

FM MODE es (25)

FUNCTION 6(24–27, 37, 47)

INPUT MODE 9(37)

IR receptor 2

Jog dial wf (21, 37–40, 47)

LEVEL wd (38)

MASTER VOLUME 5(23, 24)

MEMORY w; (26)

MODE +/– 0(35, 38)

MULTI CH DIRECT 8(24)

NORMAL SURR (;PLII) qh

(36)

PHONES jack qj

PRESET TUNING +/– qd (26)

RDS PTY ea (28)

(Models of area code CEL, CEK

only)

SET UP ws (21)

SLEEP ea (47)

(Except for models of area code

CEL, CEK)

SPEAKERS ON/OFF qk (24)

SURR wk (37)

TUNING +/– wa (25)

(Except for models of area code

CEL, CEK)

TUNING/PTY SELECT +/– wa

(25, 28)

(Models of area code CEL, CEK

only)

VIDEO 3 INPUT jacks ef (16)

M – V 2CH ST qa (33)

?/1 (power) 1

NUMBERS AND SYMBOLS

List of Button Locations and Reference Pages

Open the front door

–

+–

–

123 4 5

67890

qs qaqdqfqhqjqk qg

ql w; wa ws wd wf

whwl

e; wgwjeaef esed

Getting Started

1: Check how to hookup your components

Steps 1a through 1c beginning on page 10 describe how to hook up your components to this receiver.

Before you begin, refer to “Connectable components”below for the pages which describe how to

connect each component.

After hooking up all your components, proceed to “2: Connecting the antennas”(page 17).

Connectable components

Component to be connected Page

DVD/LD player

With digital audio output*110–11

With multi-channel audio output*213–14

With analog audio output only*310–11

TV monitor

With component video input*4 *511 or 14

With S-Video or composite video input only 16

Satellite tuner

With digital audio output*110–11

With analog audio output only*310–11

CD/Super Audio CD player

With digital audio output*112

With multi-channel audio output*213

With analog audio output only*315

MD/Tape deck

With digital audio output*112

With analog audio output only*315

Analog disc turntable 15

Multi-channel decoder 13

VCR, video camera, video game, etc. 16

*1Model with a DIGITAL OPTICAL OUTPUT or DIGITAL COAXIAL OUTPUT connector, etc.

*2Model with a MULTI CH OUTPUT connectors, etc. This connection is used to output the audio decoded by the

component’s internal multi-channel decoder through this receiver.

*3Model equipped only with AUDIO OUT L/R jacks, etc.

*4Model with component video (Y, B-Y, R-Y) input jacks

*5Except for models of area code CEL, CEK.

Getting Started

Notes

•Turn off the power to all components before making any connections.

•Be sure to make connections firmly to avoid hum and noise.

•When connecting an audio/video cord, be sure to match the color-coded pins to the appropriate jacks on the

components: yellow (video) to yellow; white (left, audio) to white; and red (right, audio) to red.

•When connecting optical digital cords, insert the cord plugs straight in until they click into place.

•Do not bend or tie optical digital cords.

If you have a Sony components with CONTROL A1 jack

See “CONTROL A1 control system”on page 49.

Required cords

The hookup diagrams on the subsequent pages assume the use of the following optional connection

cords (Ato H) (not supplied).

AAudio cord

White (L)

Red (R)

BAudio/video cord

Yellow (video)

White (L/audio)

Red (R/audio)

CVideo cord

Yellow

DS-video cord

EOptical digital cord

FCoaxial digital cord

GMonaural audio cord

Black

Tip

Audio cord Acan be torn into two monaural audio

cords G.

HComponent video cord

(Except for models of area code CEL, CEK)

Green

Blue

Red

1a: Connecting components with digital audio output

jacks

Hooking up a DVD player, LD player, TV, or satellite tuner

For details on the required cords (A–H), see page 9.

1 Connect the audio jacks.

DVD/LD player

Satellite tuner

* Connect to either the ASSIGNABLE COAXIAL IN (DVD/LD CD/SACD) or the DVD/LD OPTICAL IN jack.

We recommend making connections to the ASSIGNABLE COAXIAL IN (DVD/LD CD/SACD) jack.

PHONO

CD/SACD

MD/TAPE

IN IN

OUT

MULTI CH IN

SIGNAL

GND

CONTROL

FRONT

SURROUND

CENTER

SUB

WOOFER

MONITOR

OUT TV/SAT

IN DVD/LD

MONITOR

AUDIO

VIDEO

OUT

VIDEO

AUDIO

OUT

VIDEO 1

AUDIO

TV/SAT

AUDIO

DVD/LD

COMPONENT VIDEO

AUDIO

OUT

VIDEO 2

S-VIDEO

VIDEO

S-VIDEO

OUT

VIDEO

S-VIDEO

VIDEO

S-VIDEO

VIDEO

S-VIDEO

OUT

VIDEO

DIGITAL

ANTENNA

MD/TAPE

OPTICAL

TV/SAT

OPTICAL

DVD/LD

OPTICAL

Ω

COAXIAL

ASSIGNABLE

COAXIAL IN

DVD/LD

CD/SACD

MD/TAPE

OPTICAL

OUT

/B-Y

/R-Y

+–

SURROUND

()

SPEA

IMPEDANCE

+–

SURROUND

DIGITAL

COAXIAL

OUTPUT

DIGITAL

OPTICAL

OUTPUT

DIGITAL

OPTICAL

OUTPUT

AUDIO

OUT

OUTPUT

AUDIO

OUT

OUTPUT

Table des matières

Autres manuels Sony Récepteur stéréo

Sony

Sony STR-DN1000 Manuel utilisateur

Sony

Sony STR-DE375 Manuel utilisateur

Sony

Sony STR-DA90ESG Manuel utilisateur

Sony

Sony STR-D560Z Manuel utilisateur

Sony

Sony STR-DE515 Manuel utilisateur

Sony

Sony STR-D915 Manuel utilisateur

Sony

Sony STR-DE805G - Fm/am Stereo Receiver Manuel utilisateur

Sony

Sony STR-V555ES - Fm Stereo/fm-am Receiver Manuel utilisateur

Sony

Sony STR-DE835 Manuel utilisateur

Sony

Sony STR-DB798 Guide de démarrage rapide

Sony

Sony STR-DA2100ES Operating Instructions for... Manuel utilisateur

Sony

Sony STR-AV1000 Manuel utilisateur

Sony

Sony XAV-712HD Manuel utilisateur

Sony

Sony STR-GA9ESG Manuel utilisateur

Sony

Sony STR-DE698 - A/v Receiver Guide de démarrage rapide

Sony

Sony STR-DA5600ES - Multi Channel Av Receiver Manuel utilisateur

Sony

Sony STR-DK5 E Guide de démarrage rapide

Sony

Sony STR-DH100 Manuel utilisateur

Sony

Sony STR-DE675 - Fm Stereo/fm-am Receiver Manuel utilisateur

Sony

Sony STR-DA1000ES Manuel utilisateur

Sony

Sony STR-DE497 Guide de démarrage rapide

Sony

Sony XAV-AX5110 Manuel utilisateur

Sony

Sony XAV-AX6050 Manuel utilisateur

Sony

Sony STR-DE845 Manuel utilisateur

Manuels Récepteur stéréo populaires d'autres marques

Marantz

Marantz CINEMA 70S Manuel utilisateur

Kenwood

Kenwood KMDX92 Manuel utilisateur

Yamaha

Yamaha RX-830 Manuel utilisateur

Pioneer

Pioneer AVH-Z7250BT Manuel utilisateur

Yamaha

Yamaha RX-750 Manuel utilisateur

Denon

Denon AVR-1311 Manuel utilisateur

Denon

Denon AVR-S760H Manuel utilisateur

Denon

Denon AVR-X7200W Manuel utilisateur

Pioneer

Pioneer SC-LX904 Manuel

Radio Shack

Radio Shack DX-399 Manuel utilisateur

Pioneer

Pioneer SX-1000TA Manuel utilisateur

Yamaha

Yamaha MusicCast TSR-5B3D Manuel utilisateur

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Manuel utilisateur

Pioneer

Pioneer SX-838 Manuel utilisateur

Sherwood

Sherwood S-2660CP Manuel technique

Pioneer

Pioneer XR-VS77 Manuel utilisateur

Pioneer

Pioneer AVH-2300NEX Manuel utilisateur

Denon

Denon DRA-697CI Manuel utilisateur
