Sony SRS-XV500 Guide de référence
Help Guide
Wireless Speaker
SRS-XV500
Model: YY7855E
The following explains how to use this speaker. Select a topic from the navigation pane.
Design and specifications are subject to change without notice.
Use the latest versions of the software pre-installed on the speaker and “Sony | Music Center.”
Getting Started
Parts and controls
Carrying/placing the speaker
Power source/charging
Charging the speaker
Turning the power on
Turning the power off
Using the BLUETOOTH standby (auto power on) function
Charging a USB device such as a smartphone or iPhone
Auto Standby (power saving) function
1
Lighting function
Turning on/off the speaker’s light (Lighting function)
Making connections
USB device
Connecting with a USB device
BLUETOOTH® device
Pairing and connecting with BLUETOOTH devices
Connecting with a computer via a BLUETOOTH connection (Windows®)
Connecting with a computer via a BLUETOOTH connection (Mac)
Multipoint connection
Connecting the speaker concurrently with 2 BLUETOOTH devices (multipoint connection)
Listening to music
USB device
Listening to music of a USB device
BLUETOOTH device
Listening to music of a device via a BLUETOOTH connection
Selecting the quality for music playback via a BLUETOOTH connection (Codec)
Supported codecs
Terminating the BLUETOOTH connection (After use)
Turning on or off the BLUETOOTH function
Listening to music of a portable audio device, etc. through a wired connection
Enjoying switching the sound effects
Stereo Pair function
Listening to music wirelessly with 2 speakers (Stereo Pair function)
Party Connect function
Enjoying wireless playback using multiple speakers (Party Connect function)
Additional features
Using an external microphone
Enjoying sound from a guitar
2
Using “Sony | Music Center”
What you can do with “Sony | Music Center”
Installing “Sony | Music Center”
Using “Fiestable”
What you can do with “Fiestable”
Installing “Fiestable”
Information
About the indicators
Updating the pre-installed software
Notes on use
Precautions
Notes on charging
Notes on water resistant feature
How to care for the speaker
About the BLUETOOTH wireless technology
Licenses
Trademarks
Troubleshooting
What can I do to solve a problem?
Power supply
Unable to charge the speaker
Unable to turn on the speaker or the speaker suddenly turns off
Sound
No sound/Sound from only one speaker/Low sound level/Distorted sound/Humming or noise in the speaker output
Sound becomes low while in use
USB device
The USB device is not detected; playback from an audio source fails; no sound comes out of the speaker; playback does not start
with the first track
The sound from the speaker contains noise, skips, or is distorted
3
5-053-791-11(1) Copyright 2024 Sony Corporation
It takes a long time before playback starts
BLUETOOTH device
Unable to pair the speaker with a BLUETOOTH device
Speaker output is interrupted
Unable to connect a BLUETOOTH device with the speaker for the Stereo Pair function
Unable to connect with a speaker for the Party Connect function
Unable to add a speaker for the Party Connect function
Unable to connect the speaker concurrently with 2 devices (multipoint connection)
Microphone
There is no microphone sound
There is acoustic feedback
Reset
Restarting the speaker
Initializing the speaker
Specifications
Specifications
4
Note
The port and jacks on the speaker are not designed for water resistant. Do not use the speaker in places where the speaker is
likely to have water splashed on it. When you are finished with using the speaker, be sure to securely close the cap.
Related Topic
About the indicators
5-053-791-11(1) Copyright 2024 Sony Corporation
(BLUETOOTH) with indicator
AUDIO IN
USB
LIGHT4.
MEGA BASS with indicator/ STAMINA with indicator5.
–/+ (volume)6.
(play)*
7.
Handles8.
Lights9.
Cap10.
BATTERY button/ BATTERY CARE button11.
KEY CONTROL (flat) button with indicator/ (sharp) button with indicator12.
ECHO button with indicator13.
GUITAR button with indicator14.
PLAY/CHARGE OUTPUT (DC power output only) port (USB)15.
AC input jack16.
AUDIO IN jack (Φ 3.5 mm)17.
MIC level (MIN/MAX) knob
MIC1 jack (Φ 6.3 mm)
18.
MIC and GUITAR level (MIN/MAX) knob
MIC2/GUITAR jack (Φ 6.3 mm)
19.
Touching and holding (play) on the speaker for about 5 seconds makes the speaker play the music track stored for demonstration purposes.
To disable this feature, tap (play) on the speaker once again.
*
6
Help Guide
Wireless Speaker
SRS-XV500
Carrying/placing the speaker
To carry the speaker
Before carrying the speaker, disconnect all the cables connected to the speaker.
Grasp the top and bottom handles with both hands, and then lift and move the speaker.
Note
To avoid personal injuries and/or property damage, place your hands properly on the speaker to hold and carry the speaker.
Do not let children or infants be near when carrying the speaker.
If your skin remains in contact with the handle for a long time while the light is turned on, there is a risk of low-temperature burns.
To carry a speaker while it is powered on, turn the light (lighting function) off.
To place the speaker in the horizontal orientation
The speaker can be placed in the horizontal orientation as well. (Be sure to place the side with the rubber feet down.)
Related Topic
Turning on/off the speaker’s light (Lighting function)
7
5-053-791-11(1) Copyright 2024 Sony Corporation
8
Help Guide
Wireless Speaker
SRS-XV500
Charging the speaker
The speaker is capable of running on power either from an AC outlet connected by the supplied AC power cord (mains
lead) or from the rechargeable built-in lithium-ion battery.
When using the speaker for the first time, be sure to charge the built-in battery for more than 1 hour before turning on the
speaker.
With the built-in battery charged in advance, you can use the speaker solely with battery power.
Hint
For charging the built-in battery of the speaker, the Battery Care mode option is available in addition to the normal charging
method. Battery Care mode limits the maximum charge capacity to approximately 90% and makes the battery life last longer. The
playback time available in Battery Care mode is shorter than the time available when the built-in battery is charged by the normal
charging method. At the time of purchase, the speaker is not in Battery Care mode.
While the speaker is turned on, pressing and holding the BATTERY button/ BATTERY CARE button behind the cap on the
rear side of the speaker for about 2 seconds places the speaker into Battery Care mode and you hear voice guidance (Battery
Care mode, ON) from the speaker. Pressing and holding the BATTERY button/ BATTERY CARE button once again for about
2 seconds brings the speaker out of Battery Care mode and you hear voice guidance (Battery Care mode, OFF) from the
speaker.
You can place/bring the speaker into/out of Battery Care mode with “Sony | Music Center” as well.
Checking the charging completion
Connect the speaker to an AC outlet to charge it.
Connect the AC input jack on the speaker and an AC outlet with the supplied AC power cord (mains lead).
Battery charging starts and the CHARGE indicator lights up in orange. Charging will complete in about 3 hours* and
the indicator will turn off.
After you disconnect the AC power cord (mains lead) from the speaker upon completion of battery charging, be
sure to close the cap securely.
The cap plays a very important role in maintenance of the water resistant performance.
1
Time that is required to charge the empty built-in battery to its full capacity while the speaker is turned off.
*
9
If the built-in battery is fully charged when you connect the speaker to an AC outlet, the CHARGE indicator lights up in
orange then turns off after about 1 minute.
Checking the built-in battery level of the rechargeable built-in battery
After pressing the BATTERY button behind the cap on the rear side of the speaker, when the speaker is turned on, the
voice guidance listed below is output from the speaker depending on the remaining built-in battery power.
81% - 100%: “Battery fully charged”
81% - 90% (Battery Care mode): “Battery Care Mode, Fully Charged, Battery About 90%”
61% - 80%: “Battery about 80%”
41% - 60%: “Battery about 60%”
21% - 40%: “Battery about 40%”
1% - 20%: “Low Battery”
Hint
By using “Sony | Music Center,” you can activate/deactivate the voice guidance associated with the remaining battery power that
you hear when you turn on the speaker.
Built-in battery life (while the speaker is not in Battery Care mode and a BLUETOOTH connection is
established)
Approx. 25 hours
Volume level: 18
Sound: MEGA BASS on
Lighting: off
Approx. 12 hours
Volume level: 18
Sound: MEGA BASS on
Lighting: on
Approx. 5 hours
Volume level: 50 (MAX.)
Sound: MEGA BASS on
Lighting: off
Approx. 4.5 hours
Volume level: 50 (MAX.)
Sound: MEGA BASS on
Lighting: on
Time required for charging the built-in rechargeable battery (while Battery Care mode is not
activated)
Approx. 3 hours*
10 minutes of charging provide approximately 2.5 hours of music playback.
10
