Sony STR-DN1020 Manuel utilisateur

Sony STR-DN1020 [GB] 4-282-221-11(1)

STR-DN1020Multi Channel AV Receiver

Start here

Hello, this is your Quick Setup Guide

Sony STR-DN1020 [GB] 4-282-221-11(1)

Connecting your TV and other devices

Other connections

Selecting speakers and optimizing

Playback

Setting up the speakers

Sony STR-DN1020 [GB] 4-282-221-11(1)

Here’s what’s in the box

You will need to have a speaker system in place

and/or other equipment ready to connect.

Multi Channel AV Receiver (1)

Optimizer microphone (ECM-AC2) (1) R6 (size-AA) batteries (2)

Remote control (RM-AAP064) (1) FM wire antenna (aerial) (1)AM loop antenna (aerial) (1)

Sony STR-DN1020 [GB] 4-282-221-11(1)

FRONT L SUBWOOFER SUBWOOFERCENTRE FRONT R

SUR RSUR BACK L SUR BACK R

SUR L

STR-DN1020

First, position your existing

speakers around the room

using the illustration below as a

reference.

 You can connect two FRONT HIGH

speakers instead of two SUR BACK

speakers if you prefer.

 Up to two subwoofers can be connected.

Sony STR-DN1020 [GB] 4-282-221-11(1)

Next, connect your speakers to the AV receiver.

Match the labels for each terminal to the

position of each speaker. Do not forget to

connect the subwoofer cable(s) as well.

Subwoofer 

10 mm

Progress

Sony STR-DN1020 [GB] 4-282-221-11(1)

Continue by connecting your

TV. To enjoy high-quality video

and audio, the best method is to

connect via a High Speed HDMI

cable (not supplied).

To connect your Blu-ray Disc

player, PlayStation®3, or satellite

tuner, simply connect with a High

Speed HDMI cable.

Blu-ray Disc player, PlayStation®3, or satellite tuner

Digital (better quality)

Analog (good quality)

Sony STR-DN1020 [GB] 4-282-221-11(1)

If your TV has an HDMI ARC

jack, you do not need an optical

digital cord.

If your TV has no HDMI ARC jack,

you need an optical digital cord

(not supplied) to enjoy TV sound

through the system speakers.

HDMI cable

Optical digital cord

Digital (better quality)

Analog (good quality)

Progress

Sony STR-DN1020 [GB] 4-282-221-11(1)

For FM radio, connect the supplied

FM wire antenna (aerial) into the

FM ANTENNA jack and extend it

for the best reception.

Alternatively, connect your own

external antenna (aerial).

You can connect to the internet

and home network services using

a LAN cable.

You can also connect your

iPhone/iPod to the iPhone/iPod

terminals.

Apple Composite

AV Cable (not supplied)

  



LAN cable (not supplied) FM wire antenna (aerial) AM loop antenna (aerial)

Sony STR-DN1020 [GB] 4-282-221-11(1)

/

Now you can switch on the AV receiver, TV,

subwoofer and other devices.

Do not forget to put batteries in the remote.

The shape of the wall

outlet (mains) differs

depending on the region.

/

Progress

Sony STR-DN1020 [GB] 4-282-221-11(1)

With the supplied remote, select the speaker

pattern according to your speaker system.

1 Press MENU.

The menu is displayed on the TV screen.

2 Press / repeatedly to select “Settings,” then

press .

3 Press / repeatedly to select “Speaker,” then

press .

4 Press / repeatedly to select “SP Pattern,”

then press .

5 Press / repeatedly to select the speaker

pattern you want, then press .

6 Press RETURN/EXIT .

RETURN/EXIT 

/,

Autres manuels pour STR-DN1020

Autres manuels Sony Récepteur

Sony

Sony STR-DN1060 Manuel d'utilisation et d'entretien

Sony

Sony STR-DB830 - Fm Stereo/fm-am Receiver Manuel utilisateur

Sony

Sony STR-DA5300ES - Multi Channel Av Receiver Manuel utilisateur

Sony

Sony STR-DN1040 Guide Manuel utilisateur

Sony

Sony STR-DG510 Manuel utilisateur

Sony

Sony ICF-7601 Manuel utilisateur

Sony

Sony HBD-E2100 Manuel utilisateur

Sony

Sony DMX-NV1 (For DMX-NV1 model sold separately) Manuel utilisateur

Sony

Sony STR-DH520 Manuel utilisateur

Sony

Sony CMA-87 Manuel utilisateur

Sony

Sony STR-DG800 Manuel utilisateur

Sony

Sony HCD-FX200 Manuel utilisateur

Sony

Sony STR-DE885 Guide de l'utilisateur

Sony

Sony HCD-FX900KW Manuel utilisateur

Sony

Sony HCD-DZ7T Manuel utilisateur

Sony

Sony ICF-7700 Manuel utilisateur

Sony

Sony STR-DA4300ES - Multi Channel Av Receiver Manuel utilisateur

Sony

Sony STR-DE897 Manuel utilisateur

Sony

Sony STR-DG600 - Multi Channel Av Receiver Manuel utilisateur
