Sony CD-9255 Manuel utilisateur

Platinum CCTV Surveillance Solutions

CD-9255 SONY Indoor/Outdoor

Day/Night Long-Range Infrared

Varifocal Camera

Installation Manual

Outdoor Weatherproof Day/Night

Infrared CCD Bullet Camera

For Warranty Registration, Visit

Http:// Platinum-CCTV.com

Platinum CCTV Surveillance Solutions

Camera Installation

1. Camera Mounting:

Items Needed:

Screwdriver, Drill, Mounting Hardware (not

included), Pencil

2. For Wall Mount bracket

a. Assemble 2 pieces of camera support

bracket and secure with 4 screws

b. Attach support bracket to Camera body

Platinum CCTV Surveillance Solutions

Camera Installation

c. Attach support bracket to camera bracket

d. Push cable through holes in bracket

e. For Ceiling mount bracket, simply thread bracket

to camera (top or bottom)

Platinum CCTV Surveillance Solutions

Adjusting the Lens

The Lens of the CD-9255 camera is an externally

adjustable 4-9mm varifocal lens. The lens can be

easily adjusted after mounting the camera.

WARNING! – Failure to follow these

instructions carefully can result in damage

to the camera and will void the warranty

On the back of the camera, you will find 2

weatherproof caps. These caps hide the zoom

and focus adjustments for the camera.

1. Carefully remove the zoom cap from the

camera

Do NOT lose the cap, you will need to replace the

weather-proof cap after adjustment

Platinum CCTV Surveillance Solutions

Camera Installation

2. Use a small screwdriver to adjust the zoom of the

lens. The CD-9255 camera will adjust between

4mm (wide-angle) and approx. 9mm (fixed

zoom).

When making Zoom and Focus adjustments,

STOP when there is a slight resistance.

Forcing the camera’s adjustment will void

the warranty and damage the camera

Platinum CCTV Surveillance Solutions

Camera Installation

3. Next, remove the weatherproof cap for the focus

adjustment..

4. Then use a small standard screwdriver to adjust

the focus of the camera.

When making Zoom and Focus adjustments,

STOP when there is a slight resistance.

Forcing the camera’s adjustment will void

the warranty and damage the camera

Platinum CCTV Surveillance Solutions

Camera Installation

5. You may have to repeat the zoom and focus

adjustments to achieve the width of view that is

desired.

6. Once you have completed the adjustments,

replace the weatherproof caps, making sure they

are completely seated to ensure the camera

remains weatherproof.

DO NOT OVERTORQUE

WEATHERPROOF CAPS

Platinum CCTV Surveillance Solutions

CD-9255 Long Range IR CCD Camera

Image Sensor 1/3” SONY CCD

Number of Pixels NTSC: 540 (H) x 491 (V)

Scanning System 15.7343Khz (H), 60 Hz (V)

Sync System Internal Synchronization

Resolution 420 TVL

Lens 4-9mm Varifocal Lens (Ext. Adjust)

Video Output 1.0Vp-p75Ω

S/N Ratio >52dB

Shutter Time 1/60-1/100,000 Sec.

Operation Temp. -20°C ~ +50°C

Storage Temp. -30°C ~ +60°C

Useable

Illumination 0.5 Lux (F:2.0), 0 Lux (IR On)

Power Source DC 12V 1000mA

Installation Notes

•For Indoor or Outdoor Use

•Disassembly of camera will void warranty

•Remove protective film from lens before use

•Handle with care

•Never touch lens directly

•Clean the lens occasionally with a dry micro-fiber

cloth, or plastic cleaner only – Do not use abrasive-

type cleaners as they will scratch lens
